Dahua 4 x 6MP DH-IPC-HDW3666EMP-S-AUS SMD 4.0 AI Turret Security Kit 50m IR 2.8mm with Wizsense + 4CH NVR

The DH-IPC-HDW3666EMP-S-AUS is a 6MP fixed-focal network camera that delivers high-resolution video with a 3072 x 2048 pixel resolution, thanks to its advanced 1/1.8” CMOS sensor. It features a fixed 3.6mm lens for a wide field of view and supports infrared night vision up to 50 meters for clear imaging in low-light conditions. With integrated WizSense technology, the camera enhances intelligent detection and analysis capabilities, while true WDR (Wide Dynamic Range) helps manage complex lighting conditions.

It uses H.265 and H.264 compression formats to reduce bandwidth and storage needs. The camera includes a built-in microphone for audio recording, is IP67 rated for dust and water resistance, and supports PoE (Power over Ethernet) for easy installation. It integrates with Dahua’s SmartPSS software and other VMS solutions, offers intelligent analytics features like line crossing and intrusion detection, and supports local recording via microSD card. Its compact, discreet design ensures it blends into various environments while providing reliable, high-performance surveillance.

Features:

• Records up to 6MP, 1/2.7” CMOS image sensor, low illuminance, high image definition
• 2.8mm Fixed lens
• Outputs max. 6 MP (3072 x 2048) @25/30 fps.
• Supports Starlight technology, generates clear images in near-complete darkness.
• Supports PoE "Power-Over-Ethernet" installations.
• Built-In Mic
• Intelligent Detection: Intrusion, tripwire and motion (Up to 4 areas)
• Supports 50m Smart Infrared Range
• 120 dB Wide Dynamic Range WDR. 3D Digital Noise Reduction 3D DNR.
• Day/Night Infrared Cut Removal ICR. Auto White Balance AWB. Automatic Gain Control AGC. Backlight Compensation BLC. Highlight Compensation HLC. Region of Interest ROI.
• Supports MicroSD Card Storage up to 256 Gigabytes.
• Resilient "Weather-Proof" Ingress Protection Rating (IP67).
• Metal Housing

Functions:

Smart (H.265+ & H.264+)

With advanced scene-adaptive rate control algorithm, Dahua smart encoding technology realizes the higher encoding efficiency than H.265 and H.264, provides high-quality video, and reduces the cost of storage and transmission. Wide dynamic range (WDR) Dahua adopts advanced Wide Dynamic Range (WDR) technology. You can get clear details in the environment of strong brightness contrast. In high brightness and back- light environment, bright region and dark region with strong light source, you can also get clear images.

Starlight

Dahua Starlight technology mainly applies to the environment of low illumination, and it can provide clear colorful video. Even in the environment of min. illumination, the technology can guarantee a good image effect.

Intelligent Video Analysis (IVS)

With an advanced video algorithm, Dahua camera supports intelligent detection, such as tripwire and intrusion and so on.

Protection (IP67, wide voltage) IP67:

The camera passes a series of strict tests on dust and soak. It has a dust-proof function, and the enclosure can work normally after soaking in 1 m deep water for 30 minutes. Wide voltage: The camera allows ±30% input voltage tolerance (wide voltage range), and it is widely applied to the outdoor environment with unstable voltage.

Technical Specifications:

Starlight technology generates clear colour images in near-complete darkness. A high-performing sensor and special algorithms work together to capture images in low-light and no-light environments. With advanced video algorithms, Dahua's Intelligent Video Surveillance (IVS) technology supports smart functions such as Tripwire and Intrusion Detection.

The 4 Channel Compact 1U 4PoE 4K & H.265 Lite Network Video Recorder DHI-NVR4104HS-P-4KS2/L by Dahua Security offers advanced video recording capabilities with support for both 4 and 8 channels, making it versatile for various security needs. This NVR supports up to 4K resolution, ensuring high-quality video playback and detailed footage analysis. With H.265 compression technology, it significantly reduces bandwidth and storage requirements while maintaining superior video quality. The device is equipped with 4 PoE ports, simplifying the installation process by providing power and data transmission over a single cable for connected cameras. It features intelligent video system (IVS) analytics, such as intrusion detection and tripwire, enhancing security by enabling real-time threat detection.

The NVR also supports face detection and recognition, offering an additional layer of surveillance for identifying and tracking individuals. It includes a smart search function, allowing quick and efficient retrieval of specific events from recorded footage. The compact 1U design ensures it can fit into limited spaces without compromising performance. Dual HDMI and VGA outputs provide flexible display options for monitoring and playback. With a maximum incoming bandwidth of 80 Mbps, it can handle multiple high-resolution video streams simultaneously. The NVR supports mobile access via the Dahua app, enabling remote monitoring and management from anywhere. Additionally, it includes a USB port for easy data backup and firmware updates, ensuring the system remains up-to-date and secure.

Features

• 4-channel IP video access
• Smart H.265+/Smart H.264+/H.265/H.264; H.265 auto switch
• Max 200 Mbps incoming bandwidth
• Up to 8MP resolution for preview and playback

• AI by Camera: Perimeter protection; SMD Plus; people counting; heat map
• Support IPC UPnP, 4 PoE ports

Functions

4K Resolution
4K resolution represents a significant advancement in image processing technology. It provides four times the resolution of standard 1080p HDTV cameras, delivering superior picture quality and detailed images. This enhancement allows for clearer magnification of scenes, enabling the capture of crisp forensic video over large areas.

High Efficiency Video Coding (H.265)
The H.265 (ITU-T VCEG) video compression standard offers twice the data compression ratio at the same level of video quality, or significantly improved video quality at the same bit rate, compared to older compression technologies. It achieves this through advanced pattern comparison and difference-coding, enhanced motion vector prediction and motion region merging, and an additional filtering step called sample-adaptive offset filtering.

Intelligent Video System
When paired with IVS-enabled IP cameras, the NVR identifies and records video containing IVS data across all IP channels. It supports both standard and premium IVS features, detecting abandoned or missing objects, Tripwire violations, and intrusion violations. Additionally, it can record business analytics data such as Facial Detection, People Counting, and Heat Maps from IP cameras with built-in Intelligent Business Analytics.

ANR (Automatic Network Replenishment Technology)
NVRs equipped with ANR functionality automatically store video data on an IP camera's SD card when the network connection is lost. Once the network is restored, the NVR retrieves the stored video data from the camera seamlessly.

Easy4ip
The Easy4ip app, available on the iOS App Store and Google Play, simplifies surveillance. It allows remote access to NVR devices, live video viewing, event push notifications, and recorded video searches from an iPhone, iPad, or Android phone anytime and from virtually anywhere.

Technical Specifications:

Enhance your security with the Dahua Camera System Kit. Experience superior clarity, advanced analytics, and reliable performance. Upgrade your surveillance system today!
