AXIS I8116-E Network Video Intercom with 5MP Camera, SIP Support & IP65 Rating

Model: AXIS I8116-E

Who This Is For

Security integrators specifying visitor management at commercial entrances, gated facilities, or multi-tenant buildings will find the AXIS I8116-E a well-considered fit. It combines a 5MP camera with SIP-based two-way audio into a single outdoor-rated unit, meaning reception staff or a remote operator can see, speak with, and verify a visitor without any additional hardware at the door. The IP65 rating handles exposed outdoor mounting - front entrances, car park boom gate pedestals, loading dock intercom posts - without shelter concerns. SIP compatibility means it can register directly to an existing IP PBX or cloud phone system, so the call rings through to a desk phone, softphone, or mobile rather than a proprietary handset. Facilities teams managing multiple entry points across a site also use the I8116-E because it integrates into AXIS Camera Station or third-party VMS platforms for centralised management.

What This Intercom Actually Does

Who Buys This Model

• Commercial Building Managers: Specifying a visitor intercom for a lobby or car park entry where the call needs to route to reception via an existing IP phone system rather than a standalone handset.
• Industrial and Logistics Sites: Installing at a guardhouse bypass, pedestrian gate, or loading dock intercom post where the unit will face direct weather exposure and needs IP65 protection without a separate enclosure.
• Multi-Tenant Commercial Properties: Where SIP routing lets a single intercom call different tenants based on button selection, and where VMS integration means the intercom video is managed alongside the rest of the CCTV system.
• IT and AV Integrators: Deploying AXIS hardware into an existing IP infrastructure where ONVIF compliance and AXIS OS mean the intercom fits the same management and licensing model as the rest of the camera estate.
• Education and Healthcare Facilities: Controlling access to reception, secured wards, or school entry gates where staff need to see and speak with a visitor before granting access from a workstation or mobile device.

Honest Assessment

The AXIS I8116-E does the core job of an outdoor network intercom genuinely well. The 5MP sensor delivers more usable detail at door range than most intercom cameras on the market, the SIP stack is stable and integrates cleanly with mainstream IP PBX platforms, and the IP65 rating is appropriate for the exposed mounting positions these units typically occupy. Wide dynamic range performance at backlit entrances is a practical strength, not just a checkbox. Where this unit is not the right tool: it does not include an integrated access reader or relay output for direct door release without additional hardware. If the install requires card or PIN-based entry at the same point, an AXIS door station or combined access intercom with integrated reader will be a more appropriate product type. The I8116-E is also a premium-tier product supplied by Security Australia - buyers comparing on purchase price alone may find value-brand alternatives, but those rarely offer the same VMS integration depth or platform longevity.

Before You Buy

Quick Fit Check

• Good match if: You are installing at an outdoor entry point where the call needs to route to an existing SIP phone system and the Cat network run will carry both power and data via PoE.
• Good match if: Your site uses AXIS Camera Station or an ONVIF-compatible VMS and you want the intercom video feed managed in the same platform as the rest of the camera system.
• You may need a different model if: The entry point also requires integrated card or PIN-based access control at the same unit - a combined video intercom and access reader product type will handle this without additional hardware.

Key Features & Technical Specifications

Real-World Scenarios

How It Compares

• Choose this if: You need a high-resolution outdoor intercom that integrates into an existing SIP phone system and a VMS platform without proprietary hardware at the answering end.
• You may need a different model if: The entry point also requires a built-in card reader or keypad - a combined video intercom and access control unit is the appropriate product type for credential-based entry at the same device.
• Pairs well with: A PoE network switch for clean single-cable infrastructure, an IP relay module for electric strike or magnetic lock control, and a SIP-enabled IP PBX or hosted telephony service for call routing.

Common Questions

1. Does the AXIS I8116-E work with any SIP phone system, or does it require AXIS software?

   Yes - it works with any standards-compliant SIP platform. The I8116-E registers as a SIP endpoint, so it is compatible with Cisco, Yealink, 3CX, Microsoft Teams (via SIP gateway), and most hosted PBX services. You do not need AXIS Camera Station or any AXIS-specific software to handle the audio call routing.

2. Will this intercom directly release a door strike or magnetic lock?

   No, not without additional hardware. The I8116-E does not include a built-in relay output for door release. A separate relay module or access controller needs to be wired in series if you want the answering party to trigger an electric strike or maglock remotely. Plan this into your hardware list and cable schedule before installation.

3. Does the IP65 rating mean I can install this completely exposed to weather?

   Yes. IP65 confirms full dust ingress protection and resistance to water jets from any direction - it is appropriate for unsheltered outdoor mounting. The IK08 vandal resistance rating also means the unit can withstand a meaningful impact force, which matters at public-facing entry points. No additional enclosure is required for standard outdoor exposure.

4. What PoE standard does the AXIS I8116-E require?

   It operates on IEEE 802.3af PoE - the standard 15.4W class. A standard PoE switch port or PoE injector is sufficient. You do not need PoE+ (802.3at) or any higher-wattage supply, which means the I8116-E can be powered from most existing managed PoE switches without budget allocation for upgraded ports.

5. Can the intercom video be recorded and managed alongside CCTV cameras in the same system?

   Yes. The I8116-E supports ONVIF Profile S and Profile T, meaning it integrates into AXIS Camera Station and most third-party VMS platforms as a standard IP camera stream. The intercom video feed can be recorded, reviewed, and managed from the same interface as the rest of the camera estate - no separate recording system needed for the intercom channel.

6. Does the 5MP camera perform well at backlit entry points where the sun is behind visitors?

   Yes, within the limits of digital WDR processing. The I8116-E includes wide dynamic range to manage high-contrast scenes - a common issue at west-facing entries in the afternoon or any entry where sky or artificial backlighting competes with the subject. Performance is substantially better than fixed-exposure cameras in the same position, though extremely harsh direct sun can still challenge any optical system. Available through Security Australia, the I8116-E is a product where the sensor quality justifies the investment for identification-critical applications.

7. Can AXIS applications be installed on the I8116-E to add analytics or access features?

   Yes. The I8116-E runs AXIS OS, which is an open platform that supports AXIS Analytics applications and compatible third-party apps installed directly on the device. This means capabilities such as object detection or tailored access logic can be added via the AXIS application library without requiring an external server to run the processing.

Cabling Considerations

• Cable Type: Cat5e minimum, Cat6 recommended for future-proofing and to minimise signal degradation on longer runs.
• Max Cable Run: 100 metres from PoE switch to device for both network and PoE power - standard Ethernet limitation. Runs beyond this require a PoE extender or intermediate switch.
• PoE Notes: IEEE 802.3af PoE only - no PoE+ required. Ensure your switch port is confirmed PoE-capable before commissioning, particularly on unmanaged switches where not all ports may be powered.
• Door Release Wiring: If integrating with a relay module for electric strike or maglocked door, run a separate cable pair from the relay to the door frame hardware - typically 2-core security cable rated for the lock's current draw. Plan this run at rough-in stage alongside the Cat cable.
• Conduit and Weatherproofing: At outdoor mounting positions, seal the cable entry point into the intercom housing with appropriate weatherproof conduit fittings or cable glands to maintain the IP65 rating of the installation - the unit is rated, but an open cable entry point bypasses that protection.
