Hikvision Acusense BLACK DS-2CD2386G2-IU IP Camera 8MP 4K Turret Network Camera with Mic
Built as an 8MP AcuSense turret camera for outdoor and indoor fixed installations, the DS-2CD2386G2-IU delivers 4K resolution with deep learning-based human and vehicle detection to cut false alarms significantly. The black housing suits discreet or low-visibility mounting environments. Requires a PoE switch or 12V DC power supply - no power adapter included.
Why This Model
- AcuSense false alarm filtering: Deep learning distinguishes people and vehicles from animals, foliage, and other movement, so you only receive alerts that actually warrant attention.
- 4K 120 dB WDR imaging: The 3840 x 2160 sensor paired with true Wide Dynamic Range handles high-contrast scenes - entrances, carparks, and sun-facing walls - without blowing out highlights or losing shadow detail.
- Built-in microphone: Onboard audio capture is ready to go without additional hardware, useful for evidential recording or integration with a compatible NVR for audio-triggered events.
Accessories
Select options before adding this product to cart.
Need help choosing?
Click to ask a question - same day response (~2 hours during business hours)
Product Overview
Model: DS-2CD2386G2-IU-MIC-NOSTROBE-BLACK
Who This Is For
For installers and property owners who need 4K resolution with meaningful AI detection - not just motion triggers - the Hikvision DS-2CD2386G2-IU in black is a strong everyday outdoor turret. The black housing suits darker fascias, modern architectural finishes, and low-profile commercial installs where a white dome would stand out. With AcuSense deep learning filtering human and vehicle targets from irrelevant movement, this camera is well-suited to eaves, soffits, carports, small business exteriors, and residential perimeter points where nuisance alerts from trees, animals, or passing headlights are a known problem. The built-in microphone adds on-site audio capture without extra hardware. The 2.8mm fixed lens gives a wide 100-degree horizontal field of view, making it particularly useful at entry points, driveways, and building corners where broad coverage matters more than long-range reach.
What This Camera Actually Does
AcuSense Human and Vehicle Filtering
Deep learning algorithms classify motion as human or vehicle before triggering an alert. This cuts out false notifications from animals, blowing debris, and passing headlights - so when an alert fires, it's worth checking. Especially useful on properties with trees, wildlife, or busy adjacent roads.
8MP 4K Resolution at 25/30fps
The 1/1.8" CMOS sensor outputs 3840 x 2160 at full frame rate. In practice, this means readable number plates, recognisable faces, and usable evidence-grade footage from a single wide-angle position - without needing to step down to a narrower lens.
120dB Wide Dynamic Range
True 120dB WDR balances scenes where sunlight hits one side of a doorway and shadow sits on the other. Faces at a sun-facing entrance, or a vehicle partially in shade and partially in direct light, stay visible rather than blowing out or going black.
IR Night Vision to 30 Metres
Built-in IR illumination takes the camera to 0 Lux in monochrome mode with no external lighting. At 30 metres range, it covers a standard residential driveway, side gate, or carport with room to spare. This is a no-strobe variant - no visible light flash on detection.
Built-In Microphone
An integrated microphone enables on-site audio capture alongside video. Useful for evidential recording, audio-triggered events, or remote verbal deterrence without additional audio hardware at the camera position.
Who Buys This Model
- Residential installers on modern homes: The black housing suits Colorbond fascias, dark brick, and contemporary builds where a white dome draws attention. AcuSense keeps alert fatigue low for homeowners checking notifications on a phone.
- Small business owners covering entry points and car parks: 4K resolution at 100-degree FOV means a single camera at a shopfront or car park entrance captures usable identification detail without needing a separate narrow-lens camera alongside it.
- Property managers on multi-tenancy sites: The IP67 rating and PoE 802.3af power delivery simplify outdoor installation across strata buildings, rental properties, and unit complexes where weatherproofing and clean cable runs matter.
- Installers specifying audio capability: Sites where verbal communication from a camera position is needed - gated driveways, delivery zones, childcare exterior entry points - benefit from the confirmed built-in microphone for audio capture without additional hardware.
