  • Sku: DS-2CD2386G2-I
  • Vendor: SecurityAustralia

Hikvision Acusense DS-2CD2386G2-I IP Camera 8MP 4K Turret Network Camera (no mic)

$354.00 AUD
 per
In stock!
Spend $100.00 to FREE SHIPPING

Empowered by deep learning algorithms, Hikvision AcuSense technology brings human or vehicle target classification alarms to front and back-end devices. The system can greatly reduce false alarms generated by targets other than humans or vehicles, vastly improving alarm efficiency and effectiveness.


Code/SKU: DS-2CD2386G2-I (no mic)
Quick Specs: H.265+, IR 30m, IP67
Lens Options:
  • 2.8mm: Horizontal FOV: 102°, Vertical FOV: 54°, Diagonal FOV: 121°
  • 4mm: Horizontal FOV: 87°, Vertical FOV: 44°, Diagonal FOV: 101°
  • 6mm: Horizontal FOV: 51°, Vertical FOV: 29°, Diagonal FOV: 58°

Key Features:

  • Image Sensor: 8MP 1/1.8" Progressive Scan CMOS
  • Resolution: 3840 × 2160 @20 fps
  • IR Distance: 30m
  • Lens: Fixed lens options: 2.8mm, 4mm, 6mm
  • Video Compression: H.265+/H.265/H.264+/H.264
  • Smart Features: AcuSense for human/vehicle classification, intrusion detection, line crossing detection
  • Protection: IP67 weatherproof rating

This camera offers exceptional surveillance capabilities with advanced motion detection and a 30m infrared range. Suitable for both residential and commercial environments, it provides reliable and accurate monitoring.

Specifications

Camera Specification
Camera
Image Sensor 1/1.8" Progressive Scan CMOS
Max. Resolution 3840 × 2160
Min. Illumination Color: 0.003 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
Shutter Time 1/3 s to 1/100,000 s
Day & Night IR cut filter
Angle Adjustment Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
Lens
Lens Type Fixed focal lens, 2.8, 4, and 6 mm optional
Focal Length & FOV 2.8 mm, horizontal FOV 111°, vertical FOV 59°, diagonal FOV 131°
4 mm, horizontal FOV 87°, vertical FOV 47°, diagonal FOV 102°
6 mm, horizontal FOV 51°, vertical FOV 28°, diagonal FOV 60°
Lens Mount M12
Iris Type Fixed
Aperture F1.6
DORI
DORI 2.8 mm: D: 89.2 m, O: 35.4 m, R: 17.8 m, I: 8.9 m
4 mm: D: 99.4 m, O: 39.4 m, R: 19.9 m, I: 9.9 m
6 mm: D: 140.0 m, O: 55.6 m, R: 28.0 m, I: 14.0 m
Illuminator
Supplement Light Type IR
Supplement Light Range Up to 30 m
Smart Supplement Light Yes
IR Wavelength 850 nm
Video
Main Stream 50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 24 fps (3840 × 2160)
30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream 50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360)
Third Stream 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
Video Compression Main stream: H.265/H.264/H.264+/H.265+
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
Video Bit Rate 32 Kbps to 16 Mbps
H.264 Type Baseline Profile/Main Profile/High Profile
H.265 Type Main Profile
Bit Rate Control CBR/VBR
Scalable Video Coding (SVC) H.264 and H.265 encoding
Region Of Interest (ROI) 1 fixed region for main stream and sub-stream
Target Cropping Yes
Audio
Audio Type -U: mono sound
Audio Compression -U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC
Audio Bit Rate -U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC)
Audio Sampling Rate -U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Environment Noise Filtering -U: Yes
Network
Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP
Simultaneous Live View Up to 6 channels
API Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK
User/Host Up to 32 users. 3 user levels: administrator, operator and user
Security Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
Network Storage MicroSD/SDHC/SDXC card (256 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR). Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Client iVMS-4200, Hik-Connect, Hik-Central
Web Browser Plug-in required live view: IE 10+
Plug-in free live view: Chrome 57.0+, Firefox 52.0+
Local service: Chrome 57.0+, Firefox 52.0+
Image Parameters Switch Yes
Image Settings Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
Day/Night Switch Day, Night, Auto, Schedule
Wide Dynamic Range (WDR) 120 dB
SNR ≥ 52 dB
Image Enhancement BLC, HLC, 3D DNR
Privacy Mask 4 regions of privacy mask
Interface
Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage Built-in micro SD/SDHC/SDXC slot, up to 256 GB
Built-In Microphone -U: Yes
Reset Key Yes
Event
Basic Event Motion detection (human and vehicle targets classification), video tampering alarm, exception
Smart Event Scene change detection
Linkage Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture
Deep Learning Function Face Capture
General
Power 12 VDC ± 25%, 0.48 A, max. 5.8 W, Ø5.5 mm coaxial power plug, reverse polarity protection
PoE: 802.3af, Class 3, 36 V to 57 V, 0.19 A to 0.12 A, max. 6.8 W
Dimension Ø138.3 mm × 126.3 mm (Ø5.4" × 5")
Material Metal
Package Dimension 170 mm × 170 mm × 150 mm (6.9" × 6.9" × 5.9")
Weight Approx. 740 g (1.6 lb.)
With Package Weight Approx. 1020 g (2.2 lb.)
Storage Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup And Operating Conditions -30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing)
Language 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General Function Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter
Approval
EMC FCC (47 CFR Part 15, Subpart B)
CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014)
RCM (AS/NZS CISPR 32: 2015)
KC (KN 32: 2015, KN 35: 2015)
Safety UL (UL 60950-1)
CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013)
CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013)
Environment CE-RoHS (2011/65/EU)
WEEE (2012/19/EU)
Reach (Regulation (EC) No 1907/2006)
Protection IP67 (IEC 60529-2013)

