Dahua 8 x 6MP DH-IPC-HDW3666EMP-S-AUS SMD 4.0 AI Turret Kit 50m IR 2.8mm with SMD + 8CH AI NVR

The DH-IPC-HDW3666EMP-S-AUS is a 6MP fixed-focal network camera that delivers high-resolution video with a 3072 x 2048 pixel resolution, thanks to its advanced 1/1.8” CMOS sensor. It features a fixed 3.6mm lens for a wide field of view and supports infrared night vision up to 50 meters for clear imaging in low-light conditions. With integrated WizSense technology, the camera enhances intelligent detection and analysis capabilities, while true WDR (Wide Dynamic Range) helps manage complex lighting conditions.

It uses H.265 and H.264 compression formats to reduce bandwidth and storage needs. The camera includes a built-in microphone for audio recording, is IP67 rated for dust and water resistance, and supports PoE (Power over Ethernet) for easy installation. It integrates with Dahua’s SmartPSS software and other VMS solutions, offers intelligent analytics features like line crossing and intrusion detection, and supports local recording via microSD card. Its compact, discreet design ensures it blends into various environments while providing reliable, high-performance surveillance.

Features:

• Records up to 6MP, 1/2.7” CMOS image sensor, low illuminance, high image definition
• 2.8mm Fixed lens
• Outputs max. 6 MP (3072 x 2048) @25/30 fps.
• Supports Starlight technology, generates clear images in near-complete darkness.
• Supports PoE "Power-Over-Ethernet" installations.
• Built-In Mic
• Intelligent Detection: Intrusion, tripwire and motion (Up to 4 areas)
• Supports 50m Smart Infrared Range
• 120 dB Wide Dynamic Range WDR. 3D Digital Noise Reduction 3D DNR.
• Day/Night Infrared Cut Removal ICR. Auto White Balance AWB. Automatic Gain Control AGC. Backlight Compensation BLC. Highlight Compensation HLC. Region of Interest ROI.
• Supports MicroSD Card Storage up to 256 Gigabytes.
• Resilient "Weather-Proof" Ingress Protection Rating (IP67).
• Metal Housing

Functions:

Smart (H.265+ & H.264+)

With advanced scene-adaptive rate control algorithm, Dahua smart encoding technology realizes the higher encoding efficiency than H.265 and H.264, provides high-quality video, and reduces the cost of storage and transmission. Wide dynamic range (WDR) Dahua adopts advanced Wide Dynamic Range (WDR) technology. You can get clear details in the environment of strong brightness contrast. In high brightness and back- light environment, bright region and dark region with strong light source, you can also get clear images.

Starlight

Dahua Starlight technology mainly applies to the environment of low illumination, and it can provide clear colorful video. Even in the environment of min. illumination, the technology can guarantee a good image effect.

Intelligent Video Analysis (IVS)

With an advanced video algorithm, Dahua camera supports intelligent detection, such as tripwire and intrusion and so on.

Protection (IP67, wide voltage) IP67:

The camera passes a series of strict tests on dust and soak. It has a dust-proof function, and the enclosure can work normally after soaking in 1 m deep water for 30 minutes. Wide voltage: The camera allows ±30% input voltage tolerance (wide voltage range), and it is widely applied to the outdoor environment with unstable voltage.

Technical Specifications:

Starlight technology generates clear colour images in near-complete darkness. A high-performing sensor and special algorithms work together to capture images in low-light and no-light environments. With advanced video algorithms, Dahua's Intelligent Video Surveillance (IVS) technology supports smart functions such as Tripwire and Intrusion Detection.

The NVR4000-AI/ANZ series is a new generation of network recorders that offers powerful decoding capabilities and strong bandwidth. It features high-precision face recognition, perimeter protection, and SMD (Smart Motion Detection), which can distinguish target vehicles and humans from other types in real time. When connected with select IPC cameras, Quick Pick technology becomes available, allowing human and vehicle targets to be easily searched for and picked out. This network recorder is not only cost-effective but also compatible with a wide variety of third-party devices, making it a great choice for small and medium-sized businesses.

The Dahua 8 Channels Compact 1U 8PoE 1HDD WizSense Network Video Recorder (NVR4108HS-8P-AI/ANZ) offers efficient and reliable video surveillance management for various settings. It supports up to 8 IP cameras, providing seamless integration and simplified installation through its 8 PoE (Power over Ethernet) ports. This compact 1U device is designed to save space while delivering robust performance. The recorder features advanced AI capabilities for enhanced video analytics, enabling smarter detection and classification of objects. With support for one HDD, users can easily manage and store extensive video data, making it ideal for small to medium-sized installations. The NVR4108HS-8P-AI/ANZ is equipped with a user-friendly interface for intuitive setup and operation. Its compatibility with Dahua’s WizSense technology ensures superior image quality and accurate event detection.

The device is built to handle high-resolution video streams and offers reliable performance in various environmental conditions. It provides various recording modes, including continuous, scheduled, and motion-based recording, to meet different security needs. The compact design is suitable for installation in confined spaces, making it versatile for various applications. Enhanced with network security features, the recorder protects against unauthorized access and ensures data integrity. The NVR4108HS-8P-AI/ANZ is a robust and versatile solution for comprehensive video surveillance management.

Features

• Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.
• Access, storage or forwarding at 256 Mbps (180 Mbps when AI function enabled).
• Max. decoding capability: 16 × 1080p@30 fps. Supports adaptive decoding.
• AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.
• AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; ANPR; people counting; stereo analysis; heat map.
• Connected to the third-party network cameras.
• Security baseline 2.3.

Functions

Face Detection:
Face detection identifies human faces appearing in video footage. It uses a deep learning algorithm to detect, track, optimize, and capture faces, providing the best possible snapshot.

Face Recognition:
Dahua's Face Recognition technology extracts features from captured faces and compares them with a database to identify individuals.

Perimeter Protection:
This feature filters out false alarms caused by animals, rustling leaves, or bright lights. It allows for secondary recognition of targets, improving the accuracy of alarms.

SMD Plus:
Dahua's Smart Motion Detection (SMD) technology uses an intelligent algorithm to categorize targets and filter out non-relevant motion detection alarms, resulting in more precise and effective alerts.

AI Search:
AI Search allows for the quick identification of targets by searching metadata or uploading and comparing face pictures with recorded images. This feature facilitates efficient multi-channel and long-duration searches to pinpoint when and where a person of interest appeared.

Heat Map by Camera:
Dahua’s heat map technology visualizes crowd density and the probability of people appearing in specific areas. It uses color coding to display crowd status, offering statistical insights into the number of people present over time and space.

ANPR by Camera:
Using a deep learning algorithm, Dahua's Automatic Number Plate Recognition (ANPR) technology reads vehicle license plates. It supports blocklist/allowlist modes and enables searching for target vehicles in recorded footage.

Quick Pick:
Dahua’s Quick Pick technology helps users swiftly select and retrieve human or vehicle targets from SMD events, streamlining the process of finding specific objects of interest.

Technical Specifications:

Enhance your security with the Dahua Camera System Kit. Experience superior clarity, advanced analytics, and reliable performance. Upgrade your surveillance system today!
