Hikvision DS-K7M102-M M1 Contactless Smart Card with 13.56MHz Frequency, PVC & AB Glue Build, Compact Access Control Design
- Sku: DS-K7M102-M
- Vendor: SecurityAustralia
When a reliable, contactless credential is the requirement, the DS-K7M102-M delivers a compact M1 smart card operating at 13.56MHz, suited to commercial and residential access control installations using compatible Hikvision readers. Built from durable PVC with AB glue construction, it offers a straightforward credential solution for sites already running Mifare-compatible access systems.
Why This Model
- 13.56MHz M1 technology: Operates on the widely adopted Mifare frequency, making it compatible with a broad range of Hikvision and Mifare-standard access control readers already in the field.
- PVC and AB glue construction: The layered PVC body with AB glue bonding resists delamination and everyday wear, keeping the card functional through repeated daily use.
- Standard card form factor: Credit card sizing means it slots into wallets and lanyards without any additional holder, reducing friction for end users in busy commercial environments.
Free shipping - Enjoy free shipping when your order exceeds $100!
All orders are despatched within the next business day!
Best local support in Aus! We back all products with a 3 year manufacturer warranty.
Not sure if this suits your site?
Ask our team before ordering. We can help confirm lens choice, recorder compatibility, mounting accessories and project quantities.
Product Overview
Model: DS-K7M102-M
Who This Is For
When credential compatibility and card build quality are the priority, the Hikvision DS-K7M102-M is the card most installers reach for when commissioning Hikvision access control systems. Designed for facilities requiring contactless entry - offices, commercial buildings, schools, and strata complexes - this M1 smart card operates on the widely supported 13.56MHz frequency, making it compatible with a broad range of Hikvision card readers. The PVC and AB glue construction gives it the durability expected from a daily-carry credential that will be handled, pocketed, and tapped hundreds of times over its service life. Facilities managers standardising credentials across multiple entry points, and integrators rolling out larger Hikvision access control deployments, will find the DS-K7M102-M a straightforward, consistent choice for bulk credential issuance where card integrity and reader compatibility both need to be reliable from day one.
What This Card Actually Does
13.56MHz Contactless Operation
The card communicates with compatible readers at 13.56MHz, the standard frequency used across most modern Hikvision access readers. A brief tap or present is all that is needed - no physical contact with the reader required, which reduces wear on both the card and the reader surface over time.
M1 (MIFARE Classic) Technology
Built on the MIFARE Classic 1K standard, the DS-K7M102-M carries a unique card ID that the access controller reads and authenticates against its enrolled credential list. This is the credential format most Hikvision card readers are configured to accept out of the box, simplifying deployment without additional reader configuration.
PVC and AB Glue Construction
The card body combines PVC with AB glue lamination, giving it resistance to delamination under repeated daily handling. Unlike cheaper single-layer cards that can crack or peel at the edges, this construction keeps the card's internal antenna and chip intact across its expected service life.
Standard ISO Card Format
The DS-K7M102-M is built to standard ISO credit-card dimensions, meaning it fits in any card holder, lanyard sleeve, or wallet slot without modification. This matters in multi-user environments where staff are expected to carry credentials alongside other ID cards without complaints about incompatible sizing.
Scalable Credential Issuance
Because every DS-K7M102-M card carries a unique ID, adding new users to an existing Hikvision access system requires only enrolling the new card in the controller software - no hardware changes needed. This makes it practical to scale credential issuance as a building's occupancy grows over time.
Who Buys This Model
- Access Control Installers: Integrators commissioning Hikvision card reader systems who need a confirmed-compatible M1 credential to issue to end users at handover.
- Facilities Managers: Building managers running Hikvision access control across multiple entry points who need to add or replace individual user credentials without changing existing reader configuration.
- Strata and Property Managers: Residential and commercial strata sites where tenants cycle through and replacement cards need to match the existing 13.56MHz reader infrastructure already installed.
- IT and Security Administrators: Organisations managing Hikvision access control centrally who bulk-order credentials to keep a stock of unassigned cards ready for new staff onboarding.
