Hanwha Vision 8CH AI NVR with 8 x PoE
The XRN-820S integrates seamlessly with Hanwha Vision’s range of cameras, providing a cohesive and scalable security solution. It supports H.265 compression technology, which significantly reduces bandwidth and storage requirements while maintaining high image quality. The NVR is equipped with a user-friendly interface for easy configuration and operation. It also offers flexible storage options, including RAID support, to ensure data redundancy and protection. The device is built to handle high-resolution video streams from multiple cameras simultaneously, making it suitable for both small and large-scale installations. With its robust build and reliability, the XRN-820S is designed to meet the demands of continuous operation in various environments.
Key Features
Code/SKU: XRN-820S
Quick Specs:
Local Display
FHD : HDMI & VGA Dual monitor UHD : HDMI Single monitor
Multi Screen Display
[Local Monitor] - Dynamic layout, Virtual channel view - Up to 16 Division [Web] 1/ 2H/ 2V/ 3V/ 4/ 6/ 8/ 9
| Display | ||
|---|---|---|
| Network camera | ||
| Inputs | Max. 8CH | |
| Resolution | 32MP ~ CIF | |
| Protocols | SUNAPI, ONVIF | |
| Decoding | ||
| Local Display | FHD : HDMI & VGA Dual monitor UHD : HDMI Single monitor | |
| Multi Screen Display | [Local Monitor] - Dynamic layout, Virtual channel view - Clone mode : Up to 16 Division - Expand mode : Up to 9 Division [Web] 1/ 2H/ 2V/ 3V/ 4/ 6/ 8/ 9 | |
| Resolution | [Local Monitior] FHD Clone mode : 32M(15fps, H.265 Only), 12M(30fps, H.265 Only), 8.3M(50fps), 1080p(240fps), D1(480fps) UHD Single mode : 32M(15fps, H.265 Only), 12M(30fps, H.265 Only), 8.3M(50fps), 1080p(240fps), D1(270fps) FHD Expand mode: 32M(12fps, H.265 Only), 12M(25fps, H.265 Only), 8.3M(30fps), 1080p(90fps), D1(200fps) | |
| Performance | ||
| Operating System | ||
| Embedded | Linux | |
| Record | ||
| Compression | H.265, H.264, MJPEG | |
| Recording Bandwidth | Max. 120Mbps | |
| Resolution | 32MP ~ CIF | |
| Mode | Normal, Dual Stream, Schedule(Continuous/Event), Event (Pre/Post), Bookmark | |
| Event Trigger | Alarm Input, Video Loss, Camera Event(Sensor, MD, Video Analytics, Defocus, Audio), Dynamic Event, User Event | |
| Event Action | e-Mail, Event Push, PTZ Preset, Alarm Out, Buzzer, Monitor Out, FTP, SUNAPI Command, Shutdown | |
| Search & Play | ||
| Playback Bandwidth | Max. 32Mbps | |
| User | Max. 4 Users (Local 1, Remote 3) | |
| Simultaneous playback | Max. 32CH(Local 8CH, Remote 8CH per user) | |
| Fisheye Dewarping | CMS | |
| Mode | Date & Time(Calendar), Event list, Text Search, Smart Search | |
| Resolution | CIF ~ 32MP (Up to H.264 8.3MP, H.265 32MP) | |
| Playback Control | Fast/Slow Forward / Backward, Move one step Up / Down | |
| Storage | ||
| Supported HDD | Up to 6TB | |
| HDD Slot | SATA 2ea(Max. 12TB) | |
| RAID | RAID-1 | |
| Backup | ||
| File backup | BU/Exe/AVI(GUI), JPG/AVI(Network) | |
| Function | Multi channel(Up to 8CH) Play, Date-Time/Title display | |
| Network | ||
| Protocol | IPv4, IPv6, TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTSP, NTP, HTTP, DHCP (Server, Client), SMTP, ICMP, IGMP, ARP, DNS, DDNS, uPnP, HTTPS, SNMP, ONVIF (Profile-S), SUNAPI(Server, Client) | |
| DDNS | Hanwha DDNS | |
| Transmission Bandwidth | Max. 120Mbps | |
| Audio | ||
| GUI | 8 CH(network) | |
| Web | G.711, G.726, AAC(16/48KHz) | |
| Audio Communication | 2-Way | |
| Max Remote Users | Search(3), Live Unicast(10), Multicast(20) | |
| Security | IP address filtering, User access Log, 802.1x, Encryption Device certificate(Hanwha Techwin Root CA), Signed firmware | |
| Web viewer | ||
