Hanwha Vision HV-HCB-6001 1080p 2MP Analog HD Camera
1080p Analog HD camera
The Hanwha Vision HCB-6001 is a 1080p analog HD camera designed for high-resolution video surveillance. It features a 2.1-megapixel CMOS sensor, ensuring clear and detailed image capture even in challenging lighting conditions. With its True Day/Night functionality and built-in infrared LEDs, the camera provides reliable performance in low-light environments, extending its range up to 20 meters.
Key Features
- Full HD (1920 x 1080, 30fps) resolution
- 0.09 Lux @ F1.2 (Color), 0.009 Lux @ F1.2 (B/W)
- Day & Night (ICR), WDR (120dB)
- SSNR IV, Motion detection
- Transmission distance max. 500m
- Easy installation (Plug & play), Dual power, RS-485
Code/SKU: HCB-6001
Quick Specs:
- Video Output: BNC (AHD / TVI / CVI / CVBS Selectable)
- Resolution: 1920 x 1080
- Max. Framerate: 30fps @ 1080p
Need help choosing?
Click to ask a question - same day response (~2 hours during business hours)
Product Overview
The Hanwha Vision HV-HCB-6001 1080p 2MP Analog HD Camera designed for surveillance applications. With a resolution of 1080p and a 2MP sensor, it delivers crisp and clear images. Its analog HD technology ensures compatibility with existing coaxial infrastructures, simplifying installation and integration. The camera is equipped with advanced features such as day/night functionality and digital noise reduction, enhancing its performance in various lighting conditions. With its robust build quality and reliable performance, the Hanwha Vision HV-HCB-6001 is an excellent choice for securing commercial and residential premises.
Features
- Full HD (1920 x 1080, 30fps) resolution
- 0.09Lux@F1.2 (Color), 0.009Lux@F1.2 (B/W)
- Day & Night (ICR), WDR (120dB)
- SSNRⅣ, Motion detection
- Transmission distance max. 500m
- Easy installation (Plug & play), Dual power, RS-485
WiseNet HD+ series is an analog HD solution that provides better performance than existing analog products. WiseNet HD+ can transmit 1080p Full-HD high quality images through existing coaxial cable at a distance up to 1640ft. It is also backwards compatible with any existing analog system.
Technical Specifications:
| Video | |
|---|---|
| Imaging Device | 1/2.8" 2MP CMOS |
| Resolution | 1920x1080 |
| Max. Framerate | 30fps / 25fps(60Hz / 50Hz) |
| Min. Illumination | Color: 0.09Lux(F1.2, 1/30sec) BW: 0.009Lux(F1.2, 1/30sec) |
| Video Out | BNC(AHD / TVI / CVI / CVBS Selectable) |
| Video Transmission Distance | 500m(5C2V Coaxial Cable) 300m(5C2V Coaxial Cable) |
| Lens | |
| Focus Control | Simple focus, Manual |
| Lens Type | DC auto iris |
| Mount Type | C mount, CS mount |
| Operational | |
| Camera Title | Displayed up to 15 characters |
| Day & Night | Auto(ICR) |
| Backlight Compensation | BLC, HLC, WDR |
| Wide Dynamic Range | 120dB |
| Digital Noise Reduction | SSNRⅣ |
| Defog | Support |
| Motion Detection | 4ea |
| Privacy Masking | 4ea, rectangular zones |
| Gain Control | Low / Middle / High / Very High |
| White Balance | ATW / AWC / Manual / Indoor / Outdoor |
| Electronic Shutter Speed | 1 ~ 1/12,000sec |
| Video Rotation | H-Rev / V-Rev |
| Analytics | Motion detection |
| Serial Interface | RS-485(Samsung-T, Pelco-D/P, Panasonic, Bosch, AD, GE, Vicon, Honeywell) |
| Alarm I/O | MD output 1ea, External D/N 1ea |
| Alarm Triggers | Analytics |
| Alarm Events | Alarm output |
| Coaxial Protocol | ACP(AHD Coax Protocol), TCP(TVI Coax Protocol), CCP(CVI Coax Protocol) CVBS: Pelco-C(Coaxitron) |
| Environmental & Electrical | |
| Operating Temperature / Humidity | -10°C ~ +55°C(+14°F ~ +131°F) / Less than 90% RH |
| Input Voltage | 24VAC, 12VDC |
| Power Consumption | Max 6W |
| Mechanical | |
| Color / Material | Black / Aluminum, Ivory / Plastic |
| Product Dimensions / Weight | 130.9(H)×73.1(V)×67.2(D)mm(5.15×2.88×2.65"), 287g(0.63 lb) |
Key Features
Trusted Brand Partner & Security Equipment Wholesaler
- Authorised Brand Partner with Responsive & Fast Aussie Sales Support Team ★★★★★
- Best After-Sales Support and Troubleshooting Team with Years of Installation Experience.
