Dahua 8 x 6MP TIOC DH-IPC-HDW3649H-AS-PV-ANZ Turret Kit with 8CH AI NVR

$2,339.98 AUD
 per
Tax included.
Shipping calculated at checkout.
In stock!
Spend $100.00 to FREE SHIPPING

Free shipping - Enjoy free shipping when your order exceeds $100!

All orders are despatched within the next business day!

Best local support in Aus! We back all products with a 3 year manufacturer warranty.

Dahua 8CH 8 x 6MP Turret Kit

The Dahua 8CH 8 x 6MP Turret Kit is a comprehensive security solution featuring eight TiOC 2.0 Full Color turret cameras and a robust NVR, designed to enhance security with advanced AI features. This kit is suitable for medium to large installations requiring efficient monitoring and intelligent analytics.

Kit Includes:

  • 1 x 8-Channel 8 PoE Network Video Recorder
  • 8 x 6MP AI Active Deterrence Full Color Starlight IP Turret Cameras

Features:

  • TiOC 2.0 Full Color: Provides full-color video in low-light conditions, significantly enhancing night-time surveillance.
  • Built-in Mic & Speaker: Enables two-way audio for interactive communication and deterrence.
  • 2.8mm Fixed Lens: Offers a wide-angle view for extensive area coverage, ideal for monitoring large spaces.
  • Smart Motion Detection 4.0: Delivers highly accurate motion detection, minimizing false alarms and focusing on human and vehicle detection.
  • Active Deterrence Features: Integrates visual and auditory deterrence signals to warn potential intruders effectively.
  • AI-Powered Analytics: Supports advanced analytics like tripwire intrusion and missing object detection for enhanced security insights.

Code/SKU: DH-IPC-HDW3649H-AS-PV-ANZ

Quick Specs:

  • Camera Resolution: 6MP
  • Night Vision: Full color with starlight technology
  • Weatherproof Rating: IP67
  • Sound Level: Up to 110dB for alarms

Addons

Dahua DH-AC-PFA10...
$16.99 $17.00
Dahua DH-AC-PFB22...
$44.00 $65.00
4TB HDD - Surveil...
$156.00 $286.00
3TB HDD - Surveil...
$156.00 $209.00
6TB HDD - Purple ...
$300.00 $418.00

