Hikvision DS-9016HUHI-K8 80Mbps Hybrid NVR (up to 16ch Analog + 16ch IP), 8 SATA I/O:16/4 3TB HDD, RAID
- Sku: HIK-9016HFI-RT
- Vendor: SecurityAustralia
$3,520.00 AUD
Tax included.
Quick Buying Summary
16-ch 5 MP 2U H.265 DVR
The DS-9016HUHI-K8 supports remote access via Hikvision's iVMS-4200 software, allowing users to view live feeds and playback recordings from any location. It includes intelligent analytics such as motion detection and line crossing, which enhances security by alerting users to potential incidents. The DVR also boasts robust network security features to protect against unauthorized access and cyber threats. It is compatible with various Hikvision IP cameras, offering flexibility in system design and integration. The unit is designed for reliability, with a cooling system that prevents overheating and ensures stable performance.
Key Features
- 16 channels and 8 HDDs 2U DVR
- Efficient H.265 pro+ compression technology
- Encoding ability up to 8 MP @ 8 fps, 5 MP @ 12 fps
- 5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP)
- Up to 34 network cameras can be connected
- Supports POS triggered recording and POS information overlay
- Supports RAID mode for even more reliable data storage, effectively avoiding data loss risks
Code/SKU: DS-9016HUHI-K8
Quick Specs:
- Working Temperature: -10 °C to +55 °C (+14 °F to +131 °F)
- Working Humidity: 10% to 90%
- Dimension (W × D × H): 445 × 470 × 90 mm (17.5 × 18.5 × 3.5 inch)
- Weight: ≤ 8 kg (17.6 lb)
Accessories
Select options before adding this product to cart.
Free shipping - Enjoy free shipping when your order exceeds $100!
All orders are despatched within the next business day!
Best local support in Aus! We back all products with a 3 year manufacturer warranty.
Not sure if this suits your site?
Ask our team before ordering. We can help confirm lens choice, recorder compatibility, mounting accessories and project quantities.
Product Overview
Hikvision DS-9016HUHI-K8 80Mbps Hybrid NVR (up to 16ch Analog + 16ch IP), 8 SATA I/O:16/4 3TB HDD, RAID
The Hikvision DS-9016HUHI-K8 is a versatile hybrid NVR designed to support up to 16 channels of analog cameras and 16 channels of IP cameras. With a maximum bandwidth of 80 Mbps, this NVR delivers high-quality video streaming and recording, ensuring efficient operation within surveillance systems.
With support for advanced H.265 video compression, the DS-9016HUHI-K8 optimizes storage space while maintaining superior video quality, which is crucial for environments with extensive monitoring needs. The unit also features RAID support, enhancing data redundancy and ensuring that video footage remains secure and accessible.
The device's multiple video outputs, including HDMI and VGA interfaces, allow for seamless integration with various display systems, making it an ideal choice for both professional and commercial surveillance applications.
Features:
- Hybrid NVR Design: Supports up to 16 analog and 16 IP channels, offering flexibility for diverse surveillance setups with varying types of cameras.
- High Bandwidth: Capable of handling up to 80 Mbps, ensuring smooth video recording and playback without lag, even with multiple high-resolution streams.
- H.265 Compression: Utilizes H.265 compression to significantly reduce storage requirements while retaining excellent image quality, optimizing efficiency for large-scale surveillance.
- RAID Support: Includes RAID functionality for enhanced data redundancy and security, protecting vital footage from potential hard drive failures.
- Multiple Video Outputs: Equipped with HDMI and VGA outputs, allowing for simultaneous display of multiple video feeds on different monitors for effective monitoring.
- User-Friendly Interface: Designed with an intuitive GUI that simplifies configuration and management, making it easy for users to navigate and operate the system.
- Remote Access Capabilities: Supports remote monitoring and management via Hikvision's software, enabling users to view live feeds and playback recordings from anywhere.
- Robust Build Quality: Engineered for reliability and durability, ensuring stable operation and performance even in demanding surveillance environments.
Functions:
Comprehensive Video Management:
This NVR enables effective management of multiple camera feeds, facilitating live viewing, recording, and playback for thorough surveillance coverage and operational oversight.
Seamless Streaming and Playback:
Provides a smooth experience for viewing recorded footage without interruptions, allowing users to efficiently review incidents and conduct investigations.
Advanced Recording Options:
Offers various recording modes and features, including motion detection, to optimize video data storage and enhance security monitoring efficiency.
Flexible Integration:
Compatible with both analog and IP cameras, allowing users to tailor their surveillance systems to specific needs and preferences.
