5MP Lite IR Fixed-focal Eyeball Network Camera
With upgraded H.265 encoding technology, Dahua Lite series camera has efficient video encoding capacity, which saves bandwidth and storage space. This camera adopts the latest starlight technology and displays better colorful image in the environment of low illumination. It supports SD card storage, waterproof function, dust-proof function, complying to the standards of IP67.
Key Features
Code/SKU: DH-IPC-HDW2531EM-AS-S2
Quick Specs:
| Camera |
| |||||||||||||
| Image Sensor | 1/2.7” 5Megapixel progressive CMOS |
| ||||||||||||
| Max. Resolution | 2592 (H) × 1944 (V) |
| ||||||||||||
| ROM | 128 MB |
| ||||||||||||
| RAM | 256 MB |
| ||||||||||||
| Scanning System | Progressive |
| ||||||||||||
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100000 s |
| ||||||||||||
| S/N Ratio | 0.008 Lux @ F1.6 |
| ||||||||||||
| Min. Illumination | > 56 dB |
| ||||||||||||
| Illumination Distance | 30 m (98.43 ft) |
| ||||||||||||
| Illuminator On/Off Control | Auto/Manual |
| ||||||||||||
| Illuminator Number | 2 (IR LED) |
| ||||||||||||
| Pan/Tilt/Rotation Range | Pan: 0°–360° Tilt: 0°–78° Rotation: 0°–360° |
| ||||||||||||
| Lens |
| |||||||||||||
| Lens Type | Fixed-focal |
| ||||||||||||
| Mount Type | M12 |
| ||||||||||||
| Focal Length | 2.8 mm 3.6 mm |
| ||||||||||||
| Max. Aperture | F1.6 F1.6 |
| ||||||||||||
| Field of View | 2.8 mm: Horizontal 103° × Vertical 71° × Diagonal 132° 3.6 mm: Horizontal 84° × Vertical 58° × Diagonal 110° |
| ||||||||||||
| Iris Type | Fixed |
| ||||||||||||
| Close Focus Distance | 2.8 mm: 0.9 m (2.95 ft) 3.6 mm: 1.6 m (3.61 ft) |
| ||||||||||||
| DORI Distance | Lens | Detect | Observe | Recognize | Identify |
| ||||||||
| 2.8 mm | 56 m (183.73 ft) | 22.4 m (73.49 ft) | 11.2 m (36.75 ft) | 5.6 m (18.37 ft) |
| |||||||||
| 3.6 mm | 80 m (262.47 ft) | 32.0 m (104.99 ft) | 16.0 m (52.49 ft) | 8.0 m (26.25 ft) |
| |||||||||
| Smart event |
| |||||||||||||
| General IVS Analytics | Tripwire; intrusion |
| ||||||||||||
| Video |
| |||||||||||||
| Video Compression | H.265; H.264; H.264B; MJPEG (only supported by the sub stream) |
| ||||||||||||
| Smart Codec | Smart H.265+/ Smart H.264+ |
| ||||||||||||
| Video Frame Rate | Main stream: 2592 × 1944 (1 fps–20 fps) 2688 × 1520 (1 fps–25/30 fps) Sub stream: 704 × 576 (1 fps–25 fps) 704 × 480 (1 fps–30 fps) |
| ||||||||||||
| Stream Capability | 2 streams |
| ||||||||||||
| Resolution | 2592×1944(2592×1944); 2688×1520(2688×1520); 3M(2048×1536); 2304×1296(2304×1296); 1080p(1920×1080); 1.3M (1280 × 960); 720p(1280×720); D1(704× 576/704×480); VGA(640×480); CIF(352×288/352×240) |
| ||||||||||||
| Bit Rate Control | CBR/VBR |
| ||||||||||||
| Video Bit Rate | H.264: 32 kbps–8192 kbps H.265: 12 kbps–8192 kbps |
| ||||||||||||
| Day/Night | Auto(ICR)/Color/B/W |
| ||||||||||||
| BLC | Yes |
| ||||||||||||
| HLC | Yes |
| ||||||||||||
| WDR | 120 dB |
| ||||||||||||
| White Balance | Auto/natural/street lamp/outdoor/manual/regional custom |
| ||||||||||||
| Gain Control | Auto/Manual |
| ||||||||||||
| Noise Reduction | 3D DNR |
| ||||||||||||
| Motion Detection | OFF/ON (4 areas, rectangular) |
| ||||||||||||
| Region of Interest(RoI) | Yes (4 areas) |
| ||||||||||||
| Smart Illumination | Yes |
| ||||||||||||
| Image Rotation | 0°/90°/180°/270° (Supports 90°/270° with 2592 × 1944 resolution and lower.) |
| ||||||||||||
| Mirror | Yes |
| ||||||||||||
| Privacy Masking | 4 areas |
| ||||||||||||
| Audio | ||||||||||||||
| Built-in MIC | Yes | |||||||||||||
| Audio Compression | G.711A; G.711Mu; G.726; AAC | |||||||||||||
| Alarm | ||||||||||||||
| Alarm Event | No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; security exception | |||||||||||||
| Network | ||||||||||||||
| Network | RJ-45 (10/100 Base-T) | |||||||||||||
| SDK and API | Yes | |||||||||||||
| Protocol | IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; Bonjour | |||||||||||||
