Dahua DH-HAC-HFW2501TUP-A 5MP Starlight Pro HDCVI IR Bullet,WDR,ICR,3.6mm,IR 80m

Model: DH-HAC-HFW2501TUP-A

Who This Is For

For installers and site owners who need strong outdoor coverage on an existing HDCVI infrastructure without replacing recorders or cabling, the Dahua DH-HAC-HFW2501TUP-A delivers 5MP Starlight Pro imaging with 80m IR reach over a standard coax run. This is an analog HD bullet designed for open-air environments - driveways, yard perimeters, car parks, loading areas, and building approaches - where a visible camera with genuine low-light performance matters more than a covert profile. The 3.6mm fixed lens suits medium-distance coverage of wide open spaces up to roughly 10-15 metres across, and the built-in microphone supports audio recording where local regulations permit. WDR and ICR handle the shift between bright daylight and full darkness automatically, making this a practical choice for sites that run 24 hours or deal with harsh backlighting from headlights and roller door lighting.

What This Camera Actually Does

Who Buys This Model

• Analog HD upgrade projects: Sites with existing RG59 or RG6 coax infrastructure and a compatible HDCVI recorder looking to move from 2MP to 5MP without a full rewire.
• Small industrial and commercial properties: Warehouses, trade yards, and light industrial sites needing a rugged outdoor bullet with 80m night coverage over long approaches and open perimeters.
• Car park and driveway monitoring: Applications where WDR is needed to handle headlight glare or strong backlight at entry and exit points, combined with 5MP detail for vehicle identification.
• Rural and semi-rural properties: Properties with long unlit driveway runs where 80m IR reach covers the full approach distance from a single mounted position.

Honest Assessment

The DH-HAC-HFW2501TUP-A does two things particularly well: it makes an existing HDCVI coax installation meaningfully better without a cabling overhaul, and it delivers genuine low-light performance at 80 metres through the combination of Starlight Pro sensitivity and long-range IR. The 5MP resolution gives forensic headroom compared to older 1080p analog installs. WDR handling is a real-world benefit on sites with uncontrolled lighting. What this camera will not do is provide AI-based perimeter alerts, smart detection classification, or the network flexibility of an IP camera. The fixed 3.6mm lens limits its use to medium-wide coverage - it is not suited to long-distance face or plate identification. If your site requires active deterrence, two-way audio, or AI event filtering, a TiOC or AI-enabled IP bullet from the Security Australia range would be a more capable fit.

Before You Buy

Quick Fit Check

• Good match if: You have an existing HDCVI coax system and want to upgrade individual cameras to 5MP resolution without relaying cable runs.
• Good match if: Your site has long unlit outdoor approaches - driveways, yard perimeters, loading areas - where 80m IR reach with Starlight Pro low-light performance is the primary requirement.
• You may need a different model if: Your installation is new build or IP-ready - an IP bullet camera with AI detection, PoE connectivity, and smart event alerts will give you more capability and future flexibility on a fresh Cat6 run.

Key Features & Technical Specifications

Real-World Scenarios

How It Compares

• Choose this if: You are working with an existing HDCVI coax infrastructure and need a 5MP outdoor bullet with genuine Starlight Pro low-light performance and 80m IR - the coax reuse avoids rewiring costs entirely.
• You may need a different model if: Your site requires AI-based detection, smart motion classification, or active deterrence features - an AI-enabled IP bullet camera will deliver those capabilities on a Cat6 run and is worth specifying on any new installation.
• Pairs well with: A Dahua 5MP-compatible HDCVI recorder with audio input channels enabled, and a 12V DC multi-zone power distribution board for clean cable management.

Common Questions

1. Will this camera work with my existing HDCVI recorder?

   It depends on your recorder's channel capability. The DH-HAC-HFW2501TUP-A outputs a 5MP HDCVI signal, which requires a recorder with 5MP HDCVI channel support. Older HDCVI recorders may only support 1080p or 4MP channels. Check your recorder's specification sheet - some Dahua recorders support 5MP via a firmware update, but this must be confirmed for your specific model before purchasing.

2. Does this camera record audio?

   Yes, it records audio input. The "A" model designation confirms a built-in microphone. Audio is transmitted over the coax cable to a compatible recorder with audio input channels. It does not include a built-in speaker, so this is audio recording only - not two-way communication. Always confirm your local state and territory audio recording laws before enabling audio capture.

3. How far does the night vision actually reach?

   The IR illuminators are rated to 80 metres. In practice, usable detection detail typically extends the full 80m under clear conditions, though reflective surfaces, fog, and heavy rain reduce effective range. The Starlight Pro sensor also produces detail at low light before IR becomes the sole source, which improves early-evening image quality in partially lit environments.

4. Will this camera handle direct headlight glare at a car park entry?

   Yes, within the limits of its WDR capability. WDR balances bright and dark zones in the same frame, which directly addresses headlight glare scenarios at entry points. At 5MP, there is also sufficient pixel density to capture usable vehicle detail even in high-contrast lighting. For dedicated ANPR (automatic number plate recognition), a purpose-built ANPR camera is a more accurate solution, but for general vehicle monitoring this camera handles typical entry lighting well.

5. What cable does this camera run on?

   It runs on standard RG59 or RG6 coaxial cable - the same cable used in most HDCVI, HDTVI, and AHD analog HD installations. Power is supplied separately via 12V DC, typically run alongside the coax. The audio signal from the built-in microphone is also transmitted over the coax to a compatible recorder. No Cat6 or network infrastructure is required.

6. Is the 3.6mm lens suitable for identifying faces or number plates?

   At close to medium range, yes - with caveats. The 3.6mm lens produces a wide field of view suitable for coverage of open spaces. At 5MP, subjects within 5-8 metres will provide enough pixel detail for reasonable facial identification. Number plate reading at speed or distance beyond 10 metres is not reliable with this lens - a varifocal or ANPR-specific camera is needed for precise plate capture. The available range through Security Australia includes dedicated options for those applications.

7. Is this camera weatherproof enough for outdoor use in Australia?

   Yes. The DH-HAC-HFW2501TUP-A carries an IP67 weather rating, meaning it is dust-tight and protected against water immersion up to 1 metre for 30 minutes. In practice this covers rain, hose-down cleaning, and outdoor coastal or industrial environments. For tropical areas with heavy sustained rainfall or direct high-pressure washdown, confirm your installation mount directs the cable entry downward to prevent water tracking into the housing.