Documentation

3 Years Manufacturer Warranty

All IP cameras and recording devices (NVR’s/DVR’s) are covered by a 3 year back-to-base manufacturer warranty.

Our warranty is limited to the replacement of faulty items or parts and does not include damage due to incorrect fitting of parts or accessories, or damage due to mishandling the equipment once out of the box. All faults are sent to the manufacturer for inspection and diagnosis before a replacement is sent out.

Read more about the Terms & Conditions here – https://www.securityaustralia.com.au/terms-and-conditions/

Trusted Brand Partner & Security Equipment Wholesaler

Authorised Brand Partner with Responsive & Fast Aussie Sales Support Team ★★★★★
Best After-Sales Support and Troubleshooting Team with Years of Installation Experience.

Free Delivery* & Despatch Time

*Just spend over $100 to activate Fast Free Shipping!

Despatch Times: Products are despatched on the same day if the order was placed before 11am on any weekday, Monday - Friday. All other orders are processed and despatched within 24 hours or next business day.

Order Confirmation: Once you place an order, you will receive a confirmation email. This indicates that your order has been received in our system and is now being processed for dispatch. If your item is back-ordered or unavailable, we will notify you via email, and if we do not receive a response, we will attempt to contact you by phone as soon as possible. We value your time and strive to be prompt. If your item(s) are available for immediate shipment (within 2 days), we will process the charges and prepare the order for shipping.

Shipping Times: General shipping times for StarTrack, TNT and Allied couriers are between 1-3 working days from despatch. Longer delivery times may be caused by your package being held at your local courier depot that is beyond our control. Please contact us or the local post depot for confirmation.

Tracking Numbers: all tracking numbers will be emailed to you by our warehouse processing team within the day, after your order is despatched to our local courier.

