  • Sku: 8xDS-2CD2386_ACUSENSE/ DS-7616ni-3TB-WHITE
  • Vendor: SecurityAustralia

Hikvision 8MP Acusense 8 x Outdoor Turret With Strobe & Siren + 16CH NVR CCTV Kit WHITE

$4,458.00 AUD
 per
In stock!
Spend $100.00 to FREE SHIPPING

8 x 8MP Hikvision AcuSense Outdoor Turret Cameras with Strobe & Siren

Code/SKU: DS-2CD2386G2-ISU/SL

Quick Specs: H.265+, IR 30m, 120dB WDR, IP67

Lens Options: 2.8mm / 4mm; Color: BLACK/WHITE (subject to stock availabilities)

Key Features:

  • High Resolution: 8MP imaging for clear, detailed surveillance.
  • Infrared Range: IR range up to 30m for enhanced night vision.
  • Weatherproof: IP67 rating for durability in various weather conditions.
  • Wide Dynamic Range: 120dB WDR for balanced images in varied lighting.
  • Low-Light Performance: Powered by DarkFighter technology for superior imaging in low-light conditions.
  • Smart Detection: AcuSense technology for accurate human and vehicle detection, reducing false alarms.
  • Built-in Audio: Microphone for real-time audio monitoring and communication.
  • Audio Alarm: Strobe light and speaker for active deterrence of intruders.

1 x 16CH Hikvision PoE NVR

Code/SKU: DS-7616NI-M2

Quick Specs: 16CH PoE NVR, 128Mbps, 16 PnP Ports, 4K, VGA/HDMI, 2 HDD Bay, 3TB Hard Drive

Suitable For:

This system is ideal for those requiring a comprehensive, high-resolution surveillance solution with advanced features for both residential and commercial security applications.

