Tp-Link TL-DS1018GMP Omada 18-Port Gigabit Unmanaged Rackmount Switch with 16-Port PoE+

  • Sku: TL-DS1018GMP
  • Vendor: SecurityAustralia
$349.00 AUD
Tax included.
Shipping calculated at checkout.
In stock - Ready to ship
Free shipping on orders over $100. Usually ships within 1 business day when available.
Quick Buying Summary
The Omada 18-Port Gigabit Unmanaged Rackmount Switch with 16-Port PoE+ (DS1018GMP) is designed for high-performance networking in various environments, including offices and small businesses. It features 16 Gigabit PoE+ RJ45 ports and 2 combo Gigabit SFP slots, allowing for versatile connectivity options. The switch boasts a substantial PoE power budget of 250 W, with each PoE port supporting up to 30 W, making it suitable for powering devices like IP cameras, access points, and IP phones. Its plug-and-play design ensures easy setup without the need for configuration, catering to users who prefer straightforward installations. Key Features
  • 16× Gigabit PoE+ RJ45 ports and 2× Combo Gigabit SFP slots
  • High PoE power budget with up to 30 W for each PoE port and 250 W for all PoE ports
  • Working with IEEE 802.3af/at compliant PDs
  • Up to 250m data and power transmitting range under Extend Mode
  • Priority mode for ports 1–4 to guarantees the quality of sensitive applications like video monitor
  • Isolation Mode allows one-click client traffic separation for higher security and performance
  • PoE Auto Recovery guarantees stable operation of PoE devices by automatically rebooting the dropped or unresponsive PD devices
  • Plug and Play. No configuration or central management required.
Additionally, the DS1018GMP incorporates advanced features like Quality of Service (QoS) to prioritize traffic for sensitive applications, ensuring smooth performance for voice and video data. The switch also includes intelligent power management to prevent overloads by reallocating power based on priority needs. With a durable metal casing, the switch operates reliably within a wide temperature range (0–50 °C). It also offers isolation modes for enhanced security and PoE auto-recovery to automatically reset unresponsive powered devices. These characteristics make the DS1018GMP a robust solution for modern network demands Tp-Link DS1018GMP Datasheet

Need help choosing?

Click to ask a question - same day response (~2 hours during business hours)

Free shipping Enjoy free shipping when your order exceeds $100. Fast dispatch Orders are dispatched within the next business day. Best local support in Aus We back all products with manufacturer warranty support. Official Australian stock Genuine products with local warranty support.

Product Overview

The Omada 18-Port Gigabit Unmanaged Rackmount Switch (DS1018GMP) from TP-Link is designed to facilitate seamless networking with its 18 ports, including 16 Gigabit PoE+ ports and 2 combo Gigabit SFP slots. It supports a high PoE power budget, allowing each PoE port to deliver up to 30W, with a total power budget of 250W. This makes it ideal for various applications, particularly in environments needing reliable power and data transmission for devices such as IP cameras, access points, and IP phones. The switch operates with IEEE 802.3af/at compliant powered devices, ensuring wide compatibility and efficiency​. In addition to its robust functionality, the DS1018GMP features intelligent power management to prevent overload, automatically prioritizing power to critical devices. The switch includes an extend mode, allowing for data and power transmission up to 250 meters, though at reduced speeds. Its isolation mode enhances security by enabling traffic separation among clients. Installation is straightforward thanks to its plug-and-play design, requiring no additional configuration. The durable metal casing and effective heat dissipation ensure it operates reliably within a wide temperature range of 0 to 50°C​. Power over Ethernet, Flexible Network Deployment Compliant with the IEEE 802.3af/at PoE standards, the switch supports a total PoE power budget of 250 W with 30 W max per PoE+ port. When total power consumption exceeds 250 W, the intelligent power management will cut the lower priority ports power to protect devices from damage. Up to 250m Transmissions With extend mode, the PoE transmission distance reaches up to 250m—perfect for IP Camera deployment in large areas. One-click Port Priority Priority mode guarantees the quality of sensitive applications like video and voice in critical business areas by prioritizing the data of ports. Traffic Separation for Security Isolation Mode easily divides traffic for ports to avoid snooping/tampering and isolates broadcast storm for higher security. PoE Auto Recovery Recovery mode helps automatically detect and reboot PD devices, such as cameras and APs, when they fall offline or go unresponsive—all without needing manual monitoring and restarts. Specifications
HARDWARE FEATURES
Standards and Protocols IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3z, IEEE 802.1p
Interface • 16× 10/100/1000 Mbps PoE+ RJ45 ports • 2× Combo Gigabit SFP slots
Network Media • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) • 100BASE-TX: UTP category 5, 5e cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) • 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) • 1000BASE-X MMF, SMF
Fan Quantity 2
Physical Security Lock Yes
Power Supply 100–240 VAC, 50/60 Hz
PoE+ Ports(RJ45) • Standard: 802.3at/802.3af compliant • PoE Ports: Ports 1–16 • PoE Power Budget: 250 W
Dimensions ( W x D x H ) 17.3 × 7.1 × 1.73 in (440 × 180 × 44 mm)
Mounting Rack Mountable
Max Power Consumption • 19 W (220/50 Hz. no PD connected) • 293.34 W (220/50 Hz. with 250 W PD connected)
Max Heat Dissipation • 64.79 BTU/h (no PD connected) • 1000.29 BTU/h (with 250 W PD connected)
PERFORMANCE
Switching Capacity 36 Gbps
Packet Forwarding Rate 26.78 Mbps
MAC Address Table 8K
Packet Buffer Memory 4.1 Mbit
Advanced Functions • Compatible With IEEE 802.3af/at Compliant PDs • Extend Mode: Ports 1–4 • Priority Mode: Ports 1–4 • Isolation Mode: Ports 1-8/9-16 • PoE Auto Recovery: Ports 1-16 • Mac Address Auto-Learning and Auto-Aging • 802.1p/DSCP QoS • IEEE802.3x Flow Control
Jumbo Frame 10 KB
OTHERS
Certification CE, FCC, RoHS
Package Contents • DS1018GMP • Installation Guide • Power Cord • Rackmount Kit • Rubber Feet
Environment • Operating Temperature: 0–50 °C (32–122 °F) • Storage Temperature: -40–70 °C (-40–158 °F) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing
