Dahua 8 x 5MP DH-IPC-HDW2431EMP Eyeball / Turret Kit 30m IR 2.8mm+ 8CH NVR + 2TB HDD

$1,450.00 AUD
 per
In stock!
Spend $100.00 to FREE SHIPPING

Dahua 5 MP + 8 Channels Kit is a comprehensive surveillance solution. It includes eight 5 MP Turret Network Camera, offering high-resolution video capture. The kit is paired with a 8-channel NVR, allowing for efficient video recording and management. This setup ensures robust security coverage for various environments.

Dahua Camera Kit includes:

8 x 5MP Lite IR Fixed-focal Eyeball Network Camera

With upgraded H.265 encoding technology, Dahua Lite series camera has efficient video encoding capacity, which saves bandwidth and storage space. This camera adopts the latest starlight technology and displays better colorful image in the environment of low illumination. It supports SD card storage, waterproof function, dust-proof function, complying to the standards of IP67.

Key Features

  • 5MP, 1/2.7” CMOS image sensor, low illuminance, high image definition
  • Outputs max. 5MP (2592 × 1944) @20 fps, and supports 2688 ×1520 (2688 × 1520) @25/30 fps
  • H.265 codec, high compression rate, ultra-low bit rate
  • Built-in IR LED, max IR distance: 30 m
  • ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
  • Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
  • Intelligent detection: Intrusion, tripwire
  • Abnormality detection: Motion detection, video tampering, no SD card, SD card full, SD card error, network disconnected, IP conflict, illegal access, voltage detection
  • Supports max. 256 GB Micro SD card, built-in MIC
  • 12V DC/PoE power supply
  • IP67 protection

Code/SKU: DH-IPC-HDW2531EM-AS-S2
Quick Specs:

  • Focal Length: 2.8 mm, 3.6 mm
  • Max. Aperture: F1.6, F1.6
  • Field of View:
    • 2.8 mm: Horizontal 103°, Vertical 71°, Diagonal 132°
    • 3.6 mm: Horizontal 84°, Vertical 58°, Diagonal 110°



1 x 8 Channel Compact 1HDD 1U 8PoE Network Video Recorder 2TB HDD

The 8 Channel Compact 1HDD 1U 8PoE Network Video Recorder, model DHI-NVR4108HS-8P-4KS2/L, from Dahua Security is a powerful and efficient surveillance solution designed for small to medium-sized installations. This NVR supports up to 8 IP cameras with a maximum resolution of 8MP, providing clear and detailed video footage. It features H.265+ video compression, significantly reducing storage and bandwidth requirements without compromising video quality.

Key Features

  • New 4.0 user interface, Security baseline 2.1
  • H.264, H.265, Smart H.264+, and Smart H.265+. H.265 auto switch
  • Max. decoding capability: 8 × 1080p@30 fps. Supports adaptive decoding
  • Supports mainstream cameras of ONVIF and RTSP protocols
  • P2P remote surveillance, video play on mobile device
  • VGA/HDMI simultaneous video output, maximum resolution of HDMI is 4K
  • AI by Camera: Face detection, perimeter protection, IVS, people counting, heat map, and SMD
  • Supports remote configuration and management of IPC, such as setting parameters, getting information, and upgrading IPC of the same model in batches

Code/SKU: DHI-NVR4108HS-8P-4KS2/L
Quick Specs: Main Processor: Industrial-grade embedded processor, OS: Embedded Linux, Operation Interface: Web/operating in local GUI

Specifications

Camera



Image Sensor

1/2.7” 5Megapixel progressive CMOS



Max. Resolution

2592 (H) × 1944 (V)



ROM

128 MB



RAM

256 MB



Scanning System

Progressive



Electronic Shutter Speed

Auto/Manual 1/3 s–1/100000 s



S/N Ratio

0.008 Lux @ F1.6



Min. Illumination

> 56 dB



Illumination Distance

30 m (98.43 ft)



Illuminator On/Off Control

Auto/Manual



Illuminator Number

2 (IR LED)



Pan/Tilt/Rotation Range

Pan: 0°–360° Tilt: 0°–78° Rotation: 0°–360°



Lens



Lens Type

Fixed-focal



Mount Type

M12



Focal Length

2.8 mm 3.6 mm



Max. Aperture

F1.6 F1.6



Field of View

2.8 mm: Horizontal 103° × Vertical 71° × Diagonal 132°

3.6 mm: Horizontal 84° × Vertical 58° × Diagonal 110°



Iris Type

Fixed



Close Focus Distance

2.8 mm: 0.9 m (2.95 ft) 3.6 mm: 1.6 m (3.61 ft)



