The Hikvision 6MP AcuSense Turret Camera is engineered to provide exceptional surveillance capabilities. Empowered by deep learning algorithms, this camera brings human or vehicle target classification alarms to front and back-end devices, significantly reducing false alarms generated by non-human or vehicle movement. This advancement greatly enhances alarm efficiency and effectiveness.
Features:
Code/SKU: DS-2CD2366G2-IU
Quick Specs: H.265+, IR 30m, IP67, Built-in Mic.
| Camera | |
|---|---|
| Image Sensor | 1/2.4" Progressive Scan CMOS |
| Max. Resolution | 3200 × 1800 |
| Min. Illumination | Color: 0.003 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR |
| Shutter Time | 1/3 s to 1/100,000 s |
| Day & Night | IR cut filter |
| Angle Adjustment | Pan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360° |
| Lens | |
| Lens Type | Fixed lens, 2.8, 4, and 6 mm optional |
| Focal Length & FOV | 2.8 mm, horizontal FOV 105°, vertical FOV 55°, diagonal FOV 127°; 4 mm, horizontal FOV 78°, vertical FOV 38°, diagonal FOV 96°; 6 mm, horizontal FOV 51°, vertical FOV 26°, diagonal FOV 59° |
| Lens Mount | M12 |
| Iris Type | Fixed |
| Aperture | F1.6 |
| DORI | |
| DORI | 2.8 mm: D: 76 m, O: 30 m, R: 15 m, I: 7 m; 4 mm: D: 115 m, O: 45 m, R: 23 m, I: 11 m; 6 mm: D: 164 m, O: 65 m, R: 32 m, I: 16 m |
| Illuminator | |
| Supplement Light Type | IR |
| Supplement Light Range | Up to 30 m |
| Smart Supplement Light | Yes |
| IR Wavelength | 850 nm |
| Video | |
| Main Stream | 50 Hz: 25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) |
| Sub-Stream | 50 Hz: 25 fps (1280 x 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 x 720, 640 × 480, 640 × 360) |
| Third Stream | 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is supported under certain settings. |
| Video Compression | Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 *Third stream is supported under certain settings. |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| H.264 Type | Baseline Profile, Main Profile, High Profile |
| H.265 Type | Main Profile |
| Bit Rate Control | CBR, VBR |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
| Region Of Interest (ROI) | 1 fixed region for main stream and sub-stream |
| Audio | |
| Audio Type | -U: Mono sound |
| Audio Compression | -U: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio Bit Rate | -U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
| Audio Sampling Rate | -U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Environment Noise Filtering | -U: Yes |
| Network | |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP |
| Simultaneous Live View | Up to 6 channels |
| API | Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP |
| User/Host | Up to 32 users. 3 user levels: administrator, operator, and user |
| Security | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address) |
| Network Storage | NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR) Together with high-end Hikvision memory card, memory card encryption and health detection are supported. |
| Client | iVMS-4200, Hik-Connect, Hik-Central |
| Web Browser | Plug-in required live view: IE 10, IE 11 Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+ Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ |
| Image | |
| Image Parameters Switch | Yes |
| Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser |
| Day/Night Switch | Day, Night, Auto, Schedule |
| Image Enhancement | BLC, HLC, 3D DNR |
| SNR | ≥ 52 dB |
| Wide Dynamic Range (WDR) | 120 dB |
| Privacy Mask | 4 programmable polygon privacy masks |
| Interface | |
| Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
| On-Board Storage | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB |
| Built-in Microphone | Yes |
| Reset Key | Yes |
| Event | |
| Basic Event | Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception |
| Smart Event | Scene change detection |
| Linkage | Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture, trigger alarm output |
| Deep Learning Function | |
| Face Capture | Yes |
| General | |
| Power | 12 VDC ± 25%, 0.45 A, max. 5.4 W, Ø5.5 mm coaxial power plug, reverse polarity protection PoE: IEEE 802.3af, Class 3, max. 6.5 W |
| Material | Metal except for trim ring |
| Dimension | Ø138.3 mm × 111.4 mm (Ø5.4" × 4.4") |
| Package Dimension | 170 mm × 170 mm × 150 mm (6.7" × 6.7" × 5.9") |
| Weight | Approx. 740 g (1.6 lb.) With Package Weight: Approx. 1070 g (2.4 lb.) |
| Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Language | |
| 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian | |
| General Function | |
| Heartbeat, mirror, flash log, password reset via email, pixel counter, anti-flicker | |
| Approval | |
| EMC | CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014 RCM: AS/NZS CISPR 32: 2015 KC: KN32: 2015, KN35: 2015 |
| Safety | UL: UL 62368-1 CB: IEC 62368-1: 2014+A11 CE-LVD: EN 62368-1: 2014/A11: 2017 |
| Environment | CE-RoHS: 2011/65/EU WEEE: 2012/19/EU Reach: Regulation (EC) No 1907/2006 |
| Protection | IP67: IEC 60529-2013 |
All IP cameras and recording devices (NVR’s/DVR’s) are covered by a 3 year back-to-base manufacturer warranty.
