Hanwha Vision HV-ANV-L7082R 4MP H.265 NW IR Outdoor Vandal Dome Camera
4MP IR Outdoor Vandal Dome
The Hanwha Vision ANV-L7082R is a robust 4MP IR outdoor vandal dome camera, designed for high-performance surveillance in challenging environments. It features a 3mm fixed focal lens with an angular field of view of 99° horizontally, 55° vertically, and 115° diagonally. The camera captures clear images even in low-light conditions, with a minimum illumination of 0.13 lux in color mode and 0 lux in black-and-white mode, thanks to its integrated IR LEDs with a range of up to 20 meters. The camera supports H.265, H.264, and MJPEG video compression formats, optimizing storage and bandwidth usage.
Key Features
- 4MP resolution, Up to 30fps
- Color : 0.1Lux (F1.6, 1/30sec), B/W : 0Lux (IR LED On)
- 3.3 ~ 10.3mm motorized varifocal with Simple Focus
- IR viewable length: 30m (98.42ft)
- Day & Night (ICR), WDR (120dB)
- H.265, H.264, MJPEG, Multiple streaming supported
- Defocus detection, Directional detection, Motion detection, Enter/Exit, Tampering
- Hallway view (90⁰/270⁰), LDC support, WiseStream II
- Micro SD/SDHC/SDXC memory 1 slot (Max. 128GB)
- IP66, IK10
Code/SKU: ANV-L7082R
Quick Specs:
- Focal Length (Zoom Ratio): 3.3~10.3mm (3.1x) motorized varifocal
- Max. Aperture Ratio: F1.6 (Wide) ~ F3.3 (Tele)
- Angular Field of View:
- Horizontal: 94.8° (Wide) ~ 28.1° (Tele)
- Vertical: 50.2° (Wide) ~ 15.8° (Tele)
- Diagonal: 112.9° (Wide) ~ 32.2° (Tele)
Need help choosing?
Click to ask a question - same day response (~2 hours during business hours)
Product Overview
The Hanwha Vision ANV-L7082R is a robust 4MP IR outdoor vandal dome camera, designed for high-performance surveillance in challenging environments. It features a 3mm fixed focal lens with an angular field of view of 99° horizontally, 55° vertically, and 115° diagonally. The camera captures clear images even in low-light conditions, with a minimum illumination of 0.13 lux in color mode and 0 lux in black-and-white mode, thanks to its integrated IR LEDs with a range of up to 20 meters. The camera supports H.265, H.264, and MJPEG video compression formats, optimizing storage and bandwidth usage. It also includes advanced features like 120dB true wide dynamic range (WDR) for handling high-contrast lighting situations and intelligent video analytics (IVA) for enhanced security monitoring. The camera's durable construction is certified to IP66 and IK10 standards, ensuring resistance to harsh weather and vandalism. Additionally, it supports various security protocols, including HTTPS, SRTP, and 802.1X authentication, making it a reliable choice for secure and efficient surveillance.
Features
- 4MP resolution, Up to 30fps
- Color : 0.1Lux (F1.6, 1/30sec), B/W : 0Lux (IR LED On)
- 3.3 ~ 10.3mm motorized varifocal with Simple Focus
- IR viewable length: 30m (98.42ft)
- Day & Night (ICR), WDR (120dB)
- H.265, H.264, MJPEG, Multiple streaming supported
- Defocus detection, Directional detection, Motion detection, Enter/Exit, Tampering
- Hallway view (90⁰/270⁰), LDC support, WiseStream II
- Micro SD/SDHC/SDXC memory 1 slot (Max. 128GB)
- IP66, IK10
Technical Specifications:
| Video | |
| Imaging Device | 1/2.8" CMOS |
| Resolution | 2560 x 1440, 1920 x 1080, 1280 x 960, 1280 x 720, 800 x 600, 800 x 448, 720 x 576, 720 x 480, 640 x 480, 640 x 360, 320 x 240 |
| Max. Framerate | H.265/H.264: Max. 30fps at 4M all resolutions MJPEG: Max. 15fps |
| Min. Illumination | Color: 0.1Lux (F1.6, 1/30sec) B/W: 0Lux (IR LED On) |
| Lens | |
| Focal Length (Zoom Ratio) | 3.3~10.3mm (3.1x) motorized varifocal |
| Max. Aperture Ratio | F1.6 (Wide) ~ F3.3 (Tele) |
| Angular Field of View | H: 94.8° (Wide) ~ 28.1° (Tele) V: 50.2° (Wide) ~ 15.8° (Tele) D: 112.9° (Wide) ~ 32.2° (Tele) |
| Min. Object Distance | 0.5m (1.64ft) |
| Focus Control | Simple focus |
| Lens Type | DC auto iris |
| Pan / Tilt / Rotate | |
| Pan / Tilt / Rotate Range | 0° ~ 350° / 0° ~ 67° / 0° ~ 355° |
