AXIS Power Supply DIN PS56 240W Power Supply
The AXIS Power Supply DIN PS56 delivers 480W of industrial-grade power at 56V DC for demanding surveillance infrastructure, particularly the AXIS D8208-R managed switch. Its wide-range AC (85-264V) and DC (80-370V) dual input capability keeps it operational across variable power environments, and it handles temperatures from -25°C to 70°C without issue.
Why This Model
- Dual AC/DC input: Accepts both AC (85-264V) and DC (80-370V) input, making it compatible with a wider range of site power configurations including DC-backed systems.
- Adjustable output voltage: Output can be fine-tuned between 42V and 56V via a built-in potentiometer, allowing precise matching to connected equipment requirements.
- Wide operating temperature: Rated from -25°C to 70°C, so it performs reliably in harsh outdoor enclosures, industrial sites, or poorly climate-controlled comms rooms.
Need help choosing?
Click to ask a question - same day response (~2 hours during business hours)
Product Overview
Model: AXIS Power Supply DIN PS56 240 W
Product Overview
Designed for demanding industrial environments, the AXIS Power Supply DIN PS56 240W is a DIN-rail mounted power supply from Axis Communications that delivers a 56V DC output at 240W. It accepts both AC input (85-264V AC) and DC input (80-370V DC), with output voltage adjustable between 42V and 56V via a built-in potentiometer. Rated for operation across a wide temperature range of -25°C to 70°C, it is well suited to harsh or outdoor installations. Security Australia supplies this unit as a reliable power accessory compatible with supported Axis infrastructure deployments.
No downloads available for this product.
Key Features
Trusted Brand Partner & Security Equipment Wholesaler
- Authorised Brand Partner with Responsive & Fast Aussie Sales Support Team ★★★★★
- Best After-Sales Support and Troubleshooting Team with Years of Installation Experience.
What This Product Does
The AXIS Power Supply DIN PS56 delivers 480W of industrial-grade power at 56V DC for demanding surveillance infrastructure, particularly the AXIS D8208-R managed switch. Its wide-range AC (85-264V) and DC (80-370V) dual input capability keeps it operational across variable power environments, and it handles temperatures from -25°C to 70°C without issue.
Why This Model
- Dual AC/DC input: Accepts both AC (85-264V) and DC (80-370V) input, making it compatible with a wider range of site power configurations including DC-backed systems.
- Adjustable output voltage: Output can be fine-tuned between 42V and 56V via a built-in potentiometer, allowing precise matching to connected equipment requirements.
- Wide operating temperature: Rated from -25°C to 70°C, so it performs reliably in harsh outdoor enclosures, industrial sites, or poorly climate-controlled comms rooms.
Not sure if this suits your site?
Ask our team before ordering. We can help confirm lens choice, recorder compatibility, mounting accessories and project quantities.
Specifications
Specifications
| INPUT | |
|---|---|
| AC current consumption | 2.4 A @ 230 V AC / 5.2 A @ 110 V AC |
| AC input voltage range | 85-264 V AC (Derating @ 100 V AC) |
| DC current consumption | 1.5 A @ 370 V DC / 4.6 A @ 120 V DC |
| DC input voltage range | 80-370 V DC (Derating @ 120 V DC) |
| Frequency range AC | 47-63 Hz |
| Input frequency | 47-63 Hz |
| Rated input voltage | 100-240 V AC (wide-range input) |
| OUTPUT | |
| Output power | 480 W |
| Output voltage | 56 V |
| Output voltage (adjustable) | 42-56 V (adjustable via potentiometer) |
| Rated output voltage | 48 V DC ± 1 % |
