Dahua DHI-ARM320-W2 Wireless Input Expander

Model: DHI-ARM320-W2

Who This Is For

Property managers specifying Dahua wireless alarm systems who need to connect existing third-party wired sensors to a Dahua wireless hub without replacing the sensors themselves. The DHI-ARM320-W2 Wireless Input Expander bridges wired detection hardware - door contacts, PIR sensors, smoke detectors, gas detectors - into a Dahua wireless alarm network, accepting 1 alarm input and 1 anti-tamper input. It suits integrators retrofitting older wired sensor installations into a new Dahua wireless hub setup, alarm technicians building multi-zone systems where sensors are already cabled in place, and installers who need a battery-powered device in locations where mains power is unavailable. With up to 1300 m wireless range in open space and up to 5 years of battery life from 3 CR123A cells, it fits both residential and light commercial alarm projects where extending hub coverage without additional cabling runs is the priority.

What This Device Actually Does

Who Buys This Model

• Alarm Installers Retrofitting Wired Sensors: Where a site already has wired door contacts or PIR sensors cabled in, the DHI-ARM320-W2 allows those sensors to integrate into a new Dahua wireless hub without ripping out the existing cabling.
• Integrators Extending Hub Coverage: When a Dahua wireless hub doesn't reach a distant zone directly, this expander adds a relay point with up to 1300 m open-space range, bringing outlying sensors into the network.
• Commercial Fit-Out Contractors: Installers specifying multi-alarm type coverage - including gas, fire, and medical - across a single wireless alarm project benefit from the expander's ability to pass different alarm classifications from a single connected sensor.
• Property Managers with Power-Limited Locations: In areas where running a mains cable to a sensor location isn't practical, the up-to-5-year battery life from 3 CR123A cells means the expander operates independently for extended periods between maintenance visits.

Honest Assessment

The DHI-ARM320-W2 does a specific job well: it converts a wired sensor signal into a wireless transmission for a Dahua hub. The 1300 m open-space range, 5-year battery life, encrypted two-way communication, and frequency hopping make it a capable and low-maintenance addition to a Dahua wireless alarm system. The built-in tamper detection via the triaxial accelerometer is a meaningful security feature for devices installed in accessible or exposed locations. Cloud-based firmware updates remove the need for on-site software maintenance after installation. Available through Security Australia, it suits projects where the sensor infrastructure is already in place and only the wireless transmission layer needs to be added. Where this device is not the answer is if you need multiple alarm inputs per expander - this model supports 1 alarm input only, so a site with several sensor zones at a single location will need multiple units or a different expander model. It also requires an existing compatible Dahua wireless hub - it does not function as a standalone alarm controller.

Before You Buy

Quick Fit Check

• Good match if: You have an existing wired sensor in a location without practical cable access to the hub and need to integrate it wirelessly into a Dahua alarm system - the 1 alarm input with encrypted two-way wireless handles exactly this scenario.
• Good match if: The installation point lacks mains power and a long service interval is required - up to 5 years of battery operation from 3 CR123A cells suits low-traffic detection zones where battery changes need to be infrequent.
• You may need a different model if: You need to connect multiple sensor inputs per device at a single location - a multi-input wireless expander from the Dahua alarm accessories range would be more suited to that application.

Key Features & Technical Specifications

Real-World Scenarios

How It Compares

• Choose this if: You need to connect a single wired third-party sensor to a Dahua wireless hub and the location either has no mains power or a direct cable run to the hub is impractical - the battery operation and 1300 m wireless range make it a self-contained solution.
• You may need a different model if: You need to connect several wired sensor inputs from one location - a multi-input wireless expander from the Dahua alarm range would reduce device count and simplify installation at sensor-dense locations.
• Pairs well with: A compatible Dahua wireless alarm hub and a Dahua wireless alarm panel or controller - the expander functions as part of that broader system architecture and requires a hub to operate.

Common Questions

1. Does the DHI-ARM320-W2 work as a standalone alarm device?

   No. The DHI-ARM320-W2 requires a compatible Dahua wireless hub to function - it is an expander, not a standalone controller. It transmits sensor signals wirelessly to the hub, which then processes and acts on those signals. Without a connected hub, the device has no output path for alarm events.

2. How many sensors can I connect to a single DHI-ARM320-W2?

   1 alarm input sensor only. The device has 2 inputs in total - 1 is allocated to the alarm signal from your sensor and 1 is dedicated to the anti-tamper circuit. If you have multiple sensors at a single location, you will need 1 expander per sensor.

3. Will this work for a third-party smoke detector or gas sensor?

   Yes, provided the third-party sensor has a relay or open/closed contact output. The DHI-ARM320-W2 accepts a wired contact input and transmits the signal classified as the alarm type configured - including fire and gas categories. It does not read analogue sensor values; it reads the switched contact state.

4. What is the actual wireless range I should plan for inside a building?

   The confirmed 1300 m range applies in open space with no obstructions. Inside buildings, walls, floors, and metal structures reduce this significantly. Masonry or concrete walls typically reduce effective range by 50-70%. Plan your installation with test mode active before finalising mounting positions, and consider that repeaters or additional hubs may be needed across multi-storey or heavily partitioned sites.

5. How does the frequency hopping protect against interference?

   Frequency hopping causes the device to automatically shift its transmission frequency across a range of channels rather than staying fixed on one. If another wireless device - such as a Wi-Fi router, neighbouring alarm system, or RF remote - is transmitting on the same frequency, the expander moves away from that channel, maintaining communication with the hub without requiring any manual reconfiguration.

6. Does the device notify me when the battery is getting low?

   Yes. When battery charge drops below the monitoring threshold, the DHI-ARM320-W2 sends a low battery alert to the hub. This alert surfaces in the system so maintenance can be scheduled before the device loses operation. The confirmed battery life is up to 5 years from 3 CR123A cells under normal operating conditions, though high sensor activity will reduce this. The product is part of the Security Australia range of Dahua alarm accessories.

7. Can I hard-wire the device to mains power instead of using batteries?

   Yes. The DHI-ARM320-W2 supports an external power supply as an alternative to the 3x CR123A battery configuration. If the installation point has accessible DC power, using the external supply option removes the need for periodic battery replacement entirely and is the preferred choice for permanent commercial deployments where maintenance access is limited.
