Varifocal 4 MP dome with deep learning
Equipped with WDR and Lightfinder technologies, this compact and discreet dome camera delivers exceptional image quality even in challenging lighting conditions. It features a Deep Learning Processing Unit (DLPU) for intelligent edge analytics based on deep learning. Designed to seamlessly blend into any environment, the camera can be repainted and offers various accessories for unobtrusive monitoring. Additionally, it includes an HDMI port and the option to add audio and I/O connectivity via the AXIS T61 Series. Axis Edge Vault further enhances security by protecting your Axis device ID and simplifying device authorization on your network.
Key Features
Code/SKU: AXIS M4216–V
Quick Specs:
| Camera | Image Sensor: 1/2.7” progressive scan RGB CMOS |
| Lens: Varifocal, 3–6 mm, F1.9 - 2.7 | |
| Horizontal Field of View: 100°–45° | |
| Vertical Field of View: 72°–34° Remote Focus and Zoom: Fixed iris Day and Night: Automatic IR-cut filter | |
| Minimum Illumination | Color: 0.18 lux at 50 IRE F2.0 B/W: 0.03 lux at 50 IRE F2.0 |
| Shutter Speed | 1/37500 s to 1/5 s |
| Camera Angle Adjustment | Pan ±180°, tilt -40 to +65°, rotation ±105° Can be directed in any direction and see the wall/ceiling |
| System on Chip (SoC) | Model CV25 |
| Memory | 1024 MB RAM, 512 MB Flash |
| Compute Capabilities | Deep learning processing unit (DLPU) |
| Video | Video Compression: H.264 (Main and High Profiles), H.265 (Main and High Profiles), Motion JPEG |
| Resolution: 2304x1728 to 320x240 | |
| Frame Rate: Up to 25/30 fps with power line frequency 50/60 Hz in H.264 and H.265a Video Streaming: Multiple, individually configurable streams in H.264, H.265, and Motion JPEG Axis Zipstream technology in H.264 and H.265 Controllable frame rate and bandwidth VBR/MBR H.264/H.265 Low latency mode | |
| HDMI Output | HDMI 1080p (16:9) @25/30 Hz refresh rate HDMI 720p (16:9) @50/60 Hz refresh rate |
| Multi-view Streaming | Up to 2 individually cropped out view areas in full frame rate |
| Image Settings | Compression, color, brightness, sharpness, contrast, white balance, exposure control, motion-adaptive exposure, WDR: up to 110 dB depending on scene, text and image overlay, mirroring of images, privacy mask Rotation: 0°, 90°, 180°, 270°, including Corridor Format |
| Pan/Tilt/Zoom | Digital PTZ |
| Audio | Audio Input/Output: Audio features through portcast technology: two-way audio connectivity, voice enhancer |
| Network Protocols: IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS, TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP®, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCP, ARP, SSH, HDMI, LLDP, CDP, MQTT v3.1.1, Link-Local address (ZeroConf) | |
| System Integration | Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at axis.com One-click cloud connection ONVIF® Profile G, ONVIF® Profile M, ONVIF® Profile S, and ONVIF® Profile T, specification at onvif.org Support for SIP for integration with VoIP systems, peer to peer or integrated with SIP/PBX |
| Event Conditions: Device status: above operating temperature, above or below operating temperature, below operating temperature, IP address removed, network lost, new IP address, system ready, within operating temperature Edge storage: recording ongoing, storage disruption I/O: manual trigger, virtual input, digital input via AXIS T61 Audio and I/O Interfaces with portcast technology MQTT subscribe: scheduled and recurring event Video: live stream open | |
| Event Actions | MQTT publish Notification: email, HTTP, HTTPS, TCP, and SNMP trap Overlay text, zoom preset, day/night mode Pre- and post-alarm video or image buffering for recording or upload Record video: SD card and network share Upload of images or video clips: FTP, SFTP, HTTP, HTTPS, network share, and email External output activation via AXIS T61 Audio and I/O Interfaces with portcast technology |
| Built-in Installation Aids: Remote zoom, remote focus | |
| Analytics | **Included**: AXIS Live Privacy Shield, AXIS Object Analytics, AXIS Scene Metadata, AXIS Video Motion Detection, AXIS Face Detector **Supported**: AXIS People Counter, AXIS Queue Monitor Support for AXIS Camera Application Platform enabling installation of third-party applications, see axis.com/acap |