Specifications

Camera Image Sensor
1/1.8" Progressive Scan CMOS
Min. Illumination
Color: 0.003 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
Shutter Speed 1/3 s to 1/100,000 s
Slow Shutter Yes
P/N Wide Dynamic Range: 120 dB
Day & Night: IR cut filter
Angle Adjustment Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
Lens Lens Type
Fixed focal lens, 2.8, 4, and 6 mm optional
Iris Type
Fixed
Focal Length & FOV
2.8 mm, horizontal FOV 111°, vertical FOV 59°, diagonal FOV 131°
4 mm, horizontal FOV 87°, vertical FOV 47°, diagonal FOV 102°
6 mm, horizontal FOV 51°, vertical FOV 28°, diagonal FOV 60°
Aperture F1.6
Lens Mount M12
DORI 2.8 mm: D: 89.2 m, O: 35.4 m, R: 17.8 m, I: 8.9 m
4 mm: D: 99.4 m, O: 39.4 m, R: 19.9 m, I: 9.9 m
6 mm: D: 140.0 m, O: 55.6 m, R: 28.0 m, I: 14.0 m
Illuminator Supplement Light Type
IR
IR Range
Up to 30 m
IR Wavelength
850 nm
Smart Supplement Light
Yes
Visual Alarm
Yes
Video Max. Resolution
3840 × 2160
Main Stream
50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 24 fps (3840 × 2160) 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
Third Stream
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
*Third stream is supported under certain settings.
Video Compression Main stream: H.265/H.264/H.264+/H.265+
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
*Third stream is supported under certain settings.
Video Bit Rate H.264 Type: 32 Kbps to 16 Mbps (Baseline Profile/Main Profile/High Profile)
H.265 Type: Main Profile
H.264+: Main stream supports
H.265+: Main stream supports
Bit Rate Control CBR/VBR
Scalable Video Coding (SVC) H.264 and H.265 encoding
Region of Interest (ROI) 1 fixed region for main stream and sub-stream
Audio Audio Type
Mono sound
Environment Noise Filtering
Yes
Audio Sampling Rate
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Audio Compression
G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bit Rate
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
Network Simultaneous Live View
Up to 6 channels
API
Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets
User/Host Security
Up to 32 users. 3 user levels: administrator, operator and user
Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
Network Storage NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Client Web Browser
iVMS-4200, Hik-Connect, Hik-Central
Plug-in required live view: IE 10, IE 11
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Image SNR
≥ 52 dB
Target Cropping
Yes
Day/Night Switch
Day, Night, Auto, Schedule
Image Enhancement
BLC, HLC, 3D DNR
Image Parameters Switch
Yes
Image Settings
Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
Interface Alarm
1 input, 1 output (max. 24 VDC/24 VAC, 500 mA)
Audio
1 input (line in), terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium; 1 output (line out), terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium; 1 built-in speaker, 1 built-in microphone
Built-in Microphone
Yes
Built-in Speaker
Yes
On-Board Storage
Built-in micro SD/SDHC/SDXC slot, up to 512 GB
Hardware Reset Yes
Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port
Event Basic Event
Motion detection (human and vehicle targets classification), video tampering alarm, exception
Smart Event
Scene change detection
Deep Learning Function
Face Capture
Perimeter Protection
Line crossing detection, intrusion detection, region entrance detection, region exiting detection
Supports human and vehicle targets classification
General Linkage Method
Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture, trigger alarm output, audible warning, strobe light
Web Client Language
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General Function
Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter
Software Reset Yes
Firmware Version V5.5.112
Storage Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup and Operating Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Power Supply 12 VDC ± 25%, reverse polarity protection
PoE: 802.3af, Class 3
Power Consumption and Current 12 VDC, 0.75 A, max. 9 W
PoE (802.3af, 36 V to 57 V), 0.28 A to 0.17 A, max. 10 W
Power Interface Ø5.5 mm coaxial power plug
Camera Material Metal except for trim ring
Camera Dimension Ø138.3 mm× 124.5 mm (Ø5.4" × 4.9")
Package Dimension 170 mm × 170 mm × 150 mm (6.9" × 6.9" × 5.9")
Camera Weight Approx. 840 g (1.9 lb.)
With Package Weight Approx. 1160 g (2.6 lb.)
Approval EMC
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
Safety
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014 ); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014 )
Environment
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Protection
IP67 (IEC 60529-2013)

Documentation

3 Years Manufacturer Warranty

All IP cameras and recording devices (NVR’s/DVR’s) are covered by a 3 year back-to-base manufacturer warranty.

Our warranty is limited to the replacement of faulty items or parts and does not include damage due to incorrect fitting of parts or accessories, or damage due to mishandling the equipment once out of the box. All faults are sent to the manufacturer for inspection and diagnosis before a replacement is sent out.

Read more about the Terms & Conditions here – https://www.securityaustralia.com.au/terms-and-conditions/

Trusted Brand Partner & Security Equipment Wholesaler

Authorised Brand Partner with Responsive & Fast Aussie Sales Support Team ★★★★★
Best After-Sales Support and Troubleshooting Team with Years of Installation Experience.

Free Delivery* & Despatch Time

*Just spend over $100 to activate Fast Free Shipping!

Despatch Times: Products are despatched on the same day if the order was placed before 11am on any weekday, Monday - Friday. All other orders are processed and despatched within 24 hours or next business day.

Order Confirmation: Once you place an order, you will receive a confirmation email. This indicates that your order has been received in our system and is now being processed for dispatch. If your item is back-ordered or unavailable, we will notify you via email, and if we do not receive a response, we will attempt to contact you by phone as soon as possible. We value your time and strive to be prompt. If your item(s) are available for immediate shipment (within 2 days), we will process the charges and prepare the order for shipping.

Shipping Times: General shipping times for StarTrack, TNT and Allied couriers are between 1-3 working days from despatch. Longer delivery times may be caused by your package being held at your local courier depot that is beyond our control. Please contact us or the local post depot for confirmation.