Honest Assessment
The DS-2CD2386G2-IU delivers genuine 4K resolution with AcuSense filtering in a compact outdoor turret - that combination is where it earns its place. The 1/1.8" sensor handles low light well for the class, the 120dB WDR is one of the stronger ratings at this price point, and the H.265+ compression means 4K streams don't punish storage budgets as hard as older codecs. The black housing and no-strobe configuration suit installs where appearance and discreet operation matter. Where it won't serve: the 2.8mm fixed lens at 30 metres IR reach means it is not suited to monitoring long corridors, large carparks, or open paddocks where a varifocal or bullet-style camera with extended IR would do a better job. It also lacks full-colour night imaging - if you need colour in zero ambient light, a TiOC or colour-always model from the Security Australia range is the direction to go. For most eave and entry-point applications, however, this camera is a solid, honest performer.
Before You Buy
Lens and Coverage Note: The 2.8mm fixed lens gives 100 degrees horizontal - ideal for wide entry coverage at 3-6 metres mounting height, but it won't suit long narrow corridors or approaches longer than 15-20 metres where you need target detail at range. If your install requires coverage beyond that, consider a 4mm or varifocal option. Confirm your mounting height before ordering - at 2.8mm, mounting too high reduces recognition zone depth significantly.
PoE and NVR Compatibility: This camera draws power over standard IEEE 802.3af PoE - it does not require PoE+. Any 802.3af-capable switch or NVR port will power it correctly. For AcuSense smart detection events (human/vehicle filtering, perimeter intrusion) to function properly end-to-end, pair with a Hikvision NVR that supports AcuSense processing - generic third-party NVRs will record the stream but may not surface smart alert categories correctly.
Quick Fit Check
- Good match if: You are mounting at a residential or small commercial entry point, driveway, or building corner where a wide 100-degree view at 4K resolution covers the area and AcuSense filtering keeps alert volume manageable.
- Good match if: The install site has dark or modern architectural finishes - the black housing blends with Colorbond, charcoal render, and timber cladding where a white dome would look out of place.
- You may need a different model if: Your priority is full-colour night imaging with no IR - a TiOC or colour-always turret with a built-in warm light will serve that requirement better than this IR-only no-strobe variant.
Key Features & Technical Specifications
Real-World Scenarios
How It Compares
- Choose this if: You need 4K resolution with AcuSense human/vehicle filtering in a black outdoor turret with built-in microphone audio capture - and your install site suits a wide fixed 2.8mm lens rather than a variable focal length.
- You may need a different model if: Your site has a long straight approach - a driveway over 25 metres, a loading dock, or a perimeter fence line - where a varifocal or bullet-style camera with extended IR reach and a narrower field of view would cover the distance more effectively.
- Pairs well with: A Hikvision AcuSense-compatible NVR with smart event processing to make full use of the human/vehicle classification and perimeter intrusion detection capabilities of this camera.
Common Questions
-
Does this camera work with a standard PoE switch, or does it need PoE+?
Standard 802.3af PoE is sufficient. The DS-2CD2386G2-IU runs on IEEE 802.3af, which is the common PoE standard found on most NVRs and managed switches. You do not need a PoE+ (802.3at) port. A single Cat5e or Cat6 cable carries both power and data up to 100 metres, which simplifies outdoor runs to eaves and fascias without needing a separate power cable. -
Will this camera reduce false alarms compared to standard motion detection?
Yes, materially. AcuSense uses deep learning to classify detected movement as human, vehicle, or other before generating an alert. Standard motion detection fires on any pixel change - a tree branch, a cat, a passing headlight. AcuSense filters those out at the camera level, meaning the alert volume drops significantly on sites with vegetation, animals, or ambient movement. The accuracy of the classification depends on scene setup and detection zone configuration, but the difference versus generic motion detection is substantial. -
What is the identification distance for this camera at 2.8mm?