DORI Distance

Lens

Detect

Observe

Recognize

Identify



2.8 mm

56 m (183.73 ft)

22.4 m

(73.49 ft)

11.2 m

(36.75 ft)

5.6 m

(18.37 ft)



3.6 mm

80 m (262.47 ft)

32.0 m (104.99 ft)

16.0 m

(52.49 ft)

8.0 m

(26.25 ft)



Smart event



General IVS Analytics

Tripwire; intrusion



Video



Video Compression

H.265; H.264; H.264B; MJPEG (only supported

by the sub stream)



Smart Codec

Smart H.265+/ Smart H.264+



Video Frame Rate

Main stream: 2592 × 1944 (1 fps–20 fps) 2688 × 1520 (1 fps–25/30 fps) Sub stream: 704 × 576 (1 fps–25 fps) 704 × 480 (1 fps–30 fps)



Stream Capability

2 streams



Resolution

2592×1944(2592×1944); 2688×1520(2688×1520); 3M(2048×1536); 2304×1296(2304×1296); 1080p(1920×1080); 1.3M (1280 × 960); 720p(1280×720); D1(704× 576/704×480); VGA(640×480); CIF(352×288/352×240)



Bit Rate Control

CBR/VBR



Video Bit Rate

H.264: 32 kbps–8192 kbps

H.265: 12 kbps–8192 kbps



Day/Night

Auto(ICR)/Color/B/W



BLC

Yes



HLC

Yes



WDR

120 dB



White Balance

Auto/natural/street lamp/outdoor/manual/regional custom



Gain Control

Auto/Manual



Noise Reduction

3D DNR



Motion Detection

OFF/ON (4 areas, rectangular)



Region of Interest(RoI)

Yes (4 areas)



Smart Illumination

Yes



Image Rotation

0°/90°/180°/270° (Supports 90°/270° with 2592 × 1944 resolution and lower.)



Mirror

Yes



Privacy Masking

4 areas



Audio

Built-in MIC

Yes

Audio Compression

G.711A; G.711Mu; G.726; AAC

Alarm

Alarm Event

No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; security exception

Network

Network

RJ-45 (10/100 Base-T)

SDK and API

Yes

Protocol

IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; Bonjour

Interoperability

ONVIF(Profile S/Profile G/Profile T);CGI; P2P; Milestone; Genetec

User/Host

20

Storage

Dahua Cloud; FTP; SFTP; Micro SD Card (support max. 256 GB); NAS

Browser

IE

Chrome

Firefox

Management Software

Smart PSS; DSS; DMSS

Mobile Phone

IOS; Android

Certifications

CE-LVD: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B

UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07

Power



Power Supply

12V DC/PoE (802.3af)



Power Consumption

< 7.2W



Environment



Operating Conditions

–40°C to +60°C (–40°F to +140°F)/less than ≤ 95%



Storage Temperature

–40°C to +60°C (–40°F to +140°F)



Protection Grade

IP67



Structure



Casing

Metal



Dimensions

93.6 mm × Φ106 mm (3.7" × Φ4.2")



Net Weight

530 g (1.1 lb)



Gross Weight

800 g (1.7 lb)

Documentation

3 Years Manufacturer Warranty

All IP cameras and recording devices (NVR’s/DVR’s) are covered by a 3 year back-to-base manufacturer warranty.

Our warranty is limited to the replacement of faulty items or parts and does not include damage due to incorrect fitting of parts or accessories, or damage due to mishandling the equipment once out of the box. All faults are sent to the manufacturer for inspection and diagnosis before a replacement is sent out.

Read more about the Terms & Conditions here – https://www.securityaustralia.com.au/terms-and-conditions/

Trusted Brand Partner & Security Equipment Wholesaler

Authorised Brand Partner with Responsive & Fast Aussie Sales Support Team ★★★★★
Best After-Sales Support and Troubleshooting Team with Years of Installation Experience.

Free Delivery* & Despatch Time

*Just spend over $100 to activate Fast Free Shipping!

Despatch Times: Products are despatched on the same day if the order was placed before 11am on any weekday, Monday - Friday. All other orders are processed and despatched within 24 hours or next business day.