Specifications

Camera Specification
Camera
Image Sensor 1/2.7" CMOS
Max. Resolution 3200 (H) × 1800 (V)
ROM 128 MB
RAM 512 MB
Scanning System Progressive
Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s
Min. Illumination 0.003 lux@F1.0 (Color, 30 IRE)
0.0003 lux@F1.0 (B/W, 30 IRE)
0 lux (illuminator on)
S/N Ratio ﹥ 56 dB
Illumination Distance 30 m (98.43 ft) (IR)
30 m (98.43 ft) (warm light)
Illuminator On/Off Control Auto; manual
Illuminator Number 1 (IR LED)
1 (warm light)
Pan/Tilt/Rotation Range Pan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360°
Lens
Lens Type Fixed-focal
Mount Type M12
Focal Length 2.8 mm; 3.6 mm
Field of View 2.8 mm: H: 97°; V: 70°; D: 128°
3.6 mm: H: 78°; V: 58°; D: 102°
Iris Type Fixed
Close Focus Distance 2.8 mm: 1.5 m (4.92 ft)
3.6 mm: 2.2 m (7.22 ft)
DORI Distance Lens
DORI Distance 2.8 mm
Detect: 66.0 m (216.54 ft)
Observe: 26.4 m (86.61 ft)
Recognize: 13.2 m (43.31 ft)
Identify: 6.6 m (21.65 ft)
3.6 mm
Detect: 78.0 m (255.91 ft)
Observe: 31.2 m (102.36 ft)
Recognize: 15.6 m (51.18 ft)
Identify: 7.8 m (25.59 ft)
Intelligent
IVS (Perimeter Protection) Tripwire; intrusion (Support the classification and accurate detection of vehicle and human)
SMD 4.0 Less false alarm, longer detection distance
Smart Search Work together with Smart NVR to perform refined intelligent search, event extraction, and merging to event videos.
Quick Pick With AI NVR, quickly pick up the human/vehicle targets that users are interested in from SMD events.
AI SSA Adopt deep learning algorithms to adjust the parameters of the image to suit the conditions.
Video
Video Compression H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
Smart Codec Smart H.265+; Smart H.264+
AI Coding AI H.265; AI H.264
Video Frame Rate Main stream: 3200 × 1800@(1 fps–25/30 fps)
Sub stream: 704 × 576@(1 fps–25 fps)/704 × 480@(1 fps–30 fps)
Third stream: 1920 × 1080@(1 fps–25/30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
Stream Capability 3 streams
Resolution 6M (3200 × 1800); 5M (2880 × 1620); 4M (2688 × 1520/2560 × 1440);
3M (2304×1296/2048 × 1536); 1080P (1920×1080);
1.3M (1280 × 960); 720P (1280×720);
D1 (704× 576/704×480); VGA(640 × 480); CIF (352×288/352×240)
Bit Rate Control CBR/VBR
Video Bit Rate H.264: 32kbps–8192 kbps
H.265: 12kbps–8192 kbps
Day/Night
Day/Night Auto (ICR)/Color/B/W
BLC Yes
HLC Yes
WDR 120 dB
Scene Self-adaptation Yes
White Balance Auto; natural; street lamp; outdoor; manual; regional custom
Gain Control Auto; manual
Noise Reduction 3D NR
Motion Detection OFF/ON (4 areas)
Region of Interest (RoI) Yes (4 areas)
Smart Illumination Yes
Defog Yes
Image Rotation 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)
Mirror Yes
Privacy Masking 8 areas
Audio
Built-in MIC Yes
Audio Compression PCM; G.711a; G.711Mu; G.726; G.723
Alarm
Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene changing; audio detection; voltage detection; external alarm; SMD; security exception
Network
Network RJ-45 (10/100 Base-T)
SDK and API Yes
Cyber Security Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Protocol IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP
Interoperability ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; P2P; RTMP
User/Host 20 (Total bandwidth: 72 M)
Storage
Storage FTP; SFTP; Micro SD card (Support max. 256 G); NAS
Browser
IE IE8/9/11
Chrome
Firefox
Management Software
Smart PSS
DSS
DMSS
Mobile Phone
iOS
Android
Certification
Certification CE-LVD: EN 62368-1;
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU;
FCC: 47 CFR FCC Part 15, Subpart B;
UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14
Port
Audio Input 1 channel (RCA port)
Audio Output 1 channel (RCA port)
Alarm Input 1 channel in: 5 mA 3V–5 VDC
Alarm Output 1 channel out: 300 mA 12 VDC
Power
Power Supply 12 VDC/PoE (802.3af)
Power Consumption Basic: 3.7 W (12 VDC); 4.8 W (PoE)
Max. (pulling stream+warning light+speaker+warm light on): 8.3 W (DC12 V) 8.8 W (POE)
Environment
Operating Conditions –40 °C to +60 °C (–40 °F to +140 °F)/Less than 95% RH
Storage Conditions –40 °C to +60 °C (–40 °F to +140 °F)
Protection Grade IP67
Structure
Casing Metal
Dimensions 110.9 mm × Φ122.0 mm (4.37" × Φ4.80")
Net Weight 745 g (1.64 lb)
Gross Weight 915 g (2.02 lb)
Ordering Information
Type Model
6MP Camera DH-IPC-HDW3649H-AS-PV-ANZ
Description 6 MP Smart Dual Illumination Active Deterrence Fixed-focal Eyeball WizSense Network Camera
IPC-HDW3649H-AS-PV-ANZ
Accessories (Optional)
PFA137 Junction Box
PFB205W-E Wall Mount Bracket
PFA109 Mount Adapter
PFB220C Ceiling Mount Bracket
PFA152-E Pole Mount Bracket
PFM321D 12 VDC 1A Power Adapter
PFM900-E Integrated Mount Tester
TF-P100 MicroSD Memory Card

Documentation

3 Years Manufacturer Warranty

All IP cameras and recording devices (NVR’s/DVR’s) are covered by a 3 year back-to-base manufacturer warranty.