| Supported OS | Windows 10, macOS 10.13 | |
| Supported browser | Google Chrome, Microsoft Edge, Mac Safari | |
| Viewer Software | WAVE, SSM, Webviewer, Smart Viewer, Wisenet mobile Support CGI(SUNAPI) for integration to 3'rd party VMS | |
| Functions | ||
| Camera Setup | ||
| Register | Auto, Manual | |
| Item | IP address, Add profile edit, Bitrate, Compression, GOP, Quality, Camera MD setup (4, 8 point polygon) Camera video setup (Simple focus, Brightness/Contrast, Flip/Mirror, IRIS, WDR, D&N, SSNR, Shutter, SSDR, DIS), Fisheye Dewarping Mode, Hallway View Setup, Camera Webpage | |
| PTZ | ||
| Control | Via GUI, Webviewer, SPC-2000 | |
| Preset | 300 Presets | |
| Smart phone | ||
| Support Model | iOS, Android | |
| Protocol Support | RTP, RTSP, HTTP, CGI(SUNAPI) | |
| Control | Live 8CH(Multi-Profile Support), Playback 4CH | |
| Max. Remote Users | Search(3), Live Unicast(10) | |
| Redundancy | ||
| Failover | N+1 | |
| ARB | Support | |
| Easy configuration | P2P(QR code) | |
| Interface | ||
| Front | ||
| Indicator | HDD, Alarm, Power, Record, Backup, Network | |
| Storage | OK | |
| HDMI | 1EA 3840x2160 30Hz | |
| VGA | 1EA 1920x1080 60Hz | |
| Audio | Out 1EA (3.5mm Audio Jack) | |
| Ethernet | PoE+ RJ-45 8EA (LAN, 10/100), RJ-45 2ea (LAN/WAN 1Gbps) | |
| Alarm | In 4EA, Out 2EA | |
| USB | 3EA(Front 2 x USB 2.0, Rear 1 x USB 3.0) | |
| Power inlet | AC 1EA | |
| System | ||
| Log | ||
| Log List | Max. 100,000 (System Log, Event Log each) | |
| System Control | Mouse, Keyboard, Web, Controller (SPC-2000) | |
| Language | English, French, German, Italian, Spanish, Russian, Turkish, Polish, Dutch, Czech, Portuguese, Danish, Romanian, Serbian, Croatian, Hungarian, Greek, Norwegian, Finnish, Korean, Chinese, Japanese, Thai, Vietnamese | |
| Environmental | ||
| Operating Temperature | 0°C to +40°C(32℉ to 104℉) | |
| Operating Humidity | 20% ~ 85% RH | |
| Electrical | ||
| Power Input | 100 ~ 240 VAC ±10%; 50/60 Hz | |
| Power Consumption | Max 160W | |
| PoE Budget | 100W | |
| Mechanical | ||
| Color / Material | Black / Metal | |
| Dimension (WxHxD) | 370 x 50.7 x 324.3 mm (14.57 x 2 x 12.77 inch) | |
| Weight | 2.7Kg (5.95lb) | |
| Intelligent Analysis | ||
| AI Search | ||
| Object Attribute | Compatible for Hanwha AI Camera | |
All IP cameras and recording devices (NVR’s/DVR’s) are covered by a 3 year back-to-base manufacturer warranty.
Our warranty is limited to the replacement of faulty items or parts and does not include damage due to incorrect fitting of parts or accessories, or damage due to mishandling the equipment once out of the box. All faults are sent to the manufacturer for inspection and diagnosis before a replacement is sent out.
Read more about the Terms & Conditions here – https://www.securityaustralia.com.au/terms-and-conditions/
*Just spend over $100 to activate Fast Free Shipping!
Despatch Times: Products are despatched on the same day if the order was placed before 11am on any weekday, Monday - Friday. All other orders are processed and despatched within 24 hours or next business day.
Order Confirmation: Once you place an order, you will receive a confirmation email. This indicates that your order has been received in our system and is now being processed for dispatch. If your item is back-ordered or unavailable, we will notify you via email, and if we do not receive a response, we will attempt to contact you by phone as soon as possible. We value your time and strive to be prompt. If your item(s) are available for immediate shipment (within 2 days), we will process the charges and prepare the order for shipping.