Order Confirmation: Once you place an order, you will receive a confirmation email. This indicates that your order has been received in our system and is now being processed for dispatch. If your item is back-ordered or unavailable, we will notify you via email, and if we do not receive a response, we will attempt to contact you by phone as soon as possible. We value your time and strive to be prompt. If your item(s) are available for immediate shipment (within 2 days), we will process the charges and prepare the order for shipping.

Shipping Times: General shipping times for StarTrack, TNT and Allied couriers are between 1-3 working days from despatch. Longer delivery times may be caused by your package being held at your local courier depot that is beyond our control. Please contact us or the local post depot for confirmation.

Tracking Numbers: all tracking numbers will be emailed to you by our warehouse processing team within the day, after your order is despatched to our local courier.

View full details

Dahua 8 x 5MP DH-IPC-HDW2431EMP Eyeball / Turret Kit 30m IR 2.8mm+ 8CH NVR + 2TB HDD

The 5MP Lite IR Fixed-focal Eyeball Network Camera DH-IPC-HDW2531EM-AS-S2 from Dahua Security offers high-quality video performance with its 5MP resolution, providing clear and detailed images. It features Smart IR technology, ensuring optimal illumination in low-light conditions by automatically adjusting the intensity of the infrared LEDs. The camera is equipped with a fixed-focal lens, making it ideal for consistent, focused surveillance in specific areas. Its compact design allows for easy installation, and the IP67 rating guarantees protection against water and dust, making it suitable for both indoor and outdoor environments. The camera supports H.265 video compression, which reduces bandwidth and storage requirements without compromising image quality. Additionally, it includes intelligent detection functions like motion detection and intrusion detection, enhancing its security capabilities. The camera is equipped with a built-in microphone for audio recording, adding another layer of security.

With its 120dB true WDR (Wide Dynamic Range) technology, the camera performs well in challenging lighting conditions, balancing the exposure to deliver clear images. The DH-IPC-HDW2531EM-AS-S2 also supports Power over Ethernet (PoE), simplifying installation by allowing power and data to be transmitted over a single cable. This camera is part of Dahua's Lite Series, offering a cost-effective solution without sacrificing essential features. It is compatible with various NVRs and software, ensuring seamless integration into existing surveillance systems. Overall, this camera is a reliable and efficient choice for various security applications.

Features

  • 5MP, 1/2.7” CMOS image sensor, low illuminance, high image definition
  • Outputs max. 5MP (2592 × 1944) @20 fps, and supports 2688 ×1520 (2688 × 1520) @25/30 fps
  • H.265 codec, high compression rate, ultra-low bit rate
  • Built-in IR LED, max IR distance: 30 m
  • ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
  • Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
  • Intelligent detection: Intrusion, tripwire
  • Abnormality detection: Motion detection, video tampering, no SD card, SD card full, SD card error, network disconnected, IP conflict, illegal access, voltage detection
  • Supports max. 256 GB Micro SD card, built-in MIC
  • 12V DC/PoE power supply
  • IP67 protection



Functions

Smart H.265+ & Smart H.264+ Dahua's advanced scene-adaptive rate control algorithm enhances encoding efficiency beyond traditional H.265 and H.264, delivering high-quality video while minimizing storage and transmission costs.

WDR (Wide Dynamic Range) Equipped with advanced Wide Dynamic Range (WDR) technology, Dahua network cameras capture clear details even in environments with high contrast between bright and dark areas, ensuring visibility even under intense lighting or backlight conditions.

Starlight Dahua's Starlight technology is designed for low-light environments, providing clear and colorful video even in extremely low illuminance, ensuring superior image quality.

IVS (Intelligent Video System) Dahua's Intelligent Video System (IVS) technology utilizes advanced video algorithms to support smart features like tripwire detection and intrusion alerts.

Protection (IP67, Wide Voltage) IP67: The camera undergoes rigorous testing to ensure dust resistance and can operate normally after being submerged in 1 meter of water for 30 minutes.
Wide Voltage: The camera supports a wide input voltage range of ±30%, making it suitable for outdoor environments with unstable power supply.

