| Camera | ||
|---|---|---|
| Image Sensor: | 1/3" Progressive Scan CMOS | |
| Effective Pixels: | 1280(H)x960(V) | |
| Signal System: | PAL/NTSC | |
| Minimum Illumination: | Color : 0.3 lux (F1.6,1/30 sec, 50 IRE, AGC On)B/W : 0.02 lux (F1.6,1/30 sec, 50 IRE, AGC On)Color : 0.02 lux (F1.6, 1/1 sec, 50 IRE, AGC On)B/W : 0.002 lux (F1.6, 1/1 sec, 50 IRE, AGC On) | |
| White Balance: | Auto/Manual/ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp | |
| AGC: | Auto/Manual | |
| S/N Ratio: | ≥ 55dB | |
| BLC: | ON/OFF | |
| HLC: | Support | |
| Smart defog: | Support | |
| WDR: | Support | |
| Shutter Time: | 50Hz: 1-1/30,000s60Hz: 1-1/30,000s | |
| Day& Night: | ICR | |
| Digital Zoom: | 16X | |
| Privacy Masking: | 24 privacy masks programmable; optional multiple colors and mosaics | |
| Auto Focus: | Auto / Semi-automatic / Manual | |
| Lens | ||
|---|---|---|
| Focal Length: | 4.3-129mm, 30x | |
| Zoom Speed: | Approx.3s(Optical Wide-Tele) | |
| Angle of View: | 57.4 ~ 2.8 degree (Wide-Tele) | |
| Minimum Working Distance: | 10-1500mm(Wide-Tele) | |
| Aperture Range: | F1.6-F5.0 | |
| Pan & Tilt | ||
|---|---|---|
| Pan Range: | 360°endless | |
| Pan Speed: | Pan Manual Speed: 0.1° -300°/s,Pan Preset Speed: 540°/s | |
| Tilt Range: | -5°~90° (Auto Flip ) | |
| Tilt Speed: | Tilt Manual Speed: 0.1°-240°/s,Tilt Preset Speed: 400°/s | |
| Proportional Zoom: | Rotation speed can be adjusted automatically according to zoom multiples | |
| Number of Preset: | 300 | |
| Patrol: | 8 patrols, up to 32 presets per patrol | |
| Pattern: | 4 patterns, with the recording time not less than 10 minutes per pattern | |
| Power loss recovery: | Support | |
| Park Action: | Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan | |
| PTZ Position Display: | ON/OFF | |
| Freeze Frame: | Support | |
| Smart-tracking: | Manual/ Panorama/ Intrusion trigger/ Line crossing trigger / Region entrance trigger / Region exiting trigger | |
| Alarm | ||
|---|---|---|
| Alarm Input: | 7 Inputs | |
| Alarm Output: | 2 | |
| Alarm Actions: | Preset, patrol, pattern, SD/SDHC card recording, relay output, notifi cation on client | |
| Input & Output | ||
|---|---|---|
| Monitor Output: | 1.0Vp-p / 75Ω, NTSC (or PAL) composite, BNC | |
| Audio Input: | Audio input (LINE input), 2-2.4Vp-p; output impedance: 1KΩ, ±10% | |
| Audio Output: | Line level, impendance: 600Ω | |
| Network | ||
|---|---|---|
| Ethernet: | 10Base -T, /100Base-TX, RJ45 Connector | |
| Max.Image Resolution: | 1280×960 | |
| Main Stream: | 50Hz:25fps(1280×960), 25fps (1280×720)60Hz:30fps(1280×960), 30fps (1280×720) | |
| Sub Stream: | 50Hz: 25fps(704×576), 25fps (352×288), 25fps (176×144)60Hz: 30fps(704×480), 30fps (352×240), 30fps (176×120) | |
| Third Stream: | 50Hz:25fps(1280×960), 25fps (1280×720), 25fps(704×576), 25fps (352×288), 25fps (176×144)60Hz:30fps(1280×960), 30fps (1280×720), 30fps(704×480), 30fps (352×240), 30fps (176×120) | |
| Image Compression: | H.264/MJPEG/MPEG4, H.264 encoding with Baseline/Main/High profile | |
| ROI encoding: | Support 24 areas with adjustable levels | |
| Audio Compression: | G.711ulaw/G.711alaw/G.726/MP2L2/G.722 | |
| Protocols: | IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE | |
| No. of Simultaneous Users: | Up to 20 users | |
| Three-Stream: | Support | |
| Mini SD Card: | Support up to 128GB Micro SD/SDHC/SDXC card. Support Edge recording | |
| User/Host Level: | Up to 32 users,3 Levels: Administrator, Operator and User | |
| Security Measures: | User authentication (ID and PW),Host authentication (MAC address)IP address filtering | |
| Client GUI | ||
