Hanwha Vision CT-SCV-6023RP Wisenet HD+ / 1080p Full HD IR Vandal Camera
1080p Full-HD IR Vandal-Resistant Camera
The SCV-6023R boasts a rugged housing that meets stringent standards for impact resistance, safeguarding it against vandalism and harsh environments. Additionally, it incorporates advanced image processing technologies to enhance low-light performance and reduce noise. The camera supports various mounting options, allowing for flexible installation in diverse settings. It includes adjustable settings for optimal performance, including customizable IR range and image enhancement features. This model also integrates seamlessly with existing security systems, providing versatile connectivity and compatibility.
Key Features
- Resolution: 1080p @ AHD (Default)
- Illumination: 0.25Lux@F2.1 (Color), 0Lux@F2.1 (B/W: IR LED on)
- Output: Composite Video Output (Switchable)
- Lens: 4mm Fixed Lens
- Features: Day & Night (ICR), DWDR, SSNRIV, Motion Detection
- Built-in IR: Yes
- Protection: IP66/IK10
- Power Supply: 12VDC Only
Code/SKU: SCV-6023R
Quick Specs:
- Privacy Masking: 4 rectangular zones
- Gain Control: Low / Mid / High
- White Balance: ATW / AWC / Manual / Indoor / Outdoor
Need help choosing?
Click to ask a question - same day response (~2 hours during business hours)
Product Overview
The Hanwha Vision SCV-6023R is a high-performance 1080p Full-HD IR vandal-resistant camera designed to deliver exceptional video quality even in challenging conditions. With its full high-definition resolution, it ensures clear and detailed images for enhanced surveillance. The camera features infrared (IR) technology that allows it to capture clear footage in complete darkness, providing 24/7 monitoring capabilities. Its vandal-resistant design ensures durability and reliability, making it suitable for both indoor and outdoor applications where physical tampering is a concern. The SCV-6023R boasts a rugged housing that meets stringent standards for impact resistance, safeguarding it against vandalism and harsh environments. Additionally, it incorporates advanced image processing technologies to enhance low-light performance and reduce noise. The camera supports various mounting options, allowing for flexible installation in diverse settings. It includes adjustable settings for optimal performance, including customizable IR range and image enhancement features.
This model also integrates seamlessly with existing security systems, providing versatile connectivity and compatibility. Its weatherproof construction ensures reliable operation in various climatic conditions, from rain to extreme temperatures. The SCV-6023R’s user-friendly interface simplifies configuration and management, offering a straightforward setup process. It is equipped with a high-quality lens that delivers sharp and accurate video, contributing to effective monitoring and evidence collection. For enhanced security, the camera includes features like motion detection and alarm triggering. Its robust design and advanced functionalities make it an ideal choice for securing sensitive areas and high-risk locations. Overall, the SCV-6023R provides a comprehensive solution for reliable, high-quality surveillance with added protection against tampering and environmental factors.
Features
- High-Resolution Imaging: Offers clear and detailed images with its high-resolution capabilities.
- Advanced IR Technology: Equipped with Infrared LEDs for excellent night vision up to 50 meters.
- Wide Dynamic Range (WDR): Provides clear images even in challenging lighting conditions.
- Weatherproof Design: Suitable for outdoor use with IP66 rating for protection against dust and water.
- Built-In Microphone: Includes audio recording capability for enhanced surveillance.
- Motion Detection: Intelligent motion detection to alert you of any suspicious activity.
- Onvif Compliance: Ensures compatibility with a wide range of third-party systems and devices.
- Digital Noise Reduction (DNR): Reduces image noise for clearer video quality.
Specifications
- Image Sensor: 1/2.8” CMOS
- Resolution: 2MP (1080p)
- Lens: 3.6mm Fixed Lens
- IR Range: Up to 50 meters
- WDR: True WDR 120dB
- Weatherproof Rating: IP66
- Audio: Built-in Microphone
- Video Compression: H.265/H.264
- Power Supply: 12V DC
- Dimensions: 94.2 x 94.2 x 152.1 mm
- Weight: 0.82 kg
| Feature | Specification |
|---|---|
| Imaging Device | 1/3" 2MP CMOS |
| Effective Pixels | 1944(H)x1092(V) |
| NETD | None |
| Pixel Size | None |
| Min. Illumination | Color: 0.25Lux(F2.1) BW: 0.0Lux(IR LED on) |
| Video Out | BNC(AHD / CVBS selectable) |
Key Features
Trusted Brand Partner & Security Equipment Wholesaler
- Authorised Brand Partner with Responsive & Fast Aussie Sales Support Team ★★★★★
- Best After-Sales Support and Troubleshooting Team with Years of Installation Experience.
What This Product Does
1080p Full-HD IR Vandal-Resistant Camera
The SCV-6023R boasts a rugged housing that meets stringent standards for impact resistance, safeguarding it against vandalism and harsh environments. Additionally, it incorporates advanced image processing technologies to enhance low-light performance and reduce noise. The camera supports various mounting options, allowing for flexible installation in diverse settings. It includes adjustable settings for optimal performance, including customizable IR range and image enhancement features. This model also integrates seamlessly with existing security systems, providing versatile connectivity and compatibility.
