Hikvision DS-6904UDI 4 Channel Output 4K Decoder, 4x 12MP, 8x 8MP, 12x 5MP, 20x 3MP, 32x 2MP
- Sku: DS-6904UDI
- Vendor: SecurityAustralia
Hikvision DS-6904UDI 4 Channel Output 4K Decoder, 4x 12MP, 8x 8MP, 12x 5MP, 20x 3MP, 32x 2MP
Designed for high-definition video monitoring systems, the Hikvision DS-6904UDI Decoder is built on an embedded hardware platform, ensuring exceptional reliability and stability during operation. This decoder supports simultaneous decoding capabilities across multiple resolutions, making it a versatile choice for complex surveillance setups.
The DS-6904UDI Decoder can handle up to 4 channels at 12MP, 8 channels at 8MP, 12 channels at 5MP, 20 channels at 3MP, and 32 channels at 2MP. It outputs decoded video through BNC, VGA, or HDMI interfaces and supports various video stream formats, including H.265, H.264+, H.264, and MPEG4, allowing for flexible display options on video walls or large screens.
Key Features
- Multi-Resolution Support: Capable of decoding up to 4 channels at 12MP, accommodating a wide range of surveillance needs.
- Flexible Output Options: Outputs decoded video via BNC, VGA, or HDMI, ensuring compatibility with various display devices.
- Multiple Video Formats: Supports H.265, H.264+, H.264, and MPEG4 formats for versatile video stream management.
- High Stability: Built on an embedded hardware platform for reliable and stable system performance during operation.
- Video Wall Capability: Designed for displaying decoded video on video walls or large screens, enhancing visual monitoring.
- Robust Decoding Performance: Handles simultaneous decoding across multiple resolutions for comprehensive surveillance coverage.
Code/SKU: DS-6904UDI
Quick Specs:
- Max Channel Capacity: Supports 4 channels at 12MP, 8 channels at 8MP, and 32 channels at 2MP for flexible configurations.
- Output Interfaces: Includes BNC, VGA, and HDMI for diverse connectivity options.
- Power Supply: Designed for efficient power usage while maintaining high performance in demanding environments.
Free shipping - Enjoy free shipping when your order exceeds $100!
All orders are despatched within the next business day!
Best local support in Aus! We back all products with a 3 year manufacturer warranty.
Not sure if this suits your site?
Ask our team before ordering. We can help confirm lens choice, recorder compatibility, mounting accessories and project quantities.
Product Overview
Transform Your Surveillance with the HIK-6904UDI Decoder
The HIK-6904UDI Decoder is designed for high-definition video monitoring systems, built on an embedded hardware platform that guarantees reliability and stability. It supports simultaneous decoding of up to 4 channels at 12MP, 8 channels at 8MP, and more, making it ideal for extensive surveillance setups.
With multiple output options, including BNC, VGA, and HDMI, the HIK-6904UDI ensures compatibility with a variety of display devices. It supports various video stream formats such as H.265, H.264+, and MPEG4, making it versatile for different surveillance applications.
This decoder excels in video wall displays and large screen projections, providing advanced viewing functions like window splicing and roaming, thus enhancing the overall monitoring experience for security professionals.
Features:
- Powerful decoding capability for up to 128 channels at 1080p resolution, allowing extensive monitoring for large-scale security operations and ensuring no critical event goes unnoticed.
- Multiple output interfaces including HDMI, VGA, and BNC, providing flexible connectivity options for various display needs and ensuring compatibility with existing surveillance infrastructure.
- Advanced video viewing functions such as window splicing, cross-window, and window division, enabling comprehensive monitoring setups tailored to specific surveillance requirements.
- Supports a wide range of video compression formats, including H.265+, H.264+, and MPEG4, ensuring efficient video streaming and storage while maintaining high-quality output.
- Up to 4K (3840×2160 at 30Hz) output via HDMI, delivering exceptional image clarity and detail for high-definition monitoring on compatible displays.
- Two decoding modes, active and passive, providing flexibility in resource management and allowing users to optimize performance based on system needs.
- Remote video file decoding output capabilities, facilitating the use of recorded footage in live monitoring scenarios for enhanced situational awareness.
- Configurable LED width and height parameters when connected, allowing for custom display setups to suit specific monitoring environments and enhancing visual impact.
Functions:
Comprehensive Decoding:
Efficiently decodes multiple high-resolution video streams, enabling seamless integration into surveillance systems for enhanced monitoring and management capabilities.
Multi-Channel Support:
Decodes up to 32 channels at 2MP resolution, ensuring extensive coverage and monitoring across large areas with minimal lag.
Flexible Output Options:
Provides HDMI, VGA, and BNC outputs for versatile display configurations, making it suitable for various surveillance setups and environments.
Network Protocol Compatibility:
Supports multiple protocols for easy integration into existing networks, ensuring reliable communication and data transmission for effective surveillance.
Advanced Video Functions:
Features window opening and roaming capabilities, allowing users to customize their monitoring setups based on specific surveillance needs.
Audio Functionality:
Enables two-way audio communication through client software, improving interaction and responsiveness during security events.
Remote Access and Control:
Allows for remote PTZ control and access to video streams, enhancing flexibility and responsiveness in surveillance operations.
Wi-Fi Module Access:
Supports Wi-Fi connectivity for mobile viewing, enabling users to access live feeds and recordings from iOS/Android devices without a wired network.
Technical Specifications
| Model | DS-6904UDI Decoder |
| Decoding Capability | 4-ch@12MP, 8-ch@8MP, 12-ch@5MP, 20-ch@3MP, 32-ch@2MP |
| Output Interfaces | HDMI, VGA, BNC |
| Max Output Resolution | Up to 4K (3840×2160@30Hz) |
| Video Compression Formats | H.265, H.264+, H.264, MPEG4, MJPEG |
| Video Viewing Functions | Window splicing, cross-window, window division, window roaming |
| Audio Compression Formats | G.722, G.711A, G.711U, G.726, MPEG2-L2, AAC |
| Decoding Modes | Active decoding and passive decoding |
| Audio Output | Two-way audio support |
| Multi-Screen Control | Supports multi-screen control with RSC server |
| Remote Access | Wi-Fi module access for mobile display |
| Stream Input | Supports URL and RTSP from encoding devices |
| LED Configuration | Configurable LED width and height parameters |
| Virtual Screen Configuration | Regular and irregular virtual screens supported |
| PTZ Control | Remote PTZ control via transparent channel |
| Power Supply | 100~240 VAC |
| Power Consumption | Max. 50W |
| Operating Temperature | -10 °C to +55 °C |
| Dimensions (W × D × H) | Approx. 440 × 340 × 70 mm |
| Weight (Without HDD) | 5.2 kg |