|---|---|---|
| Camera Control: | Pan/Tilt, Zoom, Focus, Click centering, Zoom by mouse dragging, Iris, preset calling and programming, auto mode | |
| Date & Time Display: | Time: Week: Date, 6 formats on the Client | |
| Client: | Support iVMS-4200 | |
| Web Browser: | IE 7+, Chrome 18 +, Firefox 5.0 +, Safari 5.02 +, support multi-language | |
| General | ||
|---|---|---|
| RS-485 Protocols: | HIKVISION, Pelco-P, Pelco-D, self-adaptive | |
| Menu Language: | English / Chinese | |
| Power Supply: | 24 VAC & Hi-PoE | |
| Power Consumption: | 24VAC：Max. 60WHigh-PoE：Max. 40W | |
| Working Temperature/Humidity: | 24 VAC: -40 ℃-65℃(-40℉-149℉)(outdoor dome)Hi-PoE: -30 ℃-65℃(-22℉-149℉)(outdoor dome) | |
| Protection Level: | IP66 standard (outdoor dome)TVS 4,000V lightning protection, surge protection and voltage transient protection | |
| Mounting: | Various mounting modes optional | |
| Dimensions: | Φ220×325.5mm (Φ8.66”×12.81”)(Outdoor)Φ183.4×243mm(Φ7.22”×9.57”)(indoor)Φ245×236mm(Φ9.65”×9.29”)(indoor celing) | |
| Weight (approx.): | 4Kg (8.82 Ibs) | |
| Mount Option: | Long-arm wall mount: DS-1602ZJ;Corner mount: DS-1602ZJ-corner; Pole Mount: DS-1602ZJ-pole; Power box mount:DS-1602ZJ-box | |
All IP cameras and recording devices (NVR’s/DVR’s) are covered by a 3 year back-to-base manufacturer warranty.
Our warranty is limited to the replacement of faulty items or parts and does not include damage due to incorrect fitting of parts or accessories, or damage due to mishandling the equipment once out of the box. All faults are sent to the manufacturer for inspection and diagnosis before a replacement is sent out.
Read more about the Terms & Conditions here – https://www.securityaustralia.com.au/terms-and-conditions/
*Just spend over $100 to activate Fast Free Shipping!
Despatch Times: Products are despatched on the same day if the order was placed before 11am on any weekday, Monday - Friday. All other orders are processed and despatched within 24 hours or next business day.
Order Confirmation: Once you place an order, you will receive a confirmation email. This indicates that your order has been received in our system and is now being processed for dispatch. If your item is back-ordered or unavailable, we will notify you via email, and if we do not receive a response, we will attempt to contact you by phone as soon as possible. We value your time and strive to be prompt. If your item(s) are available for immediate shipment (within 2 days), we will process the charges and prepare the order for shipping.
Shipping Times: General shipping times for StarTrack, TNT and Allied couriers are between 1-3 working days from despatch. Longer delivery times may be caused by your package being held at your local courier depot that is beyond our control. Please contact us or the local post depot for confirmation.
Tracking Numbers: all tracking numbers will be emailed to you by our warehouse processing team within the day, after your order is despatched to our local courier.
Hikvision HIK-2DF5276-AEL 1.3MP Outdoor PTZ Camera, DWDR, 30x Zoom, Smart Tracking, IP66, HiPoE
Download Specification Sheet for HIK-2DF5276-AEL Download User Manual for HIK-2DF5276-AEL Recording at 1.3 MP with H.264 compression, Hikvision's HIK-2DF5276-AEL outdoor PTZ dome camera features a 360 degree endless pan range and a -5 to 90 degree tilt range. With a variety of additional features such as 3D digital noise reduction, a vandal-proof housing and an IP66 rating coupled with a 30x optical zoom day/night lens, this versatile weatherproof PTZ offers more detail over expansive areas.
