  • Sku: DS-2CD2386G2-IU-MIC-NOSTROBE-BLACK
  • Vendor: SecurityAustralia

Hikvision Acusense BLACK DS-2CD2386G2-IU IP Camera 8MP 4K Turret Network Camera with Mic

$348.00 AUD
 per
In stock!
Spend $100.00 to FREE SHIPPING

Overview:

Empowered by deep learning algorithms, Hikvision AcuSense technology brings human or vehicle target classification alarms to front and back-end devices. The system can greatly reduce false alarms generated by targets other than humans or vehicles, vastly improving alarm efficiency and effectiveness.

Product Details:

HIK-2CD2386G2 / DS-2CD2386G2-IU (U = mic) BLACK

Quick Specs: H.265+, IR 30m, IP67, Built-in Mic

Lens Options:

  • 2.8mm: Horizontal FOV: 102°, Vertical FOV: 54°, Diagonal FOV: 121°
  • 4mm: Horizontal FOV: 87°, Vertical FOV: 44°, Diagonal FOV: 101°
  • 6mm: Horizontal FOV: 51°, Vertical FOV: 29°, Diagonal FOV: 58°

Key Features:

  • High Resolution Imaging: Achieve detailed imaging with 8 MP resolution.
  • Smart Hybrid Light: Utilizes advanced technology for extended range.
  • Superior Backlight Performance: Clear imaging even in strong backlight conditions, thanks to 130 dB WDR technology.
  • Efficient Compression: Utilizes H.265+ compression technology for optimized storage.
  • Advanced Classification: Focuses on deep learning for accurate human and vehicle classification.
  • Active Security Features: Includes active strobe light and audio alarm to deter intruders.
  • Real-Time Communication: Supports real-time security monitoring with built-in two-way audio.
  • Expandable Storage: Supports on-board storage up to 512 GB via SD card slot.
  • Robust Design: Water and dust resistant with an IP67 rating for durability.

This camera offers exceptional surveillance capabilities with advanced motion detection and a 30m infrared range. Suitable for both residential and commercial environments, it provides reliable and accurate monitoring.

Addons

Specifications

Camera Specifications

Camera Specifications

Camera

Image Sensor 1/1.8" Progressive Scan CMOS
Max. Resolution 3840 × 2160
Min. Illumination Color: 0.003 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
Shutter Time 1/3 s to 1/100,000 s
Day & Night IR cut filter
Angle Adjustment Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°

Lens

Lens Type Fixed focal lens, 2.8, 4, and 6 mm optional
Focal Length & FOV 2.8 mm, horizontal FOV 111°, vertical FOV 59°, diagonal FOV 131°
4 mm, horizontal FOV 87°, vertical FOV 47°, diagonal FOV 102°
6 mm, horizontal FOV 51°, vertical FOV 28°, diagonal FOV 60°
Lens Mount M12
Iris Type Fixed
Aperture F1.6

DORI

DORI 2.8 mm: D: 89.2 m, O: 35.4 m, R: 17.8 m, I: 8.9 m
4 mm: D: 99.4 m, O: 39.4 m, R: 19.9 m, I: 9.9 m
6 mm: D: 140.0 m, O: 55.6 m, R: 28.0 m, I: 14.0 m

Illuminator

Supplement Light Type IR
Supplement Light Range Up to 30 m
Smart Supplement Light Yes
IR Wavelength 850 nm

Video

Main Stream 50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 24 fps (3840 × 2160)
30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream 50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360)
Third Stream 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
*Third stream is supported under certain settings.
Video Compression Main stream: H.265/H.264/H.264+/H.265+
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
*Third stream is supported under certain settings.
Video Bit Rate 32 Kbps to 16 Mbps
H.264 Type Baseline Profile/Main Profile/High Profile
H.265 Type Main Profile
Bit Rate Control CBR/VBR
Scalable Video Coding (SVC) H.264 and H.265 encoding
Region Of Interest (ROI) 1 fixed region for main stream and sub-stream
Target Cropping Yes

Audio

Audio Type -U: mono sound
Audio Compression -U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC
Audio Bit Rate -U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC)
Audio Sampling Rate -U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Environment Noise Filtering -U: Yes

Network

Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP
Simultaneous Live View Up to 6 channels
API Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK
User/Host Up to 32 users. 3 user levels: administrator, operator and user
Security Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
Network Storage MicroSD/SDHC/SDXC card (256 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Client iVMS-4200, Hik-Connect, Hik-Central
Web Browser Plug-in required live view: IE 10+
Plug-in free live view: Chrome 57.0+, Firefox 52.0+
Local service: Chrome 57.0+, Firefox 52.0+


Image Parameters Switch Yes
Image Settings Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
Day/Night Switch Day, Night, Auto, Schedule
Wide Dynamic Range (WDR) 120 dB
SNR ≥ 52 dB
Image Enhancement BLC, HLC, 3D DNR

Interface

Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage Built-in micro SD/SDHC/SDXC slot, up to 256 GB
Built-In Microphone -U: Yes
Reset Key Yes

Event

Basic Event Motion detection (human and vehicle targets classification), video tampering alarm, exception
Smart Event Scene change detection
Linkage Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture
Deep Learning Function Face Capture

General

Power 12 VDC ± 25%, 0.48 A, max. 5.8 W, Ø5.5 mm coaxial power plug, reverse polarity protection
PoE: 802.3af, Class 3, 36 V to 57 V, 0.19 A to 0.12 A, max. 6.8 W
Dimension Ø138.3 mm × 126.3 mm (Ø5.4" × 5")
Package Dimension 170 mm × 170 mm × 150 mm (6.9" × 6.9" × 5.9")
Weight Approx. 740 g (1.6 lb.)
With Package Weight Approx. 1020 g (2.2 lb.)
Storage Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup And Operating Conditions -30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing)
Language 33 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General Function Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter

Approval

EMC FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); KC (KN 32: 2015, KN 35: 2015)
Safety UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013)
Environment CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Protection IP67 (IEC 60529-2013)

Documentation

3 Years Manufacturer Warranty

All IP cameras and recording devices (NVR’s/DVR’s) are covered by a 3 year back-to-base manufacturer warranty.