Real-Time Alerts:
Includes intelligent analytics for proactive surveillance, providing instant notifications for specific events or anomalies detected by the camera system.
Remote Configuration and Monitoring:
Allows for remote control and configuration from mobile devices or web browsers, providing flexibility in managing surveillance systems.
Enhanced Security Features:
Incorporates robust security protocols to protect against unauthorized access and safeguard sensitive footage against cyber threats.
User Empowerment:
Equips users with the tools and features they need to effectively manage their surveillance operations and maintain security integrity.
Technical Specifications
| Model | DS-9016HUHI-K8 |
| Channels Supported | 16 Analog TVI + 16 IP Camera Channels |
| IP Video Input | Up to 34-ch (12 MP resolution for IP) |
| Analog Video Input | 16-ch, BNC interface (1.0 Vp-p, 75 Ω) |
| Max. Resolution for IP Cameras | Up to 12 MP |
| Incoming Bandwidth | 320 Mbps |
| Outgoing Bandwidth | 256 Mbps |
| Incoming Bandwidth (RAID Mode) | 200 Mbps |
| Outgoing Bandwidth (RAID Mode) | 200 Mbps |
| Video Compression | H.265, H.265+, H.264, H.264+ |
| Storage Options | 8 SATA interfaces, supports HDDs up to 10TB each |
| Video Output | HDMI (up to 4K), VGA output |
| Power Supply | 100-240 VAC, 50/60 Hz |
| Power Consumption | ≤ 40W (without HDD) |
| Operating Temperature | -10 °C to +55 °C (14 °F to 131 °F) |
| Dimensions (W × D × H) | 440 × 400 × 71 mm (17.32 × 15.75 × 2.76 inches) |
| Weight | Approx. 5 kg (11.02 lb) (without HDD) |
| Network Interfaces | 4 × RJ-45 10/100/1000 Mbps self-adaptive ports |
| Smart Features | Motion detection, smart tracking, and deep learning analytics |
| Specifications | |
|---|---|
| Video and Audio | |
| IP Video Input | 18-ch (up to 34-ch), Up to 12 MP resolution, Support H.265+/H.265/H.264+/H.264 IP cameras |
| Analog Video Input | 16-ch, BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection |
| HDTVI Input | 8 MP, 5 MP, 4 MP, 3 MP, 1080p25, 1080p30, 720p25, 720p30, 720p50, 720p60 |
| AHD Input | 5 MP, 4 MP, 720p25, 720p30, 1080p25, 1080p30 |
| HDCVI Input | 4 MP, 720p25, 720p30, 1080p25, 1080p30 |
| CVBS Input | PAL/NTSC |
| CVBS Output | 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| HDMI 1 Output | 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| VGA Output | 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| HDMI 2 Output | 1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Video Loop | Support |
| Audio Input | 16-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Audio Output | 2-ch, RCA (Linear, 1 KΩ) |
| Two-Way Audio | 1-ch, RCA (2.0 Vp-p, 1 KΩ) (independent) |
| Synchronous Playback | 16-ch |
| Recording | |
| Video Compression | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Encoding Resolution | 8 MP/5 MP/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF |
| Frame Rate | Main stream: 8 MP@8fps; 5 MP@12fps; 4 MP@15fps; 3 MP@18fps; 1080p/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N), Sub-stream: WD1/4CIF/CIF@25fps (P)/30fps (N) |
| Video Bitrate | 32 Kbps to 10 Mbps |
| Dual-stream | Support |
| Stream Type | Video, Video & Audio |
| Audio Compression | G.711u |
| Audio Bitrate | 64 Kbps |
| Network | |
| Remote Connection | 128 |
| Network Protocol | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF, SNMP |
| Network Interface | 2, RJ45 10M/100M/1000M self-adaptive Ethernet interface |
| Auxiliary Interface | |
| SATA | 8 SATA interfaces |
| eSATA | Support |
| Capacity | Up to 10 TB capacity for each disk |
| Serial Interface | RS-232, RS-485 (full-duplex), Keyboard |
| Alarm In/Out | 16/8 |
| USB Interface | Front panel: 2 × USB 2.0, Rear panel: 1 × USB 3.0 |
| General | |
| Power Supply | 100 to 240 VAC, 50 to 60 Hz, 1.3 A |
| Consumption | ≤ 65 W (without HDD) |
| Working Temperature | -10 °C to +55 °C (+14 °F to +131 °F) |
| Working Humidity | 10% to 90% |
| Dimension (W × D × H) | 445 × 470 × 90 mm (17.5 × 18.5 × 3.5 inch) |
| Weight | ≤ 8 kg (17.6 lb) |
