Vivotek AO-20W Wiegand Converter

  • Sku: AO-20W
  • Vendor: SecurityAustralia
$815.00 AUD
Tax included.
Shipping calculated at checkout.
In stock - Ready to ship
Free shipping on orders over $100. Usually ships within 1 business day when available.
Quick Buying Summary
Easy Integration • Ethernet to Wiegand Output Conversion The Wiegand protocol is commonly used in traditional access control systems, which grant access to drivers based on their badge with valid Wiegand ID numbers. In order to easily upgrade existing access control systems with the power of VIVOTEK LPR cameras, VIVOTEK’s onboard ANPR software can link license plates to specific Wiegand ID numbers (eg. driver’s badge). In the meantime, the VIVOTEK Wiegand converter can convert the Ethernet signal to Wiegand output signal in order to work with the existing access control system. Key Features
  • Easy Integration into any Access Control System
  • Use in Combination with the ANPR Access Service
  • Supports Ethernet to Wiegand Output Conversion
  • Supports 26-bit and 34-bit Wiegand Format
AO-20W Datasheet

Need help choosing?

Click to ask a question - same day response (~2 hours during business hours)

Free shipping Enjoy free shipping when your order exceeds $100. Fast dispatch Orders are dispatched within the next business day. Best local support in Aus We back all products with manufacturer warranty support. Official Australian stock Genuine products with local warranty support.

Product Overview

The Wiegand protocol is commonly used in traditional access control systems, which grant access to drivers based on their badge with valid Wiegand ID numbers. In order to easily upgrade existing access control systems with the power of VIVOTEK LPR cameras, VIVOTEK’s onboard ANPR software can link license plates to specific Wiegand ID numbers (eg. driver’s badge). In the meantime, the VIVOTEK Wiegand converter can convert the Ethernet signal to Wiegand output signal in order to work with the existing access control system. Moreover, with VIVOTEK’s ANPR software, you can also easily configure a mapping list to link plate numbers to specific ID numbers and set specific actions to individual groups. Technical Specifications
Product Information
Model AO-20W
Hardware
TCP Server 10/100 Mbps Base T Ethernet <--> RS485 (Auto-detection by order: RS232, RS232+RS485)
Server Port 0 Baud rate: 2400 bps - 115200 bps Support TCP/Server, TCP/Client, UDP mode
Server Port 1 Baud rate: 2400 bps - 115200 bps Support TCP/Server, TCP/Client, UDP mode
Maximum Wiegand Output Up to 96 bits
PoE No
General
Connectors Digital input x 8 Digital output x 4: relay output x1 & digital output x3 (DO1, DO2 = WG data 1, data 0 when using Wiegand protocol)
LED Indicator 9 LEDs for power, communication
Power Input DC 9 ~ 24V
Power Consumption Max. 2W
Dimension 106.5 (L) x 66.3 (W) x 27.7 (H) mm
Weight 86 (±5) g
Safety Certifications FCC, CE, RoHs
Operating Temperature Starting Temperature: -25°C ~ 85°C (14°F ~ 185°F) Working Temperature: -20°C ~ 65°C (-4°F ~ 149°F)
Humidity Storage: 5% ~ 95% Working: 20% ~ 90%
Buffer 1K each channel
Surge Protection Power: 30 Volt, bi-directional avalanche breakdown device RS485 6.5 Volt, bi-directional avalanche breakdown device 400W peak power dissipation Clamping time < 1 picosecond (theoretical)
Fuse Protection Power PTC 150mA / RS485 PTC 30mA
Software
Software Setting 701Server, 701Client HTTP web browser
Operating System Windows 7/8/10 Win Server 2008/2012/2016
Watchdogs Yes, build in watchdog for system error handling

Key Features

Trusted Brand Partner & Security Equipment Wholesaler

  • Authorised Brand Partner with Responsive & Fast Aussie Sales Support Team ★★★★★
  • Best After-Sales Support and Troubleshooting Team with Years of Installation Experience.

What This Product Does

Easy Integration • Ethernet to Wiegand Output Conversion The Wiegand protocol is commonly used in traditional access control systems, which grant access to drivers based on their badge with valid Wiegand ID numbers. In order to easily upgrade existing access control systems with the power of VIVOTEK LPR cameras, VIVOTEK’s onboard ANPR software can link license plates to specific Wiegand ID numbers (eg. driver’s badge). In the meantime, the VIVOTEK Wiegand converter can convert the Ethernet signal to Wiegand output signal in order to work with the existing access control system. Key Features
  • Easy Integration into any Access Control System
  • Use in Combination with the ANPR Access Service
  • Supports Ethernet to Wiegand Output Conversion
  • Supports 26-bit and 34-bit Wiegand Format
AO-20W Datasheet
