4-ch , H.264/H.265, 2 x HDD/SSD Mobile NVR
The AE-MN5043(RJ45) is equipped with pluggable 4G and Wi-Fi modules for versatile data transmission and built-in GPS for precise vehicle positioning, logging location information alongside video data. The device includes specialized aviation connectors for stable signal transmission, and the rugged aluminum chassis ensures durability in harsh environments. It offers advanced protection features such as shutdown delay, power-off protection, and a built-in super-capacitor to prevent damage during power outages.
Key Features
Code/SKU: AE-MN5043(RJ45)
Quick Specs:
| Video/Audio Input | |
|---|---|
| Two-way Audio | 4-ch connected via PoE interfaces and 4-ch extendable via PoE switch. |
| IP Camera | 1, integrated in EXT.DEV interface |
| Video/Audio Output | |
| Audio Output | 1, integrated in EXT.DEV interface |
| Video Output | Main output: 1, integrated in EXT.DEV interface. VGA: 1 |
| Encoding/Decoding Parameters | |
| Video Compression | H.265/H.264 |
| Audio Compression | G.711a/G.711u/G.722.1/G.726 |
| Audio Bit Rate | 16 Kbps |
| Stream Type | Video, video & audio |
| Dual Stream | Supported |
| Frame Rate | PAL: 1 to 25 fps; NTSC: 1 to 30 fps |
| Encoding Resolution | Main stream: 1080P/720P/WD1/4CIF Sub-stream: 720P/WD1/4CIF/2CIF/CIF |
| Wireless Network | |
| Wi-Fi | WI58 model: 2 × 5.8 G Wi-Fi SMA antenna (Optional. 802.11B/G/N and 802.11AC are selectable. 1 antenna is needed for 802.11B/G/N module. 2 antennas are needed for 802.11AC module.) |
| 3G/4G Dialing | 1 × 4G card slot, 1 × FAKRA antenna |
| Storage | |
| SD Card Storage | 1 × SD card, up to 256 GB (not for baseline. Note the SD card capacity when ordering) |
| HDD/SDD | 2 × 2.5 inch SATA HDD/SSD, up to 2 TB for HDD, up to 4 TB for SSD |
| Auxiliary Interface | |
| Network Interface | Front panel: 1 × 10M/100M RJ45 Rear panel: 1 × 10M/100M 6-pin aviation connector Note: The front and rear network ports are at different network segments and the 6-pin aviation network cable female head to RJ45 is optional. |
| Alarm Input | 4 high/low level signal inputs, 1 pulse signal input, 1 button input |
| Alarm Output | 2 relay signal outputs |
| Sensor-in | 4 high/low level signal inputs |
| Serial Port | 1 × RS-232 (harness is optional), 1 × RS-422 (integrated in EXT.DEV interface) |
| Positioning | |
| GNSS (Global Navigation Satellite System) | GPS (Global Positioning System) & GLONASS (Global Navigation Satellite System), 1 × FAKRA antenna |
| G-Sensor | Built-in |
| General | |
| Power Supply | +9 to +32 VDC |
| Product Dimension | 206 mm × 225.4 mm × 60.1 mm (8.1" × 8.87" × 2.37") |
| Power Consumption | Standby: ≤ 0.5 W Full load: ≤ 45 W Note: Without peripheral and storage media ≤ 20 W |
| Operating Temperature | -20°C to +60°C (-4°F to +140°F) |
| Operating Humidity | 10% to 95% (non-condensing) |
| Operation Method | Mouse, IR remote control, Web control, and touchscreen |
| Certification | |
| CE/FCC/Emark/EN50155/CB/EN45545/ROHS 2.0/ISO-7637-2 | |
| Weight (Without Storage Media) | |
| Weight | 1.66 kg (3.67 lb.) |
| Approval | |
| EMC | FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 50498: 2010); CE-EMC (EN 55032: 2015+A1:2020, EN 50130-4: 2011+A1:2014; EN IEC 61000-3-2: 2019+A1:2021, EN 61000-3-3: 2013+A1:2019+A2:2021) |
| Safety | CB (IEC 62368-1:2018); CE-LVD (EN IEC 62368-1:2020 + A11:2020 ) |
| Environment | CE-RoHS (2011/65/EU and amendment 2015/863/EU) |
| Automotive and Railway | EN50155(EN 50155:2021 clause 13, EN 50121-3-2:2016+A1:2019, EN45545-2:2020, EN50153:2014+A1:2017+A2:2020, BS EN ISO:13732-1:2008, ISO 13732-1:2006; EN61373:2010); EN45545 (EN 45545-2:2020 hl3); E-MARK (ECE R10) |
All IP cameras and recording devices (NVR’s/DVR’s) are covered by a 3 year back-to-base manufacturer warranty.
