Robust, first-class 4 MP video with 32x optical zoom
The AXIS Q1786-LE Network Camera is a versatile, high-performance camera that delivers 4 megapixel resolution and 32x optical zoom. It offers flexible installation at any distance and provides detailed video for accurate identification. Designed to withstand tough environments, it features a wide temperature range, impact resistance, and IP66, IP67, and NEMA 4X ratings. With Lightfinder, Forensic WDR, and OptimizedIR (with an 80 m / 262 ft range), it ensures clear details in both challenging lighting conditions and complete darkness. The AXIS Q1786-LE also includes built-in analytics for proactive surveillance, corridor format support, and audio input for videos with sound.
Key Features
Code/SKU: AXIS Q1786-LE
Quick Specs:
| Category | Details |
|---|---|
| Image Sensor | 1/1.8" progressive scan RGB CMOS |
| Lens | 4.3–137 mm, F1.4–4.0 |
| Horizontal Field of View | 60°–2.3° |
| Vertical Field of View | 39°–1.3° |
| Autofocus, Auto-Iris | Automatic day/night |
| Filter Thread | 62 mm, max filter thickness: 5 mm |
| Day/Night Mode | Automatically removable infrared-cut filter in day mode and infrared-pass filter 720 nm in night mode |
| Minimum Illumination | Color: 0.18 lux at 50 IRE F1.4 B/W: 0.04 lux at 50 IRE F1.4 0 lux with IR illumination on |
| Shutter Speed | 1/100000 s to 2 s |
| System on Chip (SoC) | ARTPEC-6 |
| Memory | 1024 MB RAM, 512 MB Flash |
| Video Compression | H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High Profiles Motion JPEG |
| Resolution | 2560x1440 to 160x120 |
| Maximum Pixel Density | 25 m (82 ft): 2551 px/m 50 m (164 ft): 1275 px/m 250 m (820 ft): 255 px/m |
| Frame Rate | With WDR: Up to 25/30 fps (50/60 Hz) in all resolutions Without WDR: Up to 50/60 fps (50/60 Hz) in all resolutions |
| Video Streaming | Multiple, individually configurable streams in H.264 and Motion JPEG Axis Zipstream technology in H.264 Controllable frame rate and bandwidth VBR/ABR/MBR H.264 |
| Image Settings | Saturation, contrast, brightness, sharpness, Forensic WDR: Up to 120 dB depending on scene, defogging, white balance, day/night threshold, exposure mode, exposure zones, compression, mirroring of images, electronic image stabilization, barrel distortion correction, text and image overlay, dynamic text and image overlay, privacy masks Rotation: auto, 0°, 90°, 180°, 270° including Corridor Format Scene profiles: forensic, vivid, traffic overview, backlit entrance |
| Pan/Tilt/Zoom | 32x optical zoom, preset positions |
| Audio Streaming | Audio in, simplex Two-way audio via edge-to-edge technology Audio encoding AAC-LC 8/16/32/48 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz, Opus 8/16/48 kHz, LPCM Configurable bit rate |
| Audio Input/Output | Automatic gain control, external microphone input, line input, digital input with ring power, balanced microphone, balanced input Network speaker pairing |
| Network Protocols | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTP/2, HTTPS, TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP®, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf) |
| System Integration | Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at axis.com AXIS Video Hosting System (AVHS) with One-Click Connection One-click cloud connection ONVIF® Profile G, ONVIF® Profile M, ONVIF® Profile S, and ONVIF® Profile T, specification at onvif.org |
| Onscreen Controls | Electronic image stabilization Day/night shift Defogging Wide dynamic range IR illumination Autofocus |
| Event Triggers | Analytics, edge storage events Supervised external input, virtual inputs through API, shock detection, audio detection MQTT subscribe |
| Event Actions | Pre- and post-alarm video buffering File upload: FTP, SFTP, HTTP, HTTPS, network share and email MQTT publish Notification: email, HTTP, HTTPS, TCP and SNMP trap |
| Data Streaming | Event data |
| Built-in Installation Aids | Remote zoom, pixel counter, leveling assistant, autorotation |
| Analytics Applications Included | AXIS Motion Guard, AXIS Fence Guard, AXIS Loitering Guard AXIS Video Motion Detection, active tampering alarm, gatekeeper |
| Supported Analytics | AXIS Perimeter Defender, AXIS Cross Line Detection Support for AXIS Camera Application Platform enabling installation of third-party applications, see axis.com/acap |
