  • Sku: DS-2CD2386G2-IU / DS-7616NI
  • Vendor: SecurityAustralia

8MP 16CH Hikvision CCTV Kit: 8 x Outdoor Acusense Turret Cameras + 16CH NVR with 3TB

$4,298.00 AUD
 per
In stock!
Spend $100.00 to FREE SHIPPING

Kit Includes:

  • 8 x 8 MP Hikvision Outdoor Turret Cameras (DS-2CD2386G2-IU)
  • 1 x 16 CH Hikvision PoE NVR (DS-7616NI-I2-16P) with 3TB Hard Drive

Overview:

This Hikvision surveillance kit is designed for users seeking reliable video monitoring without the siren and strobe features. It includes eight 8MP AcuSense turret cameras paired with a 16-channel NVR, delivering comprehensive security for larger properties.

Key Features:

  • High Resolution: 8MP cameras provide clear, detailed video.
  • Infrared Range: 30m IR ensures effective night vision.
  • Environmental Protection: IP67-rated for water and dust resistance.
  • Wide Dynamic Range: 120dB true WDR offers clarity in varying lighting conditions.
  • Audio Capability: Built-in microphone enables real-time audio monitoring.

Technical Details:

  • Lens Options: 2.8mm
  • NVR Capacity: 16 channels, 4K output, with a 3TB hard drive.

Suitable For:

This kit is ideal for those requiring extensive surveillance coverage without deterrent features like sirens and strobe lights, perfect for residential and commercial properties.

Specifications

Camera Image Sensor
1/1.8" Progressive Scan CMOS
Min. Illumination
Color: 0.003 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
Shutter Speed 1/3 s to 1/100,000 s
Slow Shutter Yes
P/N Wide Dynamic Range
120 dB
Day & Night
IR cut filter
Angle Adjustment Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
Lens Lens Type
Fixed focal lens, 2.8, 4, and 6 mm optional
Focal Length & FOV
2.8 mm, horizontal FOV 111°, vertical FOV 59°, diagonal FOV 131°
4 mm, horizontal FOV 87°, vertical FOV 47°, diagonal FOV 102°
6 mm, horizontal FOV 51°, vertical FOV 28°, diagonal FOV 60°
Lens Mount M12
Iris Type Fixed
Aperture F1.6
DORI 2.8 mm: D: 89.2 m, O: 35.4 m, R: 17.8 m, I: 8.9 m
4 mm: D: 99.4 m, O: 39.4 m, R: 19.9 m, I: 9.9 m
6 mm: D: 140.0 m, O: 55.6 m, R: 28.0 m, I: 14.0 m
Illuminator Supplement Light Type
IR
Smart Supplement Light
Yes
IR Wavelength
850 nm
IR Range
Up to 30 m
Video Max. Resolution
3840 × 2160
Main Stream
50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 24 fps (3840 × 2160) 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
Third Stream
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
*Third stream is supported under certain settings.
Video Compression Main stream: H.265/H.264/H.264+/H.265+
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
*Third stream is supported under certain settings.
Video Bit Rate H.264 Type: 32 Kbps to 16 Mbps (Baseline Profile/Main Profile/High Profile)
H.265 Type: Main Profile
H.264+: Main stream supports
H.265+: Main stream supports
Bit Rate Control CBR/VBR
Scalable Video Coding (SVC) H.264 and H.265 encoding
Region of Interest (ROI) 1 fixed region for main stream and sub-stream
Audio Audio Type
Mono sound
Audio Compression
G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bit Rate
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
Audio Sampling Rate 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Environment Noise Filtering Yes
Network Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets
Simultaneous Live View
Up to 6 channels
API
Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK
User/Host Security Up to 32 users. 3 user levels: administrator, operator and user
Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
Network Storage NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Client Web Browser
iVMS-4200, Hik-Connect, Hik-Central
Plug-in required live view: IE 10, IE 11
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Image Image Parameters Switch
Yes
Image Settings
Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
Day/Night Switch
Day, Night, Auto, Schedule
SNR
≥ 52 dB
Image Enhancement
BLC, HLC, 3D DNR
Target Cropping
Yes
Interface Ethernet Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage
Built-in micro SD/SDHC/SDXC slot, up to 512 GB
Built-in Microphone
Yes
Hardware Reset
Yes
Event Basic Event
Motion detection (human and vehicle targets classification), video tampering alarm, exception
Smart Event
Scene change detection
Deep Learning Function
Face Capture
Perimeter Protection
Line crossing detection, intrusion detection, region entrance detection, region exiting detection
Supports human and vehicle targets classification
General Linkage Method
Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture
Camera Material
Metal
Camera Dimension
Ø138.3 mm × 126.3 mm (Ø5.4" × 5")
Package Dimension
170 mm × 170 mm × 150 mm (6.9" × 6.9" × 5.9")
Camera Weight
Approx. 740 g (1.6 lb.)
With Package Weight
Approx. 1020 g (2.2 lb.)
Storage Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup and Operating Conditions
-30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing)
Web Client Language
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General Function
Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter
Firmware Version
V5.5.112
Software Reset
Yes
Power Consumption and Current
12 VDC, 0.48 A, max. 5.8 W
Power Supply
PoE (802.3af, 36 V to 57 V), 0.19 A to 0.12 A, max. 6.8 W
12 VDC ± 25%, reverse polarity protection
PoE: 802.3af, Class 3
Power Interface
Ø5.5 mm coaxial power plug
Approval EMC
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); KC (KN 32: 2015, KN 35: 2015)
Safety
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 609501:2005 + Am 1:2009 + Am 2:2013)
Environment Protection
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Protection
IP67 (IEC 60529-2013)