The confirmed DORI identification distance is 8 metres. This is the distance at which the camera can resolve enough detail to identify a specific individual. At 17 metres it reaches recognition level (enough to distinguish one person from another), and at 35 metres it reaches observation level. For a wide 100-degree lens at 4K, these are realistic figures - mounting height and scene lighting affect real-world results. If you need identification beyond 10-12 metres, a narrower fixed lens or varifocal option would be more appropriate. -
Does this camera record in colour at night, or only in black and white?
Monochrome IR only after dark with no ambient light. The camera switches to black and white IR mode in low-light conditions, using the built-in IR illuminator to 0 Lux. It does not have a white light emitter or colour-always sensor. If your site has streetlighting or external lighting present overnight, the camera will use that ambient light to retain some colour - but in complete darkness the image will be monochrome. For full-colour night imaging with no ambient light source, a TiOC or warm-light-equipped turret is the appropriate alternative. This is the no-strobe variant, so there is no triggered visible flash on detection. -
Does this camera have a built-in speaker for two-way audio?
No. The DS-2CD2386G2-IU has a built-in microphone for audio capture but does not have a built-in speaker. This means it records audio alongside video but cannot output your voice at the camera location. For two-way audio capability, look for the Live-Guard variants (e.g. DS-2CD2386G2-ISU/SL) which include a built-in speaker. Audio also records to a compatible NVR if the NVR supports audio input channels. Available through Security Australia as the MIC-equipped variant of this model. -
How much storage does 4K footage from this camera actually use?
Considerably less than you'd expect with H.265+ encoding active. H.265+ is Hikvision's adaptive compression that adjusts bitrate based on scene activity - a static scene with low movement uses far less data than a busy intersection. As a practical guide, a single 4K H.265+ stream at moderate motion runs roughly 2-4GB per hour depending on bitrate settings. Over 24 hours on a typical residential install, a single camera sits in the range of 30-60GB per day. Pairing with an AcuSense-compatible NVR that records on smart event rather than continuous motion can reduce that further.
Downloads & Resources
No downloads available for this product.
What This Product Does
Built as an 8MP AcuSense turret camera for outdoor and indoor fixed installations, the DS-2CD2386G2-IU delivers 4K resolution with deep learning-based human and vehicle detection to cut false alarms significantly. The black housing suits discreet or low-visibility mounting environments. Requires a PoE switch or 12V DC power supply - no power adapter included.
Why This Model
- AcuSense false alarm filtering: Deep learning distinguishes people and vehicles from animals, foliage, and other movement, so you only receive alerts that actually warrant attention.
- 4K 120 dB WDR imaging: The 3840 x 2160 sensor paired with true Wide Dynamic Range handles high-contrast scenes - entrances, carparks, and sun-facing walls - without blowing out highlights or losing shadow detail.
- Built-in microphone: Onboard audio capture is ready to go without additional hardware, useful for evidential recording or integration with a compatible NVR for audio-triggered events.
Not sure if this suits your site?
Ask our team before ordering. We can help confirm lens choice, recorder compatibility, mounting accessories and project quantities.