| Cybersecurity | Edge security Software: Signed firmware, brute force delay protection, digest authentication, password protection Network security IEEE 802.1X (EAP-TLS), HTTPS/HSTS, TLS v1.2/v1.3, Network Time Security (NTS), X.509 Certificate PKI, IP address filtering Documentation AXIS OS Hardening Guide Axis Vulnerability Management Policy Axis Security Development Model AXIS OS Software Bill of Material (SBOM) To download documents, go to axis.com/support/cybersecurity/resources To read more about Axis cybersecurity support, go to axis.com/cybersecurity |
| Casing | IP66-, IP67-, and NEMA 4X-rated, IK10 impact-resistant aluminum enclosure with integrated dehumidifying membrane, IK08 impact-resistant glass front window, weathershield with black anti-glare coating Color: White NCS S 1002-B For repainting instructions of casing and impact on warranty, contact your Axis partner. |
| Sustainability | PVC free, 2% recycled plastic |
| Power | Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 3 Typical 8.6 W, max 12.95 W 20–28 V DC, typical 8.6 W, max 13.8 W 20–24 V AC, typical 12.6 V A, max 20 V A |
| Connectors | Shielded RJ45 10BASE-T/100BASE-TX PoE IDC punchdown connector DC Power connector Terminal block for two configurable supervised inputs / digital outputs (12 V DC output, max. load 50 mA) 3.5 mm mic/line in |
| IR Illumination | OptimizedIR with power-efficient, long-life 850 nm IR LED’s with adjustable angle of illumination and intensity. Range of reach 30 m (98 ft) in wide field of view and 80 m (262 ft) in full tele view, or more depending on the scene |
| Storage | Support for microSD/microSDHC/microSDXC card Support for SD card encryption (AES-XTS-Plain64 256bit) Recording to network-attached storage (NAS) For SD card and NAS recommendations see axis.com |
| Operating Conditions | -40 °C to 60 °C (-40 °F to 140 °F) Maximum temperature according to NEMA TS 2 (2.2.7): 74 °C (165 °F) Humidity 10-100% RH (condensing) |
| Storage Conditions | -40 °C to 65 °C (-40 °F to 149 °F) Humidity 5-95% RH (non-condensing) |
| Approvals EMC | EN 55032 Class A, EN 50121-4, IEC 62236-4, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-003 Class A, VCCI Class A, RCM AS/NZS CISPR 32 Class A, KCC KN32 Class A, KN35, EAC |
| Approvals Safety | IEC/EN/UL 62368-1, IEC/EN/UL 60950-22, EN/IEC 62471 IS 13252 |
| Environment | EN 50581, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-30, IEC 60068-2-27, IEC 60068-2-78, IEC/EN 60529 IP66, IP67, IEC/EN 62262 IK10 body, IK08 glass, NEMA 250 Type 4X, NEMA TS 2 (2.2.7-2.2.9) |
| Network | NIST SP500–267 |
| Dimensions | Length: 386 mm (15 3/16 in) ø 147 mm (5 13/16 in) |
| Weight | 2.4 kg (5.3 lb) |
| Included Accessories | Installation guide, Windows® decoder 1-user license, connector kit, Resistorx® L-key RJ45 patch cable |
| Optional Accessories | AXIS T8604 Media Converter Switch AXIS T91A47 Pole Mount, AXIS T94P01B Corner Bracket AXIS Q17 Front Window Kit B (IK10 impact-resistant plastic front window) For more accessories, see axis.com |
| Video Management Software | AXIS Companion, AXIS Camera Station, video management software from Axis Application Development Partners available at axis.com/vms |
| Languages | English, German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese, Traditional Chinese, Dutch, Czech, Swedish, Finnish, Turkish, Thai, Vietnamese |
All IP cameras and recording devices (NVR’s/DVR’s) are covered by a 3 year back-to-base manufacturer warranty.
Our warranty is limited to the replacement of faulty items or parts and does not include damage due to incorrect fitting of parts or accessories, or damage due to mishandling the equipment once out of the box. All faults are sent to the manufacturer for inspection and diagnosis before a replacement is sent out.
Read more about the Terms & Conditions here – https://www.securityaustralia.com.au/terms-and-conditions/
*Just spend over $100 to activate Fast Free Shipping!
Despatch Times: Products are despatched on the same day if the order was placed before 11am on any weekday, Monday - Friday. All other orders are processed and despatched within 24 hours or next business day.