Honest Assessment
The DS-K7M102-M does exactly what a quality access credential should do: present a consistent, unique ID to compatible readers every time, hold together through daily handling, and fit the existing card infrastructure without complication. The 13.56MHz M1 format is well-matched to the majority of Hikvision card readers, and the PVC-plus-AB glue construction is a meaningful step above entry-level card stock that delaminates within months of regular use. Available through Security Australia, these cards suit deployments where credential reliability and reader compatibility need to be predictable. What this card will not do is replace the need for a PIN or biometric in high-security applications - if your site requires two-factor authentication, you will need a reader that supports card-plus-PIN or card-plus-fingerprint rather than card alone. It is also not suitable for installations using older 125kHz EM or HID Prox readers, which require a different credential format entirely.
Before You Buy
Compatibility Check: Confirm your installed Hikvision card readers are configured for 13.56MHz M1 (MIFARE Classic) before ordering. Some Hikvision readers support multiple card formats but may need to be set to M1 mode in the controller software. Readers running in 125kHz EM mode will not detect the DS-K7M102-M at all - check the reader model and its configured card type before bulk ordering credentials.
Enrolment Process: Each card must be individually enrolled into the Hikvision access controller or management platform before it will grant access. Budget enrolment time into your commissioning schedule, particularly for large-scale rollouts. If you are using Hik-Connect or iVMS-4200 for credential management, have the enrolment workflow tested on a single card before issuing in bulk to catch any configuration issues early.
Quick Fit Check
- Good match if: Your site runs Hikvision card readers configured for 13.56MHz M1 credentials and you need a durable, standard-format card to issue to new or replacement users.
- Good match if: You are managing a multi-user facility where credentials need to be added or revoked individually without disrupting the rest of the access system - each card's unique ID enables this directly in the controller software.
- You may need a different model if: Your site requires key fob-format credentials rather than card format, or if your readers operate on 125kHz - both cases require a different credential type from the Hikvision access control range.
Key Features & Technical Specifications
Real-World Scenarios
How It Compares
- Choose this if: Your site already runs Hikvision card readers configured for 13.56MHz M1 credentials and you need a durable, consistent card-format credential for staff or tenant issuance.
- You may need a different model if: Your users prefer a key fob over a card - a fob-format M1 credential from the Hikvision access control range will offer the same reader compatibility in a more compact carry format.
- Pairs well with: Hikvision 13.56MHz card readers, Hikvision access controllers, and Hikvision video intercom panels that support card-based entry.
Common Questions
-
Will this card work with my existing Hikvision card reader?
It will work if your Hikvision reader is configured for 13.56MHz M1 (MIFARE Classic) card format. Many Hikvision readers support multiple card standards, but the active card type must match the credential being presented. Check your reader's configuration in the access controller software before issuing cards. Readers set to 125kHz EM mode will not read the DS-K7M102-M. -
Does this card work with non-Hikvision access control readers?
Yes, it can - but with conditions. The DS-K7M102-M uses the MIFARE Classic 1K standard at 13.56MHz, which is a widely used format supported by many third-party readers. However, compatibility depends on how the third-party reader is configured and whether it supports M1 card reading. For guaranteed compatibility, it is best used within a Hikvision access control system. -
How do I add the DS-K7M102-M card to an existing Hikvision system?
Each card is enrolled through the Hikvision access controller's management interface - either directly on the controller, through iVMS-4200, or via Hik-Connect, depending on your setup. You present or scan the card to capture its unique ID, assign it to a user profile, and then set the door access permissions for that user. The card is not pre-programmed to any specific system and works only after this enrolment process is completed. -
Is the card durable enough for daily use?
Yes. The DS-K7M102-M uses PVC construction with AB glue lamination, which keeps the card layers bonded under repeated daily handling, wallet carry, and tap-to-read use. It is significantly more resistant to edge cracking and surface delamination than basic single-layer card stock. For environments with particularly rough handling - such as construction sites - a key fob credential may offer greater physical resilience. -
Can a lost or stolen DS-K7M102-M card be deactivated?
Yes. Because each card carries a unique ID enrolled to a specific user in the Hikvision access controller, a lost card can be revoked from the controller software without affecting any other enrolled credential. The revoked card will be denied access at all readers connected to that controller immediately once the change is saved, with no need to replace hardware or re-issue other users' cards. -
Does this card support any data storage beyond the access ID?
The MIFARE Classic 1K chip in the DS-K7M102-M does include onboard memory sectors beyond the card ID, which some advanced Hikvision systems may utilise for extended credential data. However, for most standard Hikvision access control deployments, the card functions as a unique identifier only. Refer to your specific Hikvision access controller documentation or contact Security Australia if your application requires extended card data functionality.