| Interoperability | ONVIF(Profile S/Profile G/Profile T);CGI; P2P; Milestone; Genetec | |||||||||||||
| User/Host | 20 | |||||||||||||
| Storage | Dahua Cloud; FTP; SFTP; Micro SD Card (support max. 256 GB); NAS | |||||||||||||
| Browser | IE Chrome Firefox | |||||||||||||
| Management Software | Smart PSS; DSS; DMSS | |||||||||||||
| Mobile Phone | IOS; Android | |||||||||||||
| Certifications | CE-LVD: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 | |||||||||||||
| Power |
| |||||||||||||
| Power Supply | 12V DC/PoE (802.3af) |
| ||||||||||||
| Power Consumption | < 7.2W |
| ||||||||||||
| Environment |
| |||||||||||||
| Operating Conditions | –40°C to +60°C (–40°F to +140°F)/less than ≤ 95% |
| ||||||||||||
| Storage Temperature | –40°C to +60°C (–40°F to +140°F) |
| ||||||||||||
| Protection Grade | IP67 |
| ||||||||||||
| Structure |
| |||||||||||||
| Casing | Metal |
| ||||||||||||
| Dimensions | 93.6 mm × Φ106 mm (3.7" × Φ4.2") |
| ||||||||||||
| Net Weight | 530 g (1.1 lb) |
| ||||||||||||
| Gross Weight | 800 g (1.7 lb) | |||||||||||||
All IP cameras and recording devices (NVR’s/DVR’s) are covered by a 3 year back-to-base manufacturer warranty.
Our warranty is limited to the replacement of faulty items or parts and does not include damage due to incorrect fitting of parts or accessories, or damage due to mishandling the equipment once out of the box. All faults are sent to the manufacturer for inspection and diagnosis before a replacement is sent out.
Read more about the Terms & Conditions here – https://www.securityaustralia.com.au/terms-and-conditions/
*Just spend over $100 to activate Fast Free Shipping!
Despatch Times: Products are despatched on the same day if the order was placed before 11am on any weekday, Monday - Friday. All other orders are processed and despatched within 24 hours or next business day.
Order Confirmation: Once you place an order, you will receive a confirmation email. This indicates that your order has been received in our system and is now being processed for dispatch. If your item is back-ordered or unavailable, we will notify you via email, and if we do not receive a response, we will attempt to contact you by phone as soon as possible. We value your time and strive to be prompt. If your item(s) are available for immediate shipment (within 2 days), we will process the charges and prepare the order for shipping.
Shipping Times: General shipping times for StarTrack, TNT and Allied couriers are between 1-3 working days from despatch. Longer delivery times may be caused by your package being held at your local courier depot that is beyond our control. Please contact us or the local post depot for confirmation.
Tracking Numbers: all tracking numbers will be emailed to you by our warehouse processing team within the day, after your order is despatched to our local courier.
Dahua DH-IPC-HDW2531EMP-AS-0280B-S2-AUS 5MP Starlight IP 30m IR Turret Camera
The 5MP Lite IR Fixed-focal Eyeball Network Camera DH-IPC-HDW2531EM-AS-S2 from Dahua Security offers high-quality video performance with its 5MP resolution, providing clear and detailed images. It features Smart IR technology, ensuring optimal illumination in low-light conditions by automatically adjusting the intensity of the infrared LEDs. The camera is equipped with a fixed-focal lens, making it ideal for consistent, focused surveillance in specific areas. Its compact design allows for easy installation, and the IP67 rating guarantees protection against water and dust, making it suitable for both indoor and outdoor environments. The camera supports H.265 video compression, which reduces bandwidth and storage requirements without compromising image quality. Additionally, it includes intelligent detection functions like motion detection and intrusion detection, enhancing its security capabilities. The camera is equipped with a built-in microphone for audio recording, adding another layer of security.