Documentation

3 Years Manufacturer Warranty

All IP cameras and recording devices (NVR’s/DVR’s) are covered by a 3 year back-to-base manufacturer warranty.

Our warranty is limited to the replacement of faulty items or parts and does not include damage due to incorrect fitting of parts or accessories, or damage due to mishandling the equipment once out of the box. All faults are sent to the manufacturer for inspection and diagnosis before a replacement is sent out.

Read more about the Terms & Conditions here – https://www.securityaustralia.com.au/terms-and-conditions/

Trusted Brand Partner & Security Equipment Wholesaler

Authorised Brand Partner with Responsive & Fast Aussie Sales Support Team ★★★★★
Best After-Sales Support and Troubleshooting Team with Years of Installation Experience.

Free Delivery* & Despatch Time

*Just spend over $100 to activate Fast Free Shipping!

Despatch Times: Products are despatched on the same day if the order was placed before 11am on any weekday, Monday - Friday. All other orders are processed and despatched within 24 hours or next business day.

Order Confirmation: Once you place an order, you will receive a confirmation email. This indicates that your order has been received in our system and is now being processed for dispatch. If your item is back-ordered or unavailable, we will notify you via email, and if we do not receive a response, we will attempt to contact you by phone as soon as possible. We value your time and strive to be prompt. If your item(s) are available for immediate shipment (within 2 days), we will process the charges and prepare the order for shipping.

Shipping Times: General shipping times for StarTrack, TNT and Allied couriers are between 1-3 working days from despatch. Longer delivery times may be caused by your package being held at your local courier depot that is beyond our control. Please contact us or the local post depot for confirmation.

Tracking Numbers: all tracking numbers will be emailed to you by our warehouse processing team within the day, after your order is despatched to our local courier.

View full details

8MP 16CH Hikvision CCTV Kit: 8 x Outdoor Acusense Turret Cameras + 16CH NVR with 3TB

$4,298.00 AUD
 per

Enhanced Security with 4K Resolution and AcuSense Gen2 Technology

Elevate your security setup with the Hikvision DS-2CD2386G2-IU, a powerful 8MP fixed turret network camera from the AcuSense Gen2 range. Designed to deliver superior performance in both residential and commercial environments, this camera offers crystal-clear 4K resolution, making it an ideal choice for capturing intricate details in surveillance footage. Equipped with DarkFighter technology, the DS-2CD2386G2-IU excels in low-light conditions, ensuring clear and vivid imaging even at just 0.003 lux. The camera also features 120 dB true WDR technology, providing optimal clarity in challenging lighting situations, such as areas with strong backlight. With efficient H.265+ compression, it minimizes bandwidth usage while maintaining high video quality, making storage more efficient.