| **AXIS Object Analytics**: Object classes: humans, vehicles (types: cars, buses, trucks, bikes) Scenarios: line crossing, object in area, crossline counting, occupancy in area, time in area Up to 10 scenarios Other features: triggered objects visualized with color-coded bounding boxes Polygon include/exclude areas Perspective configuration ONVIF Motion Alarm event | |
| **AXIS Scene Metadata**: Object classes: humans, faces, vehicles (types: cars, buses, trucks, bikes), license plates Object attributes: vehicle color, upper/lower clothing color, confidence, position | |
| Approvals | EMC: EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2 Australia/New Zealand: CISPR 24, CISPR 35, RCM AS/NZS CISPR 32 Class A Canada: ICES-3(A)/NMB-3(A) Japan: VCCI Class A Korea: KC KN32 Class A, KC KN35 USA: FCC Part 15 Subpart B Class A |
| Safety: IEC/EN/UL 62368-1, CAN/CSA C22.2 No. 62368-1, IS 13252 | |
| Environment: IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-6, IEC/EN 60529 IP42, IEC/EN 62262 IK08 | |
| Network: NIST SP500-267 | |
| Cybersecurity: ETSI EN 303 645 | |
| Cybersecurity Edge Security: Software: Signed OS, brute force delay protection, digest authentication and OAuth 2.0 RFC6749 OpenID Authorization Code Flow for centralized ADFS account management, password protection, AES-XTS-Plain64 256bit SD card encryption Hardware: Axis Edge Vault cybersecurity platform, Secure element (CC EAL 6+), system-on-chip security (TEE), Axis device ID, secure keystore, signed video, secure boot, encrypted filesystem (AES-XTS-Plain64 256bit) | |
| Network Security: IEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2), IEEE 802.1AE (MACsec PSK/EAP-TLS), IEEE 802.1AR, HTTPS/HSTS, TLS v1.2/v1.3, Network Time Security (NTS), X.509 Certificate PKI, host-based firewall | |
| Documentation | AXIS OS Hardening Guide Axis Vulnerability Management Policy Axis Security Development Model AXIS OS Software Bill of Material (SBOM) To download documents, go to axis.com/support/cybersecurity/resources To read more about Axis cybersecurity support, go to axis.com/cybersecurity |
| General: Casing: IP42 water- and dust-resistant, IK08 impact-resistant, polycarbonate and aluminum casing with hard-coated dome Encapsulated electronics Color: white NCS S 1002-B For repainting instructions of casing and impact on warranty, contact your Axis partner Sustainability: PVC free, BFR/CFR free, 43% recycled plastics | |
| Power | Power over Ethernet (PoE): IEEE 802.3af/802.3at Type 1 Class 2 Typical: 2.8 W Max: 4.4 W |
| Connectors: RJ45 10BASE-T/100BASE-TX PoE HDMI type D Audio: Audio and I/O connectivity via portcast technology | |
| Storage: Support for microSD/microSDHC/microSDXC card Support for SD card encryption Support for recording to network-attached storage (NAS) For SD card and NAS recommendations see axis.com | |
| Operating Conditions: 0 °C to 45 °C (32 °F to 113 °F) Humidity 10–85% RH (non-condensing) | |
| Storage Conditions | -40 °C to 65 °C (-40 °F to 149 °F) Humidity 5–95% RH (non-condensing) |
| Dimensions | Height: 71 mm (2.8 in) ø 121 mm (4.76 in) |
| Weight | 350 g (0.77 lb) |
| Included Accessories | Installation guide, Windows® decoder 1-user license |
| Optional Accessories | AXIS TM3207 Recessed Mount AXIS T94C01L Recessed Mount AXIS T94C01U Universal Mount AXIS T94C01M J-Box/Gang Box Plate AXIS M42 Casing A Black 4P AXIS M42 Smoked Dome A 4P AXIS T91A33 Lighting Track Mount AXIS T91A23 Tile Grid Ceiling Mount AXIS TM3101 Pendant Wall Mount AXIS Surveillance Cards For more accessories, see axis.com |
| Video Management Software | AXIS Companion, AXIS Camera Station, and video management software from Axis Application Development Partners. For more information, see axis.com/vms |
| Languages | English, German, French, Spanish, Italian, Russian, Japanese, Korean, Portuguese, Simplified Chinese, Traditional Chinese, Dutch, Czech, Swedish, Finnish, Turkish, Thai, Vietnamese |
All IP cameras and recording devices (NVR’s/DVR’s) are covered by a 3 year back-to-base manufacturer warranty.