With its 120dB true WDR (Wide Dynamic Range) technology, the camera performs well in challenging lighting conditions, balancing the exposure to deliver clear images. The DH-IPC-HDW2531EM-AS-S2 also supports Power over Ethernet (PoE), simplifying installation by allowing power and data to be transmitted over a single cable. This camera is part of Dahua's Lite Series, offering a cost-effective solution without sacrificing essential features. It is compatible with various NVRs and software, ensuring seamless integration into existing surveillance systems. Overall, this camera is a reliable and efficient choice for various security applications.
Features
Functions
Smart H.265+ & Smart H.264+ Dahua's advanced scene-adaptive rate control algorithm enhances encoding efficiency beyond traditional H.265 and H.264, delivering high-quality video while minimizing storage and transmission costs.
WDR (Wide Dynamic Range) Equipped with advanced Wide Dynamic Range (WDR) technology, Dahua network cameras capture clear details even in environments with high contrast between bright and dark areas, ensuring visibility even under intense lighting or backlight conditions.
Starlight Dahua's Starlight technology is designed for low-light environments, providing clear and colorful video even in extremely low illuminance, ensuring superior image quality.
IVS (Intelligent Video System) Dahua's Intelligent Video System (IVS) technology utilizes advanced video algorithms to support smart features like tripwire detection and intrusion alerts.
Protection (IP67, Wide Voltage) IP67: The camera undergoes rigorous testing to ensure dust resistance and can operate normally after being submerged in 1 meter of water for 30 minutes.
Wide Voltage: The camera supports a wide input voltage range of ±30%, making it suitable for outdoor environments with unstable power supply.
|
Camera |
|
|||||||||||||
|
Image Sensor |
1/2.7” 5Megapixel progressive CMOS |
|
||||||||||||
|
Max. Resolution |
2592 (H) × 1944 (V) |
|
||||||||||||
|
ROM |
128 MB |
|
||||||||||||
|
RAM |
256 MB |
|
||||||||||||
|
Scanning System |
Progressive |
|
||||||||||||
|
Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100000 s |
|
||||||||||||
|
S/N Ratio |
0.008 Lux @ F1.6 |
|
||||||||||||
|
Min. Illumination |
> 56 dB |
|
||||||||||||
|
Illumination Distance |
30 m (98.43 ft) |
|
||||||||||||
|
Illuminator On/Off Control |
Auto/Manual |
|
||||||||||||
|
Illuminator Number |
2 (IR LED) |
|
||||||||||||
|
Pan/Tilt/Rotation Range |
Pan: 0°–360° Tilt: 0°–78° Rotation: 0°–360° |
|
||||||||||||
|
Lens |
|
|||||||||||||
|
Lens Type |
Fixed-focal |
|
||||||||||||
|
Mount Type |
M12 |
|
||||||||||||
|
Focal Length |
2.8 mm 3.6 mm |
|
||||||||||||
|
Max. Aperture |
F1.6 F1.6 |
|
||||||||||||
|
Field of View |
2.8 mm: Horizontal 103° × Vertical 71° × Diagonal 132° 3.6 mm: Horizontal 84° × Vertical 58° × Diagonal 110° |
|
||||||||||||
|
Iris Type |
Fixed |
|
||||||||||||
|
Close Focus Distance |
2.8 mm: 0.9 m (2.95 ft) 3.6 mm: 1.6 m (3.61 ft) |
|
||||||||||||
|
DORI Distance |
Lens |
Detect |
Observe |
Recognize |
Identify |
|
||||||||
|
2.8 mm |
56 m (183.73 ft) |
22.4 m (73.49 ft) |
11.2 m (36.75 ft) |
5.6 m (18.37 ft) |
|
|||||||||
|
3.6 mm |
80 m (262.47 ft) |
32.0 m (104.99 ft) |
16.0 m (52.49 ft) |
8.0 m (26.25 ft) |
||||||||||
