Dahua 3 x 6MP BLACK DH-IPC-HDW3666EMP-S-AUS Turret Security Kit 30m IR 2.8mm with SMD + 4CH NVR Wizsense

The DH-IPC-HDW3666EMP-S-AUS-BLK is a 6MP fixed-focal network camera that delivers high-resolution video with a 3072 x 2048 pixel resolution, thanks to its advanced 1/1.8” CMOS sensor. It features a fixed 3.6mm lens for a wide field of view and supports infrared night vision up to 50 meters for clear imaging in low-light conditions. With integrated WizSense technology, the camera enhances intelligent detection and analysis capabilities, while true WDR (Wide Dynamic Range) helps manage complex lighting conditions.

It uses H.265 and H.264 compression formats to reduce bandwidth and storage needs. The camera includes a built-in microphone for audio recording, is IP67 rated for dust and water resistance, and supports PoE (Power over Ethernet) for easy installation. It integrates with Dahua’s SmartPSS software and other VMS solutions, offers intelligent analytics features like line crossing and intrusion detection, and supports local recording via microSD card. Its compact, discreet design ensures it blends into various environments while providing reliable, high-performance surveillance.

Features

• Records up to 6MP, 1/2.7” CMOS image sensor, low illuminance, high image definition
• 2.8mm Fixed lens
• Outputs max. 6 MP (3072 x 2048) @25/30 fps.
• Supports Starlight technology, generates clear images in near-complete darkness.
• Supports PoE "Power-Over-Ethernet" installations.
• Built-In Mic
• Intelligent Detection: Intrusion, tripwire and motion (Up to 4 areas)
• Supports 50m Smart Infrared Range
• 120 dB Wide Dynamic Range WDR. 3D Digital Noise Reduction 3D DNR.
• Day/Night Infrared Cut Removal ICR. Auto White Balance AWB. Automatic Gain Control AGC. Backlight Compensation BLC. Highlight Compensation HLC. Region of Interest ROI.
• Supports MicroSD Card Storage up to 256 Gigabytes.
• Resilient "Weather-Proof" Ingress Protection Rating (IP67).
• Metal Housing

Functions

Smart (H.265+ & H.264+)

With advanced scene-adaptive rate control algorithm, Dahua smart encoding technology realizes the higher encoding efficiency than H.265 and H.264, provides high-quality video, and reduces the cost of storage and transmission. Wide dynamic range (WDR) Dahua adopts advanced Wide Dynamic Range (WDR) technology. You can get clear details in the environment of strong brightness contrast. In high brightness and back- light environment, bright region and dark region with strong light source, you can also get clear images.

Starlight

Dahua Starlight technology mainly applies to the environment of low illumination, and it can provide clear colorful video. Even in the environment of min. illumination, the technology can guarantee a good image effect.

Intelligent Video Analysis (IVS)

With an advanced video algorithm, Dahua camera supports intelligent detection, such as tripwire and intrusion and so on.

Protection (IP67, wide voltage) IP67:

The camera passes a series of strict tests on dust and soak. It has a dust-proof function, and the enclosure can work normally after soaking in 1 m deep water for 30 minutes. Wide voltage: The camera allows ±30% input voltage tolerance (wide voltage range), and it is widely applied to the outdoor environment with unstable voltage.

Technical Specifications:

Starlight technology generates clear colour images in near-complete darkness. A high-performing sensor and special algorithms work together to capture images in low-light and no-light environments. With advanced video algorithms, Dahua's Intelligent Video Surveillance (IVS) technology supports smart functions such as Tripwire and Intrusion Detection.

The Dahua NVR4104HS-P-AI/ANZ is a 4-channel network video recorder designed for small to medium-sized surveillance systems. It supports AI features, including face detection and perimeter protection. This compact 1U device comes with 4 PoE ports, providing both power and data to connected IP cameras. It supports up to 8MP resolution for clear and detailed recordings. The recorder can handle up to 1 HDD for storage, ensuring ample space for video data. It integrates seamlessly with Dahua's WizSense technology, enhancing accuracy and efficiency in video analysis.

Remote access and management are possible through the Dahua DMSS app. This NVR is compatible with various third-party devices, supporting both ONVIF and custom protocols. It also features smart H.265+ compression to reduce storage and bandwidth needs. The NVR4104HS-P-AI/ANZ is an ideal solution for robust, intelligent video surveillance.

Features

• Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.
• Access, storage or forwarding at 80 Mbps.
• Max. decoding capability: 16 × 1080p@30 fps. Supports adaptive decoding.
• AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.
• AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; ANPR; people counting; stereo analysis; heat map.
• Connected to third-party network cameras.
• Security baseline 2.3.

Functions

Face Detection

Face detection is to detect if there is any human face appearing in the video. This technology adopts a deep learning algorithm to support face detection, tracking, optimization and capturing and then outputs the best face snapshot.

Face Recognition

Dahua Face Recognition technology extracts the features of captured faces and compares them with those in the face database to recognize the person's identity.

Perimeter Protection

Automatically filtering out false alarms caused by animals, rustling leaves, bright lights, etc. Enables the system to perform secondary recognition for the targets. Improving alarm accuracy.

SMD Plus

With an intelligent algorithm, Dahua Smart Motion Detection technology can categorize the targets that trigger motion detection and filter the motion detection alarm triggered by non-concerned targets to realize effective and accurate alarms.

AI Search

Support AI search by metadata of different targets or uploading face pictures to the device and comparing them with recorded faces by similarity. Enable operators to search through multi-channels quickly and easily and long duration, efficiently find out when and where a person of interest appears.

Heat Map by Camera

Dahua heat map technology is used to display the crowd density and people's appearance probability. Export and display the crowd status in different colors. Generally, crowd status is the statistics of people's quantity in space and time dimensions.

ANPR by Camera

With a deep learning algorithm, Dahua ANPR technology can recognize the number plate information of vehicles in the image with ANPR cameras. Support blocklist/allowlist mode, searching target vehicles from recorded video.

Quick Pick

Dahua Quick Pick technology can enable users to quickly pick up the human/vehicle targets that they are interested in, which facilitates retrieval from SMD events.

Technical Specifications:

When paired with compatible IPC cameras, the Quick Pick technology enables easy identification and retrieval of human and vehicle targets. This network recorder is both cost-effective and versatile, supporting a broad range of third-party devices. It’s an excellent option for small and medium-sized businesses due to its affordability and extensive compatibility.

Enhance your security with the Dahua Camera System Kit. Experience superior clarity, advanced analytics, and reliable performance. Upgrade your surveillance system today!