Key Features
- Resolution: 1080p @ AHD (Default)
- Illumination: 0.25Lux@F2.1 (Color), 0Lux@F2.1 (B/W: IR LED on)
- Output: Composite Video Output (Switchable)
- Lens: 4mm Fixed Lens
- Features: Day & Night (ICR), DWDR, SSNRIV, Motion Detection
- Built-in IR: Yes
- Protection: IP66/IK10
- Power Supply: 12VDC Only
Code/SKU: SCV-6023R
Quick Specs:
- Privacy Masking: 4 rectangular zones
- Gain Control: Low / Mid / High
- White Balance: ATW / AWC / Manual / Indoor / Outdoor
Not sure if this suits your site?
Ask our team before ordering. We can help confirm lens choice, recorder compatibility, mounting accessories and project quantities.
Specifications
Specifications
| Feature | Specification |
|---|---|
| Imaging Device | 1/3" 2MP CMOS |
| Effective Pixels | 1944(H)x1092(V) |
| NETD | None |
| Pixel Size | None |
| Min. Illumination | Color: 0.25Lux(F2.1) BW: 0.0Lux(IR LED on) |
| Video Out | BNC(AHD / CVBS selectable) |
| Feature | Specification |
|---|---|
| Focal Length (Zoom Ratio) | 4mm fixed focal |
| Max. Aperture Ratio | F2.1 |
| Angular Field of View | H: 80.7° / V: 43.5° / D: 95.8° |
| Min. Object Distance | 0.5m (1.64ft) |
| Focus Control | Manual |
| Lens Type | None |
| Mount Type | None |
| Optional Lens | None |
| Feature | Specification |
|---|---|
| Pan / Tilt / Rotate Range | 0°~350° / 0°~67° / 0°~355° |
| Pan Range | None |
| Pan Speed | None |
| Tilt Range | None |
| Tilt Speed | None |
| Rotate Range | None |
| Sequence | None |
| Preset Accuracy | None |
| Azimuth | None |
| Auto Tracking | None |
| Feature | Specification |
|---|---|
| IR Viewable Length | 20m (65.62ft) |
| Camera Title | Displayed up to 15 characters |
| Day & Night | Auto (ICR) |
| Backlight Compensation | User BLC, HLC, DWDR |
| Wide Dynamic Range | None |
| Digital Noise Reduction | SSNRIII |
| Digital Image Stabilization | None |
| Defog | Support |
| Motion Detection | 4ea |
| Privacy Masking | 4ea, rectangular zones |
| Gain Control | Low / Mid / High |
| White Balance | ATW / AWC / Manual / Indoor / Outdoor |
| LDC | None |
| Electronic Shutter Speed | 1 ~ 1/12,000 sec |
| Digital PTZ | None |
| Video Rotation | H-Rev / V-Rev |
| Analytics | Motion detection |
| Business Intelligence | None |
| Serial Interface | None |
| Alarm I/O | None |
| Alarm Triggers | None |
| Alarm Events | None |
| Audio In | None |
| Audio Out | None |
| IR Illuminator (Optional) | None |
| Wiper | None |
| Coaxial Protocol | ACP (AHD Coax Protocol) CVBS: Pelco-C (Coaxitron) |
| Video Transmission Distance | 500m (75-5 coaxial cable) |
| Feature | Specification |
|---|---|
| Temperature Detect Range | None |
| Temperature Accuracy | None |
| Temperature Detection | None |
| Additional | None |
| Feature | Specification |
|---|---|
| Ethernet | None |
| Video Compression | None |
| Resolution | 1920x1080 |
| Max. Framerate | 30fps |
| Smart Codec | None |
| Video Quality Adjustment | None |
| Bitrate Control | None |
| Streaming | None |
| Audio Compression | None |
| Protocol | None |
| Security | None |
| Edge Storage | None |
| Application Programming Interface | None |
| Webpage Language | None |
| Web Viewer | None |
| Memory | None |
| Feature | Specification |
|---|---|
| Operating Temperature / Humidity | -30°C ~ +55°C (-22°F ~ +131°F) / Less than 90% RH *Start up should be done at above -10°C (+14°F) |
| Storage Temperature / Humidity | None |
| Certification | IP66, IK10, Safety (UL), EMC (FCC, CE) |
| Feature | Specification |
|---|---|
| Input Voltage | 12VDC |
| Power Consumption | Max 4.2W |
| Feature | Specification |
|---|---|
| Color / Material | Ivory / Aluminum |
| RAL Code | None |
| Product Dimensions / Weight | 137.0x94.0mm (5.39x3.7"), 560g (1.23 lb) |
| Conduit Hole | None |
| Hanging Mount (Dome) | SBP-301HM5 |
| Skin Cover (Dome) | SPB-VAN4 |
| Weather Cap (Dome) | None |
| Power Module | None |
| Backbox | SBV-136B |