Our warranty is limited to the replacement of faulty items or parts and does not include damage due to incorrect fitting of parts or accessories, or damage due to mishandling the equipment once out of the box. All faults are sent to the manufacturer for inspection and diagnosis before a replacement is sent out.
Read more about the Terms & Conditions here – https://www.securityaustralia.com.au/terms-and-conditions/
*Just spend over $100 to activate Fast Free Shipping!
Despatch Times: Products are despatched on the same day if the order was placed before 11am on any weekday, Monday - Friday. All other orders are processed and despatched within 24 hours or next business day.
Order Confirmation: Once you place an order, you will receive a confirmation email. This indicates that your order has been received in our system and is now being processed for dispatch. If your item is back-ordered or unavailable, we will notify you via email, and if we do not receive a response, we will attempt to contact you by phone as soon as possible. We value your time and strive to be prompt. If your item(s) are available for immediate shipment (within 2 days), we will process the charges and prepare the order for shipping.
Shipping Times: General shipping times for StarTrack, TNT and Allied couriers are between 1-3 working days from despatch. Longer delivery times may be caused by your package being held at your local courier depot that is beyond our control. Please contact us or the local post depot for confirmation.
Tracking Numbers: all tracking numbers will be emailed to you by our warehouse processing team within the day, after your order is despatched to our local courier.
Hikvision AE-MN5043(RJ45) 4-ch Mobile NVR 1TB Installed w/ Wifi 4G
The Hikvision AE-MN5043(RJ45) is a robust 4-channel mobile network video recorder (NVR) designed for onboard security solutions, particularly in vehicles. It supports both H.264 and H.265 video compression formats, ensuring efficient data storage and transmission. This model is compatible with up to 4 IP cameras connected via PoE interfaces and can handle up to 5MP resolution. The unit supports two HDDs or SSDs, offering flexible storage options and allowing for a total capacity of up to 2TB. For data security, the AE-MN5043 features a user-friendly graphical interface, making it easy to operate and configure.
It is equipped with pluggable 4G and Wi-Fi modules for versatile data transmission and built-in GPS for precise vehicle positioning, logging location information alongside video data. The device includes specialized aviation connectors for stable signal transmission, and the rugged aluminum chassis ensures durability in harsh environments. It offers advanced protection features such as shutdown delay, power-off protection, and a built-in super-capacitor to prevent damage during power outages. The NVR is highly adaptable, with a wide-range power input from +9 VDC to +36 VDC, and it supports web browser access for remote monitoring. Additionally, the software-based firewall ensures enhanced cybersecurity for your mobile surveillance setup.
Features
| Encoding/Decoding Parameters | |
|---|---|
| Video Compression | H.265/H.264 |
| Audio Compression | G.711a/G.711u/G.722.1/G.726 |
| Audio Bit Rate | 16 Kbps |
| Stream Type | Video, video & audio |
| Dual Stream | Supported |
| Frame Rate | PAL: 1 to 25 fps; NTSC: 1 to 30 fps |
| Encoding Resolution | Main stream: 1080P/720P/WD1/4CIF Sub-stream: 720P/WD1/4CIF/2CIF/CIF |
| Wireless Network | |
| Wi-Fi | WI58 model: 2 × 5.8 G Wi-Fi SMA antenna (Optional. 802.11B/G/N and 802.11AC are selectable. 1 antenna is needed for 802.11B/G/N module. 2 antennas are needed for 802.11AC module.) |
| 3G/4G Dialing | 1 × 4G card slot, 1 × FAKRA antenna |
| Storage | |
| SD Card Storage | 1 × SD card, up to 256 GB (not for baseline. Note the SD card capacity when ordering) |
| HDD/SDD | 2 × 2.5 inch SATA HDD/SSD, up to 2 TB for HDD, up to 4 TB for SSD |
