| Camera |
| | |
| Image Sensor: | | | 1/2.9" Progressive Scan CMOS |
| | |
| Signal System: | | | PAL/NTSC |
| | |
| Min. Illumination: | | | Color: 0.01 lux @(F1.2, AGC ON), 0 lux with IR |
| | |
| Shutter time: | | | 1/3 s to 1/100,000 s |
| | |
| Slow shutter: | | | Support |
| | |
| Lens: | | | 2.8 mm, horizontal field of view: 80°4 mm, horizontal field of view: 63.5°6mm, horizontal field of view: 50°12 mm, horizontal field of view: 16° |
| | |
| Lens Mount: | | | M12 |
| | |
| Adjustment Range: | | | Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355° |
| | |
| Day& Night: | | | IR cut filter with auto switch |
| | |
| Wide Dynamic Range: | | | 120 dB |
| | |
| Digital noise reduction: | | | 3D DNR |
| Compression Standard |
| | |
| Video Compression: | | | H.265+/H.265/H.264+/H.264/MJPEG |
| | |
| Video bit rate: | | | 32Kbps~16Mbps |
| | |
| Triple Streams: | | | Yes |
| Image |
| | |
| Max. Image Resolution: | | | 1920 x 1080 |
| | |
| Frame Rate: | | | 50Hz: 20 fps (2560 × 1920), 25 fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 ×720)60Hz: 20 fps (2560 × 1920), 30 fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 ×720) |
| | |
| Sub Stream: | | | 50Hz: 25fps (640 × 360, 352 × 288)60Hz: 30fps (640 × 360, 352 × 240) |
| | |
| Third Stream: | | | 50Hz: 25fps (1280 ×720, 640 × 360, 352 × 288)60Hz: 30fps (1280 ×720, 640 × 360, 352 × 240) |
| | |
| Image Enhancement: | | | BLC/3D DNR |
| | |
| Image Settings: | | | Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
| | |
| Target Cropping: | | | Support |
| | |
| ROI: | | | Support 1 fixed region for each stream |
| | |
| Day/Night Switch: | | | Auto/Scheduled |
| Network |
| | |
| Protocols: | | | TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6 |
| | |
| General Function: | | | One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacymask, Watermark, IP address filtering |
| | |
| System Compatibility: | | | ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI |
| Interface |
| | |
| Communication Interface: | | | 1 RJ45 10M / 100M Ethernet interface |
| | |
| On-board storage: | | | Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Smart Feature-set |
| | |
| Behavior Analysis: | | | Line crossing detection, Intrusion detection, Unattended baggage detection, Object removal detection |
| | |
| Line Crossing Detection: | | | Cross a pre-defined virtual line |
| | |
| Intrusion Detection: | | | Enter and loiter in a pre-defined virtual region |
| | |
| Unattended Baggage: | | | Objects left over in the pre-defined region such as the baggage, purse, dangerous materials |
| | |
| Object Removal: | | | Objects removed from the pre-defined region, such as the exhibits on display. |
| | |
| Recognition: | | | Face Detection |
| General |
| | |
| Operating Conditions: | | | -30 °C ~ 60 °C (-22 °F ~ 140 °F)Humidity 95% or less (non-condensing) |
| | |
| Power Supply: | | | 12 VDC ± 25%, PoE (802.3af Class3) |
| | |
| Power Consumption: | | | 12 VDC ± 25%, 6.2 WPoE(802.3af, class 3), 9 W |
| | |
| Impact Protection: | | | IK10 |
| | |
| Weather Proof: | | | IP67 |
| | |
| IR Range: | | | Up to 30m |
| | |
| Dimensions: | | | Camera: Φ 111 × 82.4 mm (Φ 4.4″ × 3.2″)Package: 134 × 134 × 108 mm (5.27″ × 5.27″ × 4.25″) |
| | |
| Weight: | | | Camera: 500 g (1.1 lb.) |
Code/SKU:
1 x 8 CH Hikvision PoE NVR
Code/ SKU:
Upgrades available:
+ $200 Upgrade to 16 CH NVR
If you require different lens or IR range for each camera in this kit, please specify in the comments upon checkout. We will ship the right cameras to you.