Our warranty is limited to the replacement of faulty items or parts and does not include damage due to incorrect fitting of parts or accessories, or damage due to mishandling the equipment once out of the box. All faults are sent to the manufacturer for inspection and diagnosis before a replacement is sent out.
Read more about the Terms & Conditions here – https://www.securityaustralia.com.au/terms-and-conditions/
*Just spend over $100 to activate Fast Free Shipping!
Despatch Times: Products are despatched on the same day if the order was placed before 11am on any weekday, Monday - Friday. All other orders are processed and despatched within 24 hours or next business day.
Order Confirmation: Once you place an order, you will receive a confirmation email. This indicates that your order has been received in our system and is now being processed for dispatch. If your item is back-ordered or unavailable, we will notify you via email, and if we do not receive a response, we will attempt to contact you by phone as soon as possible. We value your time and strive to be prompt. If your item(s) are available for immediate shipment (within 2 days), we will process the charges and prepare the order for shipping.
Shipping Times: General shipping times for StarTrack, TNT and Allied couriers are between 1-3 working days from despatch. Longer delivery times may be caused by your package being held at your local courier depot that is beyond our control. Please contact us or the local post depot for confirmation.
Tracking Numbers: all tracking numbers will be emailed to you by our warehouse processing team within the day, after your order is despatched to our local courier.
AXIS M4216–V Fixed Network Camera, 1080p, Zipstream, WDR, PoE, 3 - 6mm VF Lens
The AXIS M4216–V Dome Camera is a versatile surveillance solution designed for various security needs. With its compact and discreet design, it integrates seamlessly into both residential and commercial environments. The camera offers a 4 MP resolution, ensuring clear and detailed video footage. Equipped with Axis' Lightfinder technology, it performs exceptionally well in low-light conditions. The built-in Wide Dynamic Range (WDR) helps capture clear images even in challenging lighting scenarios. Its built-in microphone allows for audio recording, adding another layer of security. The camera is also weather-resistant, making it suitable for outdoor use. It supports Power over Ethernet (PoE), simplifying installation by eliminating the need for separate power cables. The AXIS M4216–V is equipped with advanced analytics features, including motion detection and tampering alarms, enhancing its functionality. Overall, it provides a reliable and comprehensive surveillance solution for a variety of applications.
Features
| Camera | Image Sensor: 1/2.7” progressive scan RGB CMOS |
| Lens: Varifocal, 3–6 mm, F1.9 - 2.7 | |
| Horizontal Field of View: 100°–45° | |
| Vertical Field of View: 72°–34° Remote Focus and Zoom: Fixed iris Day and Night: Automatic IR-cut filter |
|
| Minimum Illumination | Color: 0.18 lux at 50 IRE F2.0 B/W: 0.03 lux at 50 IRE F2.0 |
| Shutter Speed | 1/37500 s to 1/5 s |
| Camera Angle Adjustment | Pan ±180°, tilt -40 to +65°, rotation ±105° Can be directed in any direction and see the wall/ceiling |
| System on Chip (SoC) | Model CV25 |
| Memory | 1024 MB RAM, 512 MB Flash |
| Compute Capabilities | Deep learning processing unit (DLPU) |
| Video | Video Compression: H.264 (Main and High Profiles), H.265 (Main and High Profiles), Motion JPEG |
| Resolution: 2304x1728 to 320x240 | |
| Frame Rate: Up to 25/30 fps with power line frequency 50/60 Hz in H.264 and H.265a Video Streaming: Multiple, individually configurable streams in H.264, H.265, and Motion JPEG Axis Zipstream technology in H.264 and H.265 Controllable frame rate and bandwidth VBR/MBR H.264/H.265 Low latency mode |
|
| HDMI Output | HDMI 1080p (16:9) @25/30 Hz refresh rate HDMI 720p (16:9) @50/60 Hz refresh rate |
| Multi-view Streaming | Up to 2 individually cropped out view areas in full frame rate |