Shipping Times: General shipping times for StarTrack, TNT and Allied couriers are between 1-3 working days from despatch. Longer delivery times may be caused by your package being held at your local courier depot that is beyond our control. Please contact us or the local post depot for confirmation.
Tracking Numbers: all tracking numbers will be emailed to you by our warehouse processing team within the day, after your order is despatched to our local courier.
Hanwha Wisenet XRN-820S 8ch PoE NVR, AI Search, H.265, 100Mbps, No HDD (2 SATA 12TB)
The Hanwha Vision XRN-820S is an advanced 8-channel AI Network Video Recorder designed for high-performance video surveillance. It features 8 Power over Ethernet (PoE) ports, simplifying the installation process by eliminating the need for separate power supplies for each camera. The NVR supports high-definition recording and playback, ensuring clear and detailed video footage. Its AI capabilities enhance surveillance efficiency by offering advanced video analytics, including object detection and classification. The XRN-820S integrates seamlessly with Hanwha Vision’s range of cameras, providing a cohesive and scalable security solution. It supports H.265 compression technology, which significantly reduces bandwidth and storage requirements while maintaining high image quality.
The NVR is equipped with a user-friendly interface for easy configuration and operation. It also offers flexible storage options, including RAID support, to ensure data redundancy and protection. The device is built to handle high-resolution video streams from multiple cameras simultaneously, making it suitable for both small and large-scale installations. With its robust build and reliability, the XRN-820S is designed to meet the demands of continuous operation in various environments. It supports remote access and management, allowing users to monitor their security system from anywhere. The NVR is compatible with various network protocols, enhancing its interoperability with other security devices. It features a compact and sleek design that fits easily into standard racks or cabinets. The XRN-820S is equipped with advanced cybersecurity measures to protect against unauthorized access and data breaches. Its comprehensive feature set makes it a versatile choice for professional security applications.
Features
| Display | |
| Network Camera | |
| Inputs | Max. 8CH |
| Resolution | 32MP ~ CIF |
| Protocols | SUNAPI, ONVIF |
| Decoding | |
| Local Display | FHD: HDMI & VGA Dual monitor UHD: HDMI Single monitor |
| Multi Screen Display |
Local Monitor: - Dynamic layout, Virtual channel view - Clone mode: Up to 16 Division - Expand mode: Up to 9 Division Web: 1 / 2H / 2V / 3V / 4 / 6 / 8 / 9 |
| Resolution |
Local Monitor: FHD Clone mode: 32M (15fps, H.265 Only), 12M (30fps, H.265 Only), 8.3M (50fps), 1080p (240fps), D1 (480fps) UHD Single mode: 32M (15fps, H.265 Only), 12M (30fps, H.265 Only), 8.3M (50fps), 1080p (240fps), D1 (270fps) FHD Expand mode: 32M (12fps, H.265 Only), 12M (25fps, H.265 Only), 8.3M (30fps), 1080p (90fps), D1 (200fps) |
| Performance | |
| Operating System | Embedded Linux |
| Record | |
| Compression | H.265, H.264, MJPEG |
| Recording Bandwidth | Max. 120Mbps |
| Resolution | 32MP ~ CIF |
| Mode | Normal, Dual Stream, Schedule (Continuous/Event), Event (Pre/Post), Bookmark |
| Event Trigger | Alarm Input, Video Loss, Camera Event (Sensor, MD, Video Analytics, Defocus, Audio), Dynamic Event, User Event |
| Event Action | e-Mail, Event Push, PTZ Preset, Alarm Out, Buzzer, Monitor Out, FTP, SUNAPI Command, Shutdown |
| Search & Play | |
| Playback Bandwidth | Max. 32Mbps |
| User | Max. 4 Users (Local 1, Remote 3) |
| Simultaneous Playback | Max. 32CH (Local 8CH, Remote 8CH per user) |
| Fisheye Dewarping | CMS |
| Mode | Date & Time (Calendar), Event list, Text Search, Smart Search |
| Resolution | CIF ~ 32MP (Up to H.264 8.3MP, H.265 32MP) |
| Playback Control | Fast/Slow Forward / Backward, Move one step Up / Down |
| Storage | |
| Supported HDD | Up to 6TB |
| HDD Slot | SATA 2ea (Max. 12TB) |
| RAID | RAID-1 |
| Backup | |
| File Backup | BU/Exe/AVI (GUI), JPG/AVI (Network) |
| Function | Multi channel (Up to 8CH) Play, Date-Time/Title display |