This model is enhanced with Hikvision’s AcuSense technology, which utilizes deep learning algorithms to distinguish between human and vehicle targets, significantly reducing false alarms. Its IP66-rated housing ensures the camera is well-protected against water and dust, making it suitable for outdoor installations. Additionally, the built-in two-way audio allows for real-time communication, adding an extra layer of security through customizable warnings during events.

Functions:

Advanced AcuSense Technology: The Hikvision DS-2CD2386G2-IU is equipped with AcuSense technology, which harnesses deep learning algorithms to accurately classify human and vehicle activities. This technology significantly reduces false alarms, enabling security teams to concentrate on actual threats. The advanced analytics also provide efficient monitoring, ensuring that only relevant events trigger alerts, thereby optimizing the response time and overall security efficiency.

Superior Low-Light Performance with DarkFighter: DarkFighter technology integrated into this camera enhances its ability to capture clear and detailed footage even in near-complete darkness, down to 0.003 lux. This makes it an ideal choice for areas where lighting conditions are less than optimal, ensuring 24/7 surveillance capability. The technology ensures that the camera delivers bright and sharp images, even in scenarios where lighting is minimal, thereby enhancing the security coverage.

Efficient H.265+ Compression: The camera features H.265+ compression technology, which significantly reduces the bandwidth and storage requirements without compromising the quality of the video. This efficiency is crucial for long-term surveillance operations where storage capacity and network bandwidth can be a constraint. By utilizing this technology, users can store high-quality video footage over longer periods, making it both cost-effective and efficient for large-scale security applications.

120 dB True WDR Technology: The wide dynamic range (WDR) technology integrated into this camera ensures clear and balanced imaging in environments with challenging lighting, such as areas with strong backlighting or high contrast between bright and dark areas. This feature is particularly beneficial in outdoor settings where natural light can create difficult viewing conditions. The 120 dB true WDR enables the camera to adjust the exposure dynamically, capturing details in both shadows and highlights for comprehensive scene coverage.

Two-Way Audio Communication: The built-in two-way audio feature allows security personnel to interact directly with individuals on-site through the camera. This function is invaluable for issuing warnings, communicating with visitors, or deterring potential intruders. The ability to both listen and speak through the camera adds an extra layer of security, making it not just a passive surveillance tool but an active deterrent system as well.

Key Features:

  • High-Resolution Imaging: 8MP (4K) resolution delivers crystal-clear video quality for detailed surveillance.
  • Low-Light Performance: DarkFighter technology ensures vivid imaging even in low-light conditions, down to 0.003 lux.
  • Wide Dynamic Range: 120 dB true WDR technology provides clear images in challenging lighting scenarios.
  • Efficient Compression: H.265+ compression reduces bandwidth and storage needs while maintaining high video quality.
  • Intelligent Detection: AcuSense technology offers accurate human and vehicle classification to reduce false alarms.
  • Two-Way Audio: Built-in microphone and speaker for real-time communication and active deterrence.
  • Durable Design: IP66-rated protection ensures the camera is resistant to water and dust, suitable for outdoor use.

Specifications:

Resolution: 8MP (4K)
Low-Light Performance: Powered by DarkFighter technology
Wide Dynamic Range: 120 dB true WDR
Compression: H.265+
Intelligent Detection: Human and vehicle classification with AcuSense technology
Audio: Two-way audio
Protection: IP66-rated for outdoor use

Experience enhanced security with detailed 4K resolution and advanced features tailored for outdoor applications. This camera is the ideal choice for those who need a reliable, high-performance, and intelligent surveillance solution.