Technical Specifications:

Camera



Image Sensor

1/2.7” 5Megapixel progressive CMOS



Max. Resolution

2592 (H) × 1944 (V)



ROM

128 MB



RAM

256 MB



Scanning System

Progressive



Electronic Shutter Speed

Auto/Manual 1/3 s–1/100000 s



S/N Ratio

0.008 Lux @ F1.6



Min. Illumination

> 56 dB



Illumination Distance

30 m (98.43 ft)



Illuminator On/Off Control

Auto/Manual



Illuminator Number

2 (IR LED)



Pan/Tilt/Rotation Range

Pan: 0°–360° Tilt: 0°–78° Rotation: 0°–360°



Lens



Lens Type

Fixed-focal



Mount Type

M12



Focal Length

2.8 mm 3.6 mm



Max. Aperture

F1.6 F1.6



Field of View

2.8 mm: Horizontal 103° × Vertical 71° × Diagonal 132°

3.6 mm: Horizontal 84° × Vertical 58° × Diagonal 110°



Iris Type

Fixed



Close Focus Distance

2.8 mm: 0.9 m (2.95 ft) 3.6 mm: 1.6 m (3.61 ft)



DORI Distance

Lens

Detect

Observe

Recognize

Identify



2.8 mm

56 m (183.73 ft)

22.4 m

(73.49 ft)

11.2 m

(36.75 ft)

5.6 m

(18.37 ft)



3.6 mm

80 m (262.47 ft)

32.0 m (104.99 ft)

16.0 m

(52.49 ft)

8.0 m

(26.25 ft)



The 8 Channel Compact 1HDD 1U 8PoE Network Video Recorder, model DHI-NVR4108HS-8P-4KS2/L, from Dahua Security is a powerful and efficient surveillance solution designed for small to medium-sized installations. This NVR supports up to 8 IP cameras with a maximum resolution of 8MP, providing clear and detailed video footage. It features H.265+ video compression, significantly reducing storage and bandwidth requirements without compromising video quality. The device includes one SATA interface, supporting up to 10TB of storage, ensuring ample space for recording and archiving footage. Equipped with 8 PoE ports, it simplifies the installation process by delivering power and data over a single cable to each connected camera. The NVR offers intelligent video system (IVS) capabilities, such as intrusion detection, tripwire, and facial detection, enhancing security and monitoring effectiveness. With its easy-to-use web interface and support for mobile access via the Dahua DMSS app, users can manage and view their surveillance system remotely.

The NVR also supports various network protocols and has a built-in P2P feature for simplified network setup. Additionally, it provides multiple recording modes, including manual, schedule, and alarm-based recording, offering flexibility to meet different security needs. The compact 1U design ensures efficient use of space and easy integration into existing setups. High reliability is guaranteed with features like redundant power supply options and ANR (Automatic Network Replenishment) technology, which ensures continuous recording even during network interruptions. The DHI-NVR4108HS-8P-4KS2/L is an ideal choice for users seeking a robust and versatile network video recorder for their security infrastructure.

Features

  • New 4.0 user interface, Security baseline 2.1
  • H.264, H.265, Smart H.264+, and Smart H.265+. H.265 auto switch
  • Max. decoding capability: 8 × 1080p@30 fps. Supports adaptive decoding
  • Supports mainstream cameras of ONVIF and RTSP protocols
  • P2P remote surveillance, video play on mobile device
  • VGA/HDMI simultaneous video output, maximum resolution of HDMI is 4K
  • AI by Camera: Face detection, perimeter protection, IVS, people counting, heat map, and SMD
  • Supports remote configuration and management of IPC, such as setting parameters, getting information, and upgrading IPC of the same model in batches



Functions

Perimeter Protection by Camera
This feature automatically filters out false alarms caused by animals, rustling leaves, bright lights, and other non-threats. It enhances the system's ability to recognize true threats, thereby improving alarm accuracy.

Face Detection by Camera
Utilizing deep learning algorithms, this technology detects human faces in the video feed. It supports face detection, tracking, optimization, and capturing, ultimately outputting the best face snapshot for identification purposes.

SMD Plus by Camera
Dahua's Smart Motion Detection technology uses intelligent algorithms to categorize motion detection targets, filtering out non-essential alarms. This ensures effective and accurate alerting for relevant movements.

People Counting by Camera
Employing deep learning algorithms, Dahua People Counting technology tracks and processes moving human targets. It provides accurate statistics on the number of people entering, leaving, and present in an area. Integrated with a management platform, it generates detailed yearly, monthly, weekly, and daily reports.

Smart Codec
Dahua's smart codec technology, featuring an advanced scene-adaptive rate control algorithm, offers higher encoding efficiency compared to H.265 and H.264 standards. This results in high-quality video while reducing storage and transmission costs.

DMSS
Available on the iOS App Store and Google Play, the DMSS app simplifies surveillance. It allows remote access to back-end devices, live video viewing, event push notifications, and recorded video searches from an iPhone, iPad, or Android device anytime, anywhere.