Tracking Numbers: all tracking numbers will be emailed to you by our warehouse processing team within the day, after your order is despatched to our local courier.

View full details

Hikvision 8MP Acusense 8 x Outdoor Turret With Strobe & Siren + 16CH NVR CCTV Kit WHITE

8 x 8MP 4K AcuSense Strobe Light and Audible Warning Fixed Turret Network Camera: Elevate your outdoor security with the DS-2CD2386G2-ISU/SL Fixed Turret Network Camera from Hikvision. This powerful camera features 8MP (4K) resolution, ensuring high-quality imaging even in challenging low-light conditions. Powered by DarkFighter technology, it offers exceptional performance in low-light environments. Benefit from 120 dB true WDR technology, which provides clear images even against strong backlight, and efficient H.265+ compression to minimize bandwidth and storage requirements.

This camera is equipped with AcuSense technology, which accurately classifies human and vehicle targets, significantly reducing false alarms. The DS-2CD2386G2-ISU/SL also includes an active strobe light and an audible alarm to deter intruders, along with built-in two-way audio for real-time communication. Designed for outdoor use, it is IP66-rated, offering protection against water and dust, ensuring durability in various weather conditions.

Functions:

AcuSense Technology: This camera leverages advanced deep learning algorithms to differentiate between human and vehicle targets and other moving objects like animals or rain. This technology significantly reduces false alarms, ensuring that users are only alerted to real security threats. Additionally, it enhances search efficiency by allowing users to filter video footage based on specific object classifications, making it faster and easier to locate relevant events.

DarkFighter Technology: DarkFighter technology is designed to capture high-quality images in low-light conditions. By utilizing a large iris and advanced image sensors, DarkFighter cameras produce clear and sharp images even in near-total darkness, making them ideal for applications requiring reliable nighttime surveillance, such as parking lots, streets, and other poorly lit areas.

Two-Way Audio: The camera features a built-in microphone and speaker, enabling two-way communication. This function allows users to listen to and communicate with individuals on the camera's premises, providing an additional layer of security and control. Whether it's warning off potential intruders or communicating with visitors, this feature enhances the camera's versatility.

Active Strobe Light and Audible Alarm: The camera includes an active deterrence feature with a built-in strobe light and audible alarm. When a potential threat is detected, the camera activates these features to warn off intruders and alert users to potential dangers. This proactive approach to security helps prevent incidents before they escalate, making it a powerful tool for protecting your property.

Key Features:

  • High-Quality Imaging: The 8MP (4K) resolution ensures that every detail is captured with stunning clarity, making it easier to identify crucial details in surveillance footage.
  • Superior Low-Light Performance: Powered by DarkFighter technology, the camera excels in low-light conditions, providing clear images even in near-total darkness.
  • Wide Dynamic Range: 120 dB true WDR technology ensures balanced imaging in environments with varying lighting conditions, such as areas with both bright and dark zones.
  • Efficient Compression: H.265+ compression technology significantly reduces bandwidth and storage requirements while maintaining high image quality.
  • Active Deterrence: The camera's built-in strobe light and audible alarm serve as effective deterrents against potential intruders.
  • Weatherproof Design: With an IP66 rating, the camera is built to withstand harsh outdoor conditions, including rain, dust, and extreme temperatures.
  • Infrared Range and Viewing Angles: The camera offers an IR range of up to 30m, with viewing angles depending on the lens options (e.g., 2.8 mm, horizontal FOV: 99°, vertical FOV: 61°, diagonal FOV: 128°).

Specifications Summary:

Resolution: 8MP (4K)
Technology: DarkFighter, 120 dB WDR, H.265+ compression
Features: AcuSense, active strobe light, two-way audio
Protection: IP66-rated (water and dust resistant)

Experience enhanced security with detailed 4K resolution and advanced features tailored for outdoor applications.