View full details

Hikvision Acusense DS-2CD2386G2-I IP Camera 8MP 4K Turret Network Camera (no mic)

8MP 4K AcuSense WITHOUT Strobe Light / Audible Warning / Fixed Turret Network Camera (without mic)

Enhance your security setup with the Hikvision DS-2CD2386G2-IU, an 8MP 4K AcuSense fixed turret network camera. This outdoor camera is designed to provide exceptional video quality with its 4K resolution, ensuring every detail is captured with clarity. Its advanced DarkFighter technology delivers outstanding low-light performance, making it perfect for round-the-clock surveillance. Additionally, the AcuSense technology helps reduce false alarms by accurately classifying human and vehicle targets, ensuring you are only alerted to genuine threats. With an IP67 rating, this camera is built to withstand harsh weather conditions, providing reliable performance year-round.

DarkFighter Technology: DarkFighter technology enables cameras to capture clear and detailed images in low-light conditions, making it ideal for night surveillance. This advanced technology works by utilizing a large iris and an advanced sensor to gather more light, thus enhancing image clarity and color fidelity even in near-total darkness. Whether it's a dimly lit alley or a poorly illuminated parking lot, DarkFighter ensures that you get the best possible footage.

AcuSense Technology: AcuSense technology leverages deep learning algorithms to significantly reduce false alarms by focusing on human and vehicle targets while ignoring other moving objects such as animals, rain, or foliage. This ensures that security personnel are alerted only to genuine security threats, thereby improving response times and enhancing overall security efficiency. The technology also supports quick and accurate retrieval of video footage based on human and vehicle classifications, making post-event investigation much faster and more efficient.

High Efficiency Video Coding (H.265+): H.265+ is an optimized video compression standard that reduces the bandwidth and storage requirements of video files without compromising image quality. This technology allows for longer recording times and less storage space usage, making it a cost-effective solution for long-term surveillance. By efficiently compressing the data, H.265+ also ensures smoother video streaming and playback, even over limited bandwidth connections, making remote monitoring more reliable.

Wide Dynamic Range (WDR): The 120 dB Wide Dynamic Range (WDR) technology ensures that images are clear and detailed even in challenging lighting conditions. It works by combining multiple exposures of the same scene to produce a single image that captures both the brightest and darkest areas effectively. This is particularly useful in environments where there are strong contrasts in lighting, such as entrances with both indoor and outdoor lighting or areas with direct sunlight and shadows.

Weatherproof Design: With an IP67 rating, this camera is fully protected against dust and can withstand water immersion up to 1 meter for 30 minutes. This makes it an ideal choice for outdoor surveillance in various weather conditions, including heavy rain and dust storms. The robust construction ensures long-term durability and reliable performance, providing peace of mind that your surveillance system will function effectively in harsh environments.

Key Features:

  • High-quality imaging with 4K resolution
  • Excellent low-light performance powered by DarkFighter technology
  • Clear imaging against strong backlight due to 120 dB true WDR technology
  • Efficient H.265+ compression technology
  • False alarm reduction through human and vehicle target classification based on deep learning
  • Water and dust resistant (IP67)

Technical Specifications:

  • Image Sensor: 1/1.8" Progressive Scan CMOS
  • Min. Illumination: Color: 0.003 Lux @ (F1.6, AGC ON)
  • Shutter Speed: 1/3 s to 1/100,000 s
  • Slow Shutter: Yes
  • Wide Dynamic Range: 120 dB
  • Day & Night: ICR Cut
  • Angle Adjustment: Pan: 0° to 360°, Tilt: 0° to 75°, Rotate: 0° to 360°
  • IR Illuminator:
    • IR Range: Up to 30 m
    • Wavelength: 850 nm

DORI:

2.8 mm: Detection: 84 m, Observation: 33 m, Recognition: 16 m, Identification: 8 m

4 mm: Detection: 102 m, Observation: 40 m, Recognition: 20 m, Identification: 10 m

Upgrade your security with the Hikvision DS-2CD2386G2-IU 8MP 4K AcuSense Fixed Turret Network Camera and experience unmatched clarity and efficiency in surveillance.