Technical Specifications:


System

Main Processor

Industrial-grade embedded processor

OS

Embedded Linux

Operation Interface

Web/operating in local GUI

Perimeter Protection by Camera

Performance

8 channels

AI Search

Search for pictures by channel, time and event type

Face Detection by Camera

Performance

4 channels

Face Attributes

6 attributes: Gender, age, glasses, expression, mouth mask, and beard

AI Search

Search for pictures by channel, time and face attributes

SMD Plus by Camera

Performance

8 channels

AI Search

Search by target classification (human, vehicle)

Video

Access Channel

8

Network Bandwidth

Access: 80 Mbps; Storage: 80 Mbps; Forward: 60 Mbps

Resolution

8MP; 6MP; 5MP; 4MP; 3MP; 1080p; 720p; D1

Decoding Capability

8 × 1080p@30 fps

Video Output

1 × VGA output, 1 × HDMI output, supports simultaneous video sources output for VGA and HDMI

Multi-screen Display

1, 4, 8, 9 views

Third-party Camera Access

ONVIF; RTSP

Compression

Video

Smart H.265/H.265/Smart H.264/H.264/MJPEG

Audio

PCM/G711A/G711U/G726/AAC

Network

Network Protocol

HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm Server; IP Search (Support Dahua IP camera; DVR; NVS; etc.); P2P; auto register

Mobile Phone Access

Android; iOS

Interoperability

ONVIF(profile T/S/G); CGI; SDK

Browser

Chrome; IE9 or later; firefox

Record Playback

Multi-channel Playback

Up to 8 channels for playback

Record Mode

Manual record; alarm recording; SMD recording; smart recording

Storage

Local HDD; network

Backup

USB storage device

Playback Function

1. Play/pause/stop/slow/quick/backward/by frame
2. Full screen, backup (video clip/file), partial zoom in, and audio on/off

Storage

Disk Group

Yes

Alarm

General Alarm

Motion detection, privacy masking, video loss, scene changing, PIR alarm, IPC external alarm

Anomaly Alarm

Camera disconnection, storage error, disk full, IP conflict, MAC conflict, login locked, and cybersecurity exception

Intelligent Alarm

Face detection, perimeter protection (intrusion and tripwire), IVS, people counting, heat map, and SMD alarms

Alarm Linkage

Recording, snapshot, audio, buzzer, log, preset, and email

External Port

Audio Input

1 × RCA input

Audio Output

1 × RCA output

HDD

1 SATA III ports, up to 10 TB for a single HDD. The maximum HDD capacity varies with environment temperature

USB

2 (1 × front USB2.0; 1 × back USB2.0)

HDMI

1 (supports up to 4K resolution output)

VGA

1

Network

1 × RJ-45, 10/100 Mbps self-adaptive Ethernet port

POE

8

General Parameter

Power Supply

DC48 V/53 V, 2A/1.8 A

Power Consumption

< 10 W (HDD not included, idling)
Total output power of PoE is 72W, the maximum output power of a single port is 25.5W

Net Weight

0.92 kg (2.03 lb)

Gross Weight

2.07 kg (4.56 lb)

Product Dimensions

260 mm × 232.5 mm × 50.3 mm (10.24" × 9.15" × 1.98") (W × L × H)

Package Dimensions

117 mm × 373 mm × 307 mm (4.61" × 14.69" × 12.09") (W × L × H)

Operating Conditions

–10 °C to +55 °C (+10 °F to +131 °F)

Storage Conditions

0 °C to +40 °C (32 °F to 104 °F)

Operating Humidity

10℅~93℅

Storage Humidity

30%~85%

Operating Altitude

3000 m (9842.52 ft)

Installation

Desktop mounted

Certifications

CE: EN62368-1; EN55032,EN55024, EN55035, EN61000-3-2, EN61000-3-3 EN50130-4
FCC: Part 15 Subpart B



Enhance your security with the Dahua Camera System Kit. Experience superior clarity, advanced analytics, and reliable performance. Upgrade your surveillance system today!

Recently viewed products

SECURITY AUSTRALIA - YOUR TRUSTED SOURCE FOR SECURITY EQUIPMENT

Discover our wide range of security equipment designed to keep you safe and secure.

We offer competitive prices to trades and commercial projects. Speak to one of our experienced consultants if you require a custom quote on larger orders.

Sales Support & Enquiry Form

Got a question or just want to chat?