Specifications
Specifications
Camera Specifications
Camera
| Image Sensor | 1/1.8" Progressive Scan CMOS |
|---|---|
| Max. Resolution | 3840 × 2160 |
| Min. Illumination | Color: 0.003 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
| Shutter Time | 1/3 s to 1/100,000 s |
| Day & Night | IR cut filter |
| Angle Adjustment | Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360° |
Lens
| Lens Type | Fixed focal lens, 2.8, 4, and 6 mm optional |
|---|---|
| Focal Length & FOV | 2.8 mm, horizontal FOV 111°, vertical FOV 59°, diagonal FOV 131° 4 mm, horizontal FOV 87°, vertical FOV 47°, diagonal FOV 102° 6 mm, horizontal FOV 51°, vertical FOV 28°, diagonal FOV 60° |
| Lens Mount | M12 |
| Iris Type | Fixed |
| Aperture | F1.6 |
DORI
| DORI | 2.8 mm: D: 89.2 m, O: 35.4 m, R: 17.8 m, I: 8.9 m 4 mm: D: 99.4 m, O: 39.4 m, R: 19.9 m, I: 9.9 m 6 mm: D: 140.0 m, O: 55.6 m, R: 28.0 m, I: 14.0 m |
|---|
Illuminator
| Supplement Light Type | IR |
|---|---|
| Supplement Light Range | Up to 30 m |
| Smart Supplement Light | Yes |
| IR Wavelength | 850 nm |
Video
| Main Stream | 50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 24 fps (3840 × 2160) 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) |
|---|---|
| Sub-Stream | 50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360) |
| Third Stream | 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is supported under certain settings. |
| Video Compression | Main stream: H.265/H.264/H.264+/H.265+ Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 *Third stream is supported under certain settings. |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| H.264 Type | Baseline Profile/Main Profile/High Profile |
| H.265 Type | Main Profile |
| Bit Rate Control | CBR/VBR |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
| Region Of Interest (ROI) | 1 fixed region for main stream and sub-stream |
| Target Cropping | Yes |
Audio
| Audio Type | -U: mono sound |
|---|---|
| Audio Compression | -U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC |
| Audio Bit Rate | -U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC) |
| Audio Sampling Rate | -U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Environment Noise Filtering | -U: Yes |
Network
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP |
|---|---|
| Simultaneous Live View | Up to 6 channels |
| API | Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK |
| User/Host | Up to 32 users. 3 user levels: administrator, operator and user |
| Security | Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface |
| Network Storage | MicroSD/SDHC/SDXC card (256 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR) Together with high-end Hikvision memory card, memory card encryption and health detection are supported. |
| Client | iVMS-4200, Hik-Connect, Hik-Central |
| Web Browser | Plug-in required live view: IE 10+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+ Local service: Chrome 57.0+, Firefox 52.0+ |
| Image Parameters Switch | Yes |
|---|---|
| Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
| Day/Night Switch | Day, Night, Auto, Schedule |
| Wide Dynamic Range (WDR) | 120 dB |
| SNR | ≥ 52 dB |
| Image Enhancement | BLC, HLC, 3D DNR |
Interface
| Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
|---|---|
| On-Board Storage | Built-in micro SD/SDHC/SDXC slot, up to 256 GB |
| Built-In Microphone | -U: Yes |
| Reset Key | Yes |
Event
| Basic Event | Motion detection (human and vehicle targets classification), video tampering alarm, exception |
|---|---|
| Smart Event | Scene change detection |
| Linkage | Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture |
| Deep Learning Function | Face Capture |
General
| Power | 12 VDC ± 25%, 0.48 A, max. 5.8 W, Ø5.5 mm coaxial power plug, reverse polarity protection PoE: 802.3af, Class 3, 36 V to 57 V, 0.19 A to 0.12 A, max. 6.8 W |
|---|---|
| Dimension | Ø138.3 mm × 126.3 mm (Ø5.4" × 5") |
| Package Dimension | 170 mm × 170 mm × 150 mm (6.9" × 6.9" × 5.9") |
| Weight | Approx. 740 g (1.6 lb.) |
| With Package Weight | Approx. 1020 g (2.2 lb.) |
| Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startup And Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing) |
| Language | 33 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| General Function | Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter |
Approval
| EMC | FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); KC (KN 32: 2015, KN 35: 2015) |
|---|---|
| Safety | UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013) |
| Environment | CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Protection | IP67 (IEC 60529-2013) |
Downloads
- UD21665B-E_Baseline_1-3-Series-Multilingual-Quick-Start-Guide_20210615_a08c2cf3-45e7-4d4f-80e4-9b28c5be6157.pdf
- UD21665B-E_Baseline_1-3-Series-Multilingual-Quick-Start-Guide_20210615_7368c925-e865-4fd8-955e-31756236e1d7.pdf
- DS-2CD2386G2-IU-C_Datasheet_V5.5.112_20210316_22f127d2-85f2-466e-a463-8b87b8896899.pdf