Our warranty is limited to the replacement of faulty items or parts and does not include damage due to incorrect fitting of parts or accessories, or damage due to mishandling the equipment once out of the box. All faults are sent to the manufacturer for inspection and diagnosis before a replacement is sent out.

Read more about the Terms & Conditions here – https://www.securityaustralia.com.au/terms-and-conditions/

Trusted Brand Partner & Security Equipment Wholesaler

Authorised Brand Partner with Responsive & Fast Aussie Sales Support Team ★★★★★
Best After-Sales Support and Troubleshooting Team with Years of Installation Experience.

Free Delivery* & Despatch Time

*Just spend over $100 to activate Fast Free Shipping!

Despatch Times: Products are despatched on the same day if the order was placed before 11am on any weekday, Monday - Friday. All other orders are processed and despatched within 24 hours or next business day.

Order Confirmation: Once you place an order, you will receive a confirmation email. This indicates that your order has been received in our system and is now being processed for dispatch. If your item is back-ordered or unavailable, we will notify you via email, and if we do not receive a response, we will attempt to contact you by phone as soon as possible. We value your time and strive to be prompt. If your item(s) are available for immediate shipment (within 2 days), we will process the charges and prepare the order for shipping.

Shipping Times: General shipping times for StarTrack, TNT and Allied couriers are between 1-3 working days from despatch. Longer delivery times may be caused by your package being held at your local courier depot that is beyond our control. Please contact us or the local post depot for confirmation.

Tracking Numbers: all tracking numbers will be emailed to you by our warehouse processing team within the day, after your order is despatched to our local courier.

View full details

Dahua 8 x 6MP TIOC DH-IPC-HDW3649H-AS-PV-ANZ Turret Kit with 8CH AI NVR

$2,339.98 AUD
 per

The Dahua 8 x 6MP TIOC DH-IPC-HDW3649H-AS-PV-ANZ Turret Kit is an advanced security solution that offers exceptional clarity and functionality for your surveillance needs. This comprehensive kit includes eight high-resolution 6MP turret cameras equipped with TIOC (Two-Way Audio, Intelligent Video Analytics, and Color at Night) technology, ensuring detailed imaging and intelligent monitoring capabilities day or night.

Paired with an 8-channel AI Network Video Recorder (NVR), this kit allows for seamless integration and management of all connected cameras. The advanced AI features enable smart motion detection and video analysis, providing enhanced situational awareness and making it easier to respond to potential threats.

Designed for durability and performance, the cameras feature an IP67 rating, ensuring they can withstand diverse outdoor conditions while delivering reliable monitoring. With its user-friendly setup and powerful capabilities, the Dahua 8 x 6MP TIOC Turret Kit with 8CH AI NVR is perfect for both residential and commercial applications, safeguarding your property with state-of-the-art technology.

Features:

  • Includes eight 6MP turret cameras offering high-resolution imaging for precise monitoring.
  • TIOC technology provides two-way audio communication and intelligent video analytics.
  • 8-channel AI NVR for easy management of multiple cameras, enhancing overall security.
  • IP67 rating ensures durable performance in various environmental conditions.
  • Night vision capabilities to ensure visibility in low-light situations.

Functions:

Intelligent Video Monitoring

Provides real-time video analysis for effective surveillance.

Remote Access

Manage and monitor your security system through mobile or web applications.

Two-Way Audio

Enables communication through the cameras, facilitating interaction and alerts.

Smart Alerts

Sends immediate notifications for detected movements or events.

Password Protection

Ensures the security of your recorded footage and system settings.

User Management

Allows multiple users to access and control the system effectively.

Expandable Setup

Add additional cameras as your security needs grow without hassle.

Technical Specifications

Model DH-IPC-HDW3649H-AS-PV-ANZ
Camera Resolution 6MP
Camera Type Turret Camera
NVR Capacity 8CH
NVR Type AI Network Video Recorder