Our warranty is limited to the replacement of faulty items or parts and does not include damage due to incorrect fitting of parts or accessories, or damage due to mishandling the equipment once out of the box. All faults are sent to the manufacturer for inspection and diagnosis before a replacement is sent out.

Read more about the Terms & Conditions here – https://www.securityaustralia.com.au/terms-and-conditions/

Trusted Brand Partner & Security Equipment Wholesaler

Authorised Brand Partner with Responsive & Fast Aussie Sales Support Team ★★★★★
Best After-Sales Support and Troubleshooting Team with Years of Installation Experience.

Free Delivery* & Despatch Time

*Just spend over $100 to activate Fast Free Shipping!

Despatch Times: Products are despatched on the same day if the order was placed before 11am on any weekday, Monday - Friday. All other orders are processed and despatched within 24 hours or next business day.

Order Confirmation: Once you place an order, you will receive a confirmation email. This indicates that your order has been received in our system and is now being processed for dispatch. If your item is back-ordered or unavailable, we will notify you via email, and if we do not receive a response, we will attempt to contact you by phone as soon as possible. We value your time and strive to be prompt. If your item(s) are available for immediate shipment (within 2 days), we will process the charges and prepare the order for shipping.

Shipping Times: General shipping times for StarTrack, TNT and Allied couriers are between 1-3 working days from despatch. Longer delivery times may be caused by your package being held at your local courier depot that is beyond our control. Please contact us or the local post depot for confirmation.

Tracking Numbers: all tracking numbers will be emailed to you by our warehouse processing team within the day, after your order is despatched to our local courier.

View full details

Hikvision Acusense BLACK DS-2CD2386G2-IU IP Camera 8MP 4K Turret Network Camera with Mic

8MP 4K AcuSense Fixed Turret Network Camera (with mic) for Outdoor Use

Discover the pinnacle of outdoor surveillance with the Hikvision 8MP 4K AcuSense Fixed Turret Network Camera. This cutting-edge camera delivers ultra-high-definition 4K resolution, ensuring every detail is captured with stunning clarity. Whether day or night, its advanced powered-by-DarkFighter technology guarantees exceptional performance in low-light conditions. Equipped with AcuSense technology, it intelligently distinguishes between human and vehicle targets, minimizing false alarms and enhancing security efficiency. Built to withstand the harshest environments, its IP67 rating ensures reliable operation in any weather condition. Elevate your security with this robust and intelligent surveillance solution.


Functions

DarkFighter Technology: This technology enhances the camera's ability to capture high-quality images in low-light conditions. By utilizing a large iris and advanced image sensors, DarkFighter cameras produce clear and sharp images even in near-total darkness, making them ideal for applications requiring reliable nighttime surveillance.

AcuSense Technology: AcuSense technology leverages advanced deep learning algorithms to differentiate between human and vehicle targets and other moving objects such as animals, rain, or leaves. This significantly reduces false alarms and ensures that users are alerted only to real security threats. Additionally, AcuSense improves search efficiency by allowing users to filter video footage based on specific object classifications, making it faster and easier to locate relevant events.

Wide Dynamic Range (WDR): The 120 dB Wide Dynamic Range (WDR) technology ensures clear and detailed images in environments with varying lighting conditions. WDR works by capturing multiple frames at different exposures and combining them to create a single, balanced image. This is especially useful in areas with high contrast lighting, such as entrances or windows, where both bright and dark areas need to be visible.

High Efficiency Video Coding (H.265+): H.265+ is an advanced video compression technology that significantly reduces bandwidth and storage requirements without compromising image quality. By efficiently compressing video data, H.265+ allows for longer recording times and reduces the need for extensive storage solutions, making it a cost-effective choice for long-term video surveillance.

Built-in Microphone: The integrated microphone provides high-quality audio recording, adding an extra layer of information to your surveillance footage. This feature is particularly useful for scenarios where audio context is important, enhancing overall security monitoring and situational awareness.


Key Features

  • High-Quality Imaging: Capture sharp and clear images with 4K resolution.
  • Low-Light Performance: Powered-by-DarkFighter technology ensures exceptional visibility in low-light conditions.
  • Wide Dynamic Range: 120 dB true WDR technology delivers clear imaging even against strong backlight.
  • Compression Technology: Efficient H.265+ compression reduces storage and bandwidth requirements.
  • Intelligent Detection: Reduces false alarms through human and vehicle target classification based on deep learning.
  • Durability: Water and dust resistant with an IP67 rating, making it suitable for outdoor use.


Specifications

Feature Details
Image Sensor 1/1.8" Progressive Scan CMOS
Minimum Illumination Color: 0.003 Lux @ (F1.6, AGC ON)
Shutter Speed 1/3 s to 1/100,000 s
Slow Shutter Yes
Wide Dynamic Range 120 dB
Day & Night ICR Cut
Angle Adjustment Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
IR Range Up to 30 m
Wavelength 850 nm