What This Product Does
1080p Analog HD camera
The Hanwha Vision HCB-6001 is a 1080p analog HD camera designed for high-resolution video surveillance. It features a 2.1-megapixel CMOS sensor, ensuring clear and detailed image capture even in challenging lighting conditions. With its True Day/Night functionality and built-in infrared LEDs, the camera provides reliable performance in low-light environments, extending its range up to 20 meters.
Key Features
- Full HD (1920 x 1080, 30fps) resolution
- 0.09 Lux @ F1.2 (Color), 0.009 Lux @ F1.2 (B/W)
- Day & Night (ICR), WDR (120dB)
- SSNR IV, Motion detection
- Transmission distance max. 500m
- Easy installation (Plug & play), Dual power, RS-485
Code/SKU: HCB-6001
Quick Specs:
- Video Output: BNC (AHD / TVI / CVI / CVBS Selectable)
- Resolution: 1920 x 1080
- Max. Framerate: 30fps @ 1080p
Not sure if this suits your site?
Ask our team before ordering. We can help confirm lens choice, recorder compatibility, mounting accessories and project quantities.
Specifications
Specifications
| Video | |
|---|---|
| Imaging Device | 1/2.8" 2MP CMOS |
| Resolution | 1920x1080 |
| Max. Framerate | 30fps / 25fps(60Hz / 50Hz) |
| Min. Illumination | Color: 0.09Lux(F1.2, 1/30sec) BW: 0.009Lux(F1.2, 1/30sec) |
| Video Out | BNC(AHD / TVI / CVI / CVBS Selectable) |
| Video Transmission Distance | 500m(5C2V Coaxial Cable) 300m(5C2V Coaxial Cable) |
| Lens | |
| Focus Control | Simple focus, Manual |
| Lens Type | DC auto iris |
| Mount Type | C mount, CS mount |
| Operational | |
| Camera Title | Displayed up to 15 characters |
| Day & Night | Auto(ICR) |
| Backlight Compensation | BLC, HLC, WDR |
| Wide Dynamic Range | 120dB |
| Digital Noise Reduction | SSNRⅣ |
| Defog | Support |
| Motion Detection | 4ea |
| Privacy Masking | 4ea, rectangular zones |
| Gain Control | Low / Middle / High / Very High |
| White Balance | ATW / AWC / Manual / Indoor / Outdoor |
| Electronic Shutter Speed | 1 ~ 1/12,000sec |
| Video Rotation | H-Rev / V-Rev |
| Analytics | Motion detection |
| Serial Interface | RS-485(Samsung-T, Pelco-D/P, Panasonic, Bosch, AD, GE, Vicon, Honeywell) |
| Alarm I/O | MD output 1ea, External D/N 1ea |
| Alarm Triggers | Analytics |
| Alarm Events | Alarm output |
| Coaxial Protocol | ACP(AHD Coax Protocol), TCP(TVI Coax Protocol), CCP(CVI Coax Protocol) CVBS: Pelco-C(Coaxitron) |
| Environmental & Electrical | |
| Operating Temperature / Humidity | -10°C ~ +55°C(+14°F ~ +131°F) / Less than 90% RH |
| Input Voltage | 24VAC, 12VDC |
| Power Consumption | Max 6W |
| Mechanical | |
| Color / Material | Black / Aluminum, Ivory / Plastic |
| Product Dimensions / Weight | 130.9(H)×73.1(V)×67.2(D)mm(5.15×2.88×2.65"), 287g(0.63 lb) |
