Hikvision DS-2CD6395G1E-IVS 9MP Fisheye Network Camera 360° Panoramic, IR, Heat Map, IK10, IP67

Model: DS-2CD6395G1E-IVS

Who This Is For

For security integrators and facility managers who need full 360-degree room coverage from a single ceiling-mounted point, the Hikvision DS-2CD6395G1E-IVS delivers 9MP panoramic imaging with built-in IR, IVS analytics, and heat mapping from one fixed installation. It suits open-plan retail floors, hotel lobbies, warehouses, transit waiting areas, and any space where multiple cameras would otherwise be needed to eliminate blind spots. The IK10 vandal-resistant housing and IP67 rating make it suitable for semi-exposed or high-traffic ceiling positions where the camera may be subject to knocks or dust. Facilities teams monitoring customer flow patterns will find the heat map function particularly useful for layout decisions, while security operators benefit from a single camera delivering panoramic, panoramic-180, panoramic-270, and quad-view dewarped display modes without needing additional software licences.

What This Camera Actually Does

Who Buys This Model

• Retail store managers: Using heat map data to measure dwell time in product zones and identify underperforming floor layouts without installing multiple cameras across the floor plate.
• Security integrators specifying open-plan spaces: Replacing a 3- or 4-camera multi-dome layout with a single fisheye position, reducing cabling runs, NVR channel usage, and installation time on wide-floor sites like showrooms or trading floors.
• Facility managers in public environments: Specifying IK10-rated hardware for spaces like transit waiting areas, hospital waiting rooms, or government reception areas where camera tampering is a documented risk.
• After-hours warehouse and storage operators: Deploying the built-in IR to cover full floor area overnight without additional lighting infrastructure, using IVS line crossing to alert on unauthorised access outside business hours.

Honest Assessment

The DS-2CD6395G1E-IVS does the things a 9MP fisheye with heat mapping and on-camera IVS should do well - it replaces multiple standard cameras in open-plan ceiling coverage scenarios, gives operators dewarped views in multiple modes, and adds genuine operational value through heat map data that most single cameras cannot produce. The IK10 and IP67 ratings make it a credible choice for publicly accessible ceilings. Where it has limits: fisheye optics are not suited to long, narrow corridors where a varifocal or telephoto lens would maintain identification-quality resolution across distance. At the edges of the 360-degree image, resolution is stretched, so identification at the room perimeter depends on room size and mounting height. If coverage of a specific external approach or perimeter zone is the priority, a dedicated fixed or PTZ camera positioned at that point will outperform a ceiling-mounted fisheye. The DS-2CD6395G1E-IVS is available through Security Australia for projects where the single-mount panoramic brief is the right fit.

Before You Buy

Quick Fit Check

• Good match if: You are covering a medium-sized open-plan space such as a retail floor, reception area, or warehouse bay from a central ceiling point, and want to reduce channel count while retaining panoramic coverage with heat map reporting.
• Good match if: The installation environment involves public access or physical risk to the camera, and the IK10 vandal-resistant rating is a specification requirement rather than a preference.
• You may need a different model if: Your coverage requirement is a long outdoor perimeter, a specific entry point, or a location requiring optical zoom and identification at extended range - a multi-sensor panoramic camera or a varifocal bullet or PTZ camera will serve those scenarios more effectively.

Key Features & Technical Specifications

Real-World Scenarios

How It Compares

• Choose this if: Your brief is open-plan ceiling coverage from a single installation point, and you need heat map reporting and IVS analytics with IK10 protection - functionality that a standard dome or turret camera does not provide.
• You may need a different model if: Your coverage requirement is directional - a long exterior approach, a specific gate, or a loading dock entry - where a varifocal bullet, turret, or PTZ camera delivers usable identification resolution at range that a fisheye lens cannot match from ceiling height.
• Pairs well with: A compatible Hikvision PoE NVR with fisheye dewarping support, which unlocks the full range of display modes and allows heat map data to be accessed and exported directly from the recording platform.

Common Questions

1. Does the DS-2CD6395G1E-IVS actually dewarp the fisheye image, or do I need separate software?

   Both options are available. The camera outputs natively dewarped streams in panoramic-180, panoramic-270, 360-degree, and quad-view modes directly from the camera itself, which any ONVIF-compatible NVR or monitor can display without additional software. Full dewarping with interactive PTZ-style digital navigation within the fisheye image requires a compatible Hikvision NVR or iVMS-4200 client with fisheye plugin support enabled.

2. Will this camera work for night coverage in a room that has its lights switched off?

   Yes. The DS-2CD6395G1E-IVS has built-in IR illumination, which means it operates in low-light and darkness without requiring external lighting. This is not a given with all fisheye cameras, as the circular housing geometry makes integrating IR LEDs more complex. The built-in IR allows the camera to maintain overnight coverage in unlit spaces such as warehouses, storage rooms, and reception areas after hours.

3. How does the heat map function actually work, and where does the data go?

   The heat map is processed on-camera using the 9MP image feed. The camera accumulates movement data over a defined reporting period and generates a colour-coded overlay - red indicating zones of highest activity, blue indicating lowest. The data can be accessed and exported through a compatible Hikvision NVR interface or iVMS-4200 client. Reports can typically be scheduled daily, weekly, or over a custom date range, giving facilities and retail teams trend data without manual observation.

4. What does IK10 actually mean, and does this camera need it for indoor use?

   IK10 is the maximum rating in the IEC 62262 enclosure impact protection standard, confirming the housing withstands 20 joules of impact force - equivalent to a 5kg mass dropped from 400mm. For most standard office or retail ceiling installs, IK10 is precautionary. Where it becomes a genuine requirement is publicly accessible ceilings, schools, correctional facilities, transit environments, and industrial spaces where cameras are within reach or in the path of moving equipment.

5. What are the DORI distances for this fisheye camera - how close does a person need to be to be identified on camera?

   Fisheye cameras do not have fixed linear DORI distances in the same way a directional camera does, because the effective pixel density per subject varies based on mounting height, radial distance from the centre of the image, and the dewarping mode in use. As a practical guide, for subject identification quality on a 9MP fisheye, subjects should be within 4 to 6 metres of the camera at a mounting height of 3 to 4 metres. At greater radial distances or mounting heights above 5 metres, the camera provides observation and detection quality but not reliable identification - this is a physical limitation of fisheye optics, not a product defect, and should be factored into the coverage design before installation.

6. Does the on-camera IVS work across the full 360-degree image, and how are detection zones set up?

   Yes. IVS analytics including line crossing and intrusion detection operate across the full fisheye field of view. Detection zones are configured through the camera's web interface or through a compatible NVR interface, where the operator draws the detection line or polygon over the dewarped or raw fisheye image. The camera handles the coordinate translation between the fisheye plane and the actual physical space. Alarm outputs can be directed to the NVR, to an email alert, or to a connected alarm output if wired. Stocked by Security Australia, the DS-2CD6395G1E-IVS supports the full Hikvision IVS configuration workflow without requiring additional licences for these functions.

7. Is PoE sufficient to power this camera, or does it require PoE+?

   Standard PoE at IEEE 802.3af is sufficient. The DS-2CD6395G1E-IVS also accepts 12V DC if a direct power supply is preferred. A standard PoE switch or PoE NVR port delivers both power and data over a single Cat5e or Cat6 cable run, which keeps the ceiling installation clean and avoids the need for a separate power adapter or local outlet above the ceiling.