Order Confirmation: Once you place an order, you will receive a confirmation email. This indicates that your order has been received in our system and is now being processed for dispatch. If your item is back-ordered or unavailable, we will notify you via email, and if we do not receive a response, we will attempt to contact you by phone as soon as possible. We value your time and strive to be prompt. If your item(s) are available for immediate shipment (within 2 days), we will process the charges and prepare the order for shipping.
Shipping Times: General shipping times for StarTrack, TNT and Allied couriers are between 1-3 working days from despatch. Longer delivery times may be caused by your package being held at your local courier depot that is beyond our control. Please contact us or the local post depot for confirmation.
Tracking Numbers: all tracking numbers will be emailed to you by our warehouse processing team within the day, after your order is despatched to our local courier.
AXIS Q1786-LE 4MP Outdoor Bullet 4.3-137MM VF Lens, 32X Optical Zoom
The AXIS Q1786-LE is a high-performance 4 MP camera designed for both day and night surveillance. It boasts a powerful 32x optical zoom, allowing for detailed close-ups from a significant distance. With its advanced image sensor, the camera delivers crisp and clear visuals even in challenging lighting conditions. The built-in infrared illumination ensures that the camera captures high-quality images in complete darkness. It features Axis' Lightfinder technology, enhancing color images in low-light scenarios. The camera's robust design is suitable for various weather conditions, making it ideal for outdoor installations. Its P-Iris control optimizes image sharpness and depth of field. The AXIS Q1786-LE supports advanced video analytics, such as motion detection and tampering alarms, providing enhanced security features. Integration with Axis' network solutions allows for seamless connectivity and management. The camera supports multiple streaming formats, offering flexibility in recording and monitoring. Its compact and discreet design ensures that it blends well with any environment. The camera’s Power over Ethernet (PoE) capability simplifies installation by eliminating the need for separate power cables. Axis' VAPIX API enables easy integration with third-party systems and software. The camera also includes a secure HTTPS connection to safeguard data transmission. With its combination of high resolution, optical zoom, and advanced features, the AXIS Q1786-LE is a top choice for comprehensive surveillance needs.
Features
| Image Sensor | 1/1.8" progressive scan RGB CMOS |
| Lens | 4.3–137 mm, F1.4–4.0 |
| Horizontal Field of View | 60°–2.3° |
| Vertical Field of View | 39°–1.3° |
| Autofocus, Auto-Iris | Automatic day/night |
| Filter Thread | 62 mm, max filter thickness: 5 mm |
| Day/Night Mode | Automatically removable infrared-cut filter in day mode and infrared-pass filter 720 nm in night mode |
| Minimum Illumination | Color: 0.18 lux at 50 IRE F1.4 B/W: 0.04 lux at 50 IRE F1.4 0 lux with IR illumination on |
| Shutter Speed | 1/100000 s to 2 s |
| System on Chip (SoC) | ARTPEC-6 |
| Memory | 1024 MB RAM, 512 MB Flash |
| Video Compression | H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High Profiles Motion JPEG |
| Resolution | 2560x1440 to 160x120 |
| Maximum Pixel Density | 25 m (82 ft): 2551 px/m 50 m (164 ft): 1275 px/m 250 m (820 ft): 255 px/m |
| Frame Rate | With WDR: Up to 25/30 fps (50/60 Hz) in all resolutions Without WDR: Up to 50/60 fps (50/60 Hz) in all resolutions |
| Video Streaming | Multiple, individually configurable streams in H.264 and Motion JPEG Axis Zipstream technology in H.264 Controllable frame rate and bandwidth VBR/ABR/MBR H.264 |
| Image Settings | Saturation, contrast, brightness, sharpness, Forensic WDR: Up to 120 dB depending on scene, defogging, white balance, day/night threshold, exposure mode, exposure zones, compression, mirroring of images, electronic image stabilization, barrel distortion correction, text and image overlay, dynamic text and image overlay, privacy masks Rotation: auto, 0°, 90°, 180°, 270° including Corridor Format Scene profiles: forensic, vivid, traffic overview, backlit entrance |
| Pan/Tilt/Zoom | 32x optical zoom, preset positions |
| Audio Streaming | Audio in, simplex Two-way audio via edge-to-edge technology Audio encoding AAC-LC 8/16/32/48 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz, Opus 8/16/48 kHz, LPCM Configurable bit rate |
| Audio Input/Output | Automatic gain control, external microphone input, line input, digital input with ring power, balanced microphone, balanced input Network speaker pairing |