| Operational | |
| Camera Title | Displayed up to 85 characters |
| Day & Night | Auto (ICR) |
| Backlight Compensation | BLC, WDR, SSDR |
| Wide Dynamic Range | 120dB |
| Digital Noise Reduction | SSNR |
| Motion Detection | 4ea, polygonal zones |
| Privacy Masking | 6ea, rectangular zones |
| Gain Control | Low / Middle / High |
| White Balance | ATW / AWC / Manual / Indoor / Outdoor |
| LDC | Support |
| Electronic Shutter Speed | Minimum/Maximum/Anti flicker (1/5~1/12,000sec) |
| Video Rotation | Flip, Mirror, Hallway view (90˚/270˚) |
| Analytics | Defocus detection, Motion detection, Tampering, Virtual area (Intrusion/Enter/Exit), Virtual line (Crossing/Direction) |
| Alarm Triggers | Analytics, Network disconnect |
| Alarm Events | File upload via FTP and e-mail, Notification via e-mail, SD/SDHC/SDXC or NAS recording at event triggers, Handover |
| IR Viewable Length | 30m (98.43ft) |
| Network | |
| Ethernet | RJ-45 (10/100BASE-T) |
| Video Compression | H.265/H.264: Main/High, MJPEG |
| Smart Codec | Manual (5ea area), WiseStreamⅡ |
| Bitrate Control | H.264/H.265: CBR or VBR MJPEG: VBR |
| Streaming | Unicast (6 users) / Multicast Multiple streaming (Up to 3 profiles) |
| Protocol | IPv4, IPv6, TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3 (MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP |
| Security | HTTPS (SSL) Login Authentication, Digest Login Authentication, IP Address Filtering, User access Log, 802.1X Authentication |
| Application Programming Interface | ONVIF Profile S/G/T, SUNAPI (HTTP API) |
| General | |
| Webpage Language | English |
| Edge Storage | Micro SD/SDHC/SDXC 1 slot 128GB |
| Memory | 512MB RAM, 256MB Flash |
| Environmental & Electrical | |
| Operating Temperature / Humidity | -30°C ~ +55°C (-22°F ~ +131°F) / Less than 95% RH * Start up should be done at above -20°C (-4°F) |
| Storage Temperature / Humidity | -30°C ~ +55°C (-22°F ~ +131°F) / Less than 95% RH |
| Certification | IP66, IK10 |
| Input Voltage | PoE (IEEE802.3af, Class3) |
| Power Consumption | Max 8.0W, typical 6.0W |
| Mechanical | |
| Color / Material | White / Plastic, Aluminum |
| Dimensions | Ø149.0 x 118.0mm (Ø5.87" x 4.65") |
| Weight | 640g (1.41 lb) |
Key Features
Trusted Brand Partner & Security Equipment Wholesaler
- Authorised Brand Partner with Responsive & Fast Aussie Sales Support Team ★★★★★
- Best After-Sales Support and Troubleshooting Team with Years of Installation Experience.
What This Product Does
4MP IR Outdoor Vandal Dome
The Hanwha Vision ANV-L7082R is a robust 4MP IR outdoor vandal dome camera, designed for high-performance surveillance in challenging environments. It features a 3mm fixed focal lens with an angular field of view of 99° horizontally, 55° vertically, and 115° diagonally. The camera captures clear images even in low-light conditions, with a minimum illumination of 0.13 lux in color mode and 0 lux in black-and-white mode, thanks to its integrated IR LEDs with a range of up to 20 meters. The camera supports H.265, H.264, and MJPEG video compression formats, optimizing storage and bandwidth usage.
Key Features
- 4MP resolution, Up to 30fps
- Color : 0.1Lux (F1.6, 1/30sec), B/W : 0Lux (IR LED On)
- 3.3 ~ 10.3mm motorized varifocal with Simple Focus
- IR viewable length: 30m (98.42ft)
- Day & Night (ICR), WDR (120dB)
- H.265, H.264, MJPEG, Multiple streaming supported
- Defocus detection, Directional detection, Motion detection, Enter/Exit, Tampering
- Hallway view (90⁰/270⁰), LDC support, WiseStream II
- Micro SD/SDHC/SDXC memory 1 slot (Max. 128GB)
- IP66, IK10
Code/SKU: ANV-L7082R
Quick Specs:
- Focal Length (Zoom Ratio): 3.3~10.3mm (3.1x) motorized varifocal
- Max. Aperture Ratio: F1.6 (Wide) ~ F3.3 (Tele)
- Angular Field of View:
- Horizontal: 94.8° (Wide) ~ 28.1° (Tele)
- Vertical: 50.2° (Wide) ~ 15.8° (Tele)
- Diagonal: 112.9° (Wide) ~ 32.2° (Tele)
Not sure if this suits your site?