Our warranty is limited to the replacement of faulty items or parts and does not include damage due to incorrect fitting of parts or accessories, or damage due to mishandling the equipment once out of the box. All faults are sent to the manufacturer for inspection and diagnosis before a replacement is sent out.
Read more about the Terms & Conditions here – https://www.securityaustralia.com.au/terms-and-conditions/
*Just spend over $100 to activate Fast Free Shipping!
Despatch Times: Products are despatched on the same day if the order was placed before 11am on any weekday, Monday - Friday. All other orders are processed and despatched within 24 hours or next business day.
Order Confirmation: Once you place an order, you will receive a confirmation email. This indicates that your order has been received in our system and is now being processed for dispatch. If your item is back-ordered or unavailable, we will notify you via email, and if we do not receive a response, we will attempt to contact you by phone as soon as possible. We value your time and strive to be prompt. If your item(s) are available for immediate shipment (within 2 days), we will process the charges and prepare the order for shipping.
Shipping Times: General shipping times for StarTrack, TNT and Allied couriers are between 1-3 working days from despatch. Longer delivery times may be caused by your package being held at your local courier depot that is beyond our control. Please contact us or the local post depot for confirmation.
Tracking Numbers: all tracking numbers will be emailed to you by our warehouse processing team within the day, after your order is despatched to our local courier.
Hikvision Acusense DS-2CD2366G2-IU IP Camera 6MP Turret Network Camera WHITE
Hikvision AcuSense DS-2CD2366G2-IU IP Camera 6MP Turret Network Camera
Enhance your surveillance capabilities with the Hikvision DS-2CD2366G2-IU, an 8MP turret network camera that integrates AcuSense technology. This camera distinguishes between humans and vehicles, reducing unnecessary false alarms caused by other movements.
With its 6MP resolution, you can capture high-quality images that provide clarity and precision for effective monitoring in various environments, ensuring that all critical details are accurately recorded.
Designed for versatility, the DS-2CD2366G2-IU features a built-in microphone, enabling two-way audio communication for real-time interaction. This is ideal for responding to live situations as they occur.
Utilizing advanced H.265+ compression technology, the camera minimizes bandwidth and storage needs without compromising video quality, making it efficient for long-term monitoring and data management.
With 120 dB Wide Dynamic Range (WDR) technology, the camera ensures that clear images are captured in varying light conditions, effectively handling challenging environments with strong contrasts.
Built to withstand harsh environments, this camera boasts an IP67 rating, protecting against dust and water ingress, making it suitable for outdoor installations in various weather conditions.
Equipped with advanced analytics for motion detection and classification, the camera provides accurate alerts and notifications through its intelligent system, enhancing your security management capabilities significantly.
This camera also includes various lens options, offering flexibility in installation and allowing for optimal coverage in various settings, adjusting to the needs of any surveillance application.
Features
Functions
Advanced Motion Detection:
The camera utilizes intelligent algorithms for effective motion detection, notifying users promptly of any identified movements in predefined areas, ensuring proactive security surveillance management.
Customizable Privacy Masking:
Users can configure privacy masks to conceal specific areas from recording, maintaining compliance with privacy regulations while ensuring comprehensive security monitoring for necessary locations.
Remote Access:
Seamlessly access live and recorded footage from smartphones or PCs, enabling convenient monitoring of surveillance systems from anywhere, ensuring constant visibility over protected areas.
Smart Notifications:
Employs intelligent features to send real-time alerts for classified human and vehicle detection events, allowing for swift responses to potential security incidents.
Day/Night Functionality:
Equipped with automatic simultaneous day/night switching, this camera maintains optimal performance in both daylight and nighttime conditions, ensuring consistent tracking and monitoring throughout all times.
Integrated Analytics:
Includes features such as line crossing and intrusion detection, analyzing video feeds to enhance overall security effectiveness by providing actionable insights and alerts during monitoring.
Flexible Installation:
Designed for easy mounting and configuration, offering versatile installation options that adapt to various environments, ensuring comprehensive coverage and effective surveillance management.
High-Quality Audio Capture:
The built-in microphone allows for superior audio monitoring, enabling users to listen and respond to sound events occurring in the monitored area, enhancing overall situational awareness.
Technical Specifications:
| Model | DS-2CD2366G2-IU |
| Image Sensor | 1/2.4" Progressive Scan CMOS |
| Max. Resolution | 3200 × 1800 (6 MP) |
| Minimum Illumination | Color: 0.003 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
| Wide Dynamic Range (WDR) | 120 dB |
| Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 75°, Rotate: 0° to 360° |
| Built-in Microphone | Yes, for real-time audio security (-U model) |
| Weatherproof Rating | IP67 |
| Shutter Speed | 1/3 s to 1/100,000 s |
| Power Supply | 12 VDC, PoE (802.3af) |
| IR Range | Up to 30 meters |
| Lens Options | 2.8 mm (Horizontal FOV: 105.1°) |
| DORI Values (2.8mm) | Detection: 78.6 m, Observation: 31.2 m, Recognition: 15.7 m, Identification: 7.9 m |