Ask our team before ordering. We can help confirm lens choice, recorder compatibility, mounting accessories and project quantities.
Specifications
Specifications
| Video | |
| Imaging Device | 1/2.8" CMOS |
| Resolution | 2560 x 1440, 1920 x 1080, 1280 x 960, 1280 x 720, 800 x 600, 800 x 448, 720 x 576, 720 x 480, 640 x 480, 640 x 360, 320 x 240 |
| Max. Framerate | H.265/H.264: Max. 30fps at 4M all resolutions MJPEG: Max. 15fps |
| Min. Illumination | Color: 0.1Lux (F1.6, 1/30sec) B/W: 0Lux (IR LED On) |
| Lens | |
| Focal Length (Zoom Ratio) | 3.3~10.3mm (3.1x) motorized varifocal |
| Max. Aperture Ratio | F1.6 (Wide) ~ F3.3 (Tele) |
| Angular Field of View | H: 94.8° (Wide) ~ 28.1° (Tele) V: 50.2° (Wide) ~ 15.8° (Tele) D: 112.9° (Wide) ~ 32.2° (Tele) |
| Min. Object Distance | 0.5m (1.64ft) |
| Focus Control | Simple focus |
| Lens Type | DC auto iris |
| Pan / Tilt / Rotate | |
| Pan / Tilt / Rotate Range | 0° ~ 350° / 0° ~ 67° / 0° ~ 355° |
| Operational | |
| Camera Title | Displayed up to 85 characters |
| Day & Night | Auto (ICR) |
| Backlight Compensation | BLC, WDR, SSDR |
| Wide Dynamic Range | 120dB |
| Digital Noise Reduction | SSNR |
| Motion Detection | 4ea, polygonal zones |
| Privacy Masking | 6ea, rectangular zones |
| Gain Control | Low / Middle / High |
| White Balance | ATW / AWC / Manual / Indoor / Outdoor |
| LDC | Support |
| Electronic Shutter Speed | Minimum/Maximum/Anti flicker (1/5~1/12,000sec) |
| Video Rotation | Flip, Mirror, Hallway view (90˚/270˚) |
| Analytics | Defocus detection, Motion detection, Tampering, Virtual area (Intrusion/Enter/Exit), Virtual line (Crossing/Direction) |
| Alarm Triggers | Analytics, Network disconnect |
| Alarm Events | File upload via FTP and e-mail, Notification via e-mail, SD/SDHC/SDXC or NAS recording at event triggers, Handover |
| IR Viewable Length | 30m (98.43ft) |
| Network | |
| Ethernet | RJ-45 (10/100BASE-T) |
| Video Compression | H.265/H.264: Main/High, MJPEG |
| Smart Codec | Manual (5ea area), WiseStreamⅡ |
| Bitrate Control | H.264/H.265: CBR or VBR MJPEG: VBR |
| Streaming | Unicast (6 users) / Multicast Multiple streaming (Up to 3 profiles) |
| Protocol | IPv4, IPv6, TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3 (MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP |
| Security | HTTPS (SSL) Login Authentication, Digest Login Authentication, IP Address Filtering, User access Log, 802.1X Authentication |
| Application Programming Interface | ONVIF Profile S/G/T, SUNAPI (HTTP API) |
| General | |
| Webpage Language | English |
| Edge Storage | Micro SD/SDHC/SDXC 1 slot 128GB |
| Memory | 512MB RAM, 256MB Flash |
| Environmental & Electrical | |
| Operating Temperature / Humidity | -30°C ~ +55°C (-22°F ~ +131°F) / Less than 95% RH * Start up should be done at above -20°C (-4°F) |
| Storage Temperature / Humidity | -30°C ~ +55°C (-22°F ~ +131°F) / Less than 95% RH |
| Certification | IP66, IK10 |
| Input Voltage | PoE (IEEE802.3af, Class3) |
| Power Consumption | Max 8.0W, typical 6.0W |
| Mechanical | |
| Color / Material | White / Plastic, Aluminum |
| Dimensions | Ø149.0 x 118.0mm (Ø5.87" x 4.65") |
| Weight | 640g (1.41 lb) |
